Java Instrumentation Suite: Accurate Analysis
of Java Threaded Applications
Jordi Guitart, Jordi Torres, Eduard Ayguadé, José Oliver and Jesús Labarta European Center for Parallelism of Barcelona (CEPBA) Computer Architecture Department, Technical University of Catalonia C/ Jordi Girona 1-3, Campus Nord UPC, Mòdul C6, E-08034 Barcelona (Spain) {jguitart, torres, eduard, joseo, jesus}@ac.upc.es
Abstract. The rapid maturing process of the Java technology is encouraging users the development of portable applications using the Java language. As an important part of the definition of the Java language, the use of threads is becoming commonplace when programming this kind of applications. Understanding and tuning threaded applications requires the use of effective tools for detecting possible performance bottlenecks. Most of the available tools summarize the behavior of the application in a global way offering different metrics that are sufficient to optimize the performance of the application in some cases. However, they do not enable a detailed analysis of the behavior of the application; this requires the use of tools that perform an exhaustive and time-aware tracing at a fine-grain level. This paper presents the Java Instrumentation Suite (JIS), a set of tools designed to instrument Java threaded applications using dynamic code interposition (avoiding the instrumentation and recompilation of the source code and/or the Java Virtual Machine JVM). Our initial implementation targets the JVM version 3.1.1 on top of the SGI Origin parallel platform. The paper describes the design of JIS and highlights some of its main functionalities specifically designed to understand the behavior of Java threaded applications and the JVM itself, and to speed them up.
1. Introduction
One of the reasons that support the recent popularity and widespread diffusion of the Java language is that it eases the implementation of parallel and distributed applications. Java offers multithreading facilities through the built-in support for threads in the language definition. The Java library supplies the Thread class definition, and the Java runtime provides support for thread, mutual exclusion and synchronization primitives. This convenience and easy-of-use come at the expenses of execution speed of Java programs compared to their equivalent counterparts written in conventional languages such as C++. Recent improvements in all the components that integrate the Java execution platform (bytecode compiler, just-in-time compiler and virtual machine) are effectively reducing the performance gap between applications written in Java and applications written in other languages that benefit from more mature compilation and execution technologies. These improvements and the portability inherent in its definition are leading to an increasing number of threaded applications that are being implemented in Java. However, tuning these applications for performance is mostly responsibility of (experienced) programmers [Klem99].
The support for this multithreaded environment requires, for each platform, an efficient mapping of Java threads to the underlying system threads. Thread support traverses many layers: from the application, through various Java classes (e.g., Thread and ThreadGroup), then through the platform-independent layer, the platform-specific layer, and finally to the operating system
itself. While this layering provides a clean separation of responsibilities and allows many platforms to "plug in" their support, it also contributes to extra overhead.
Although a number of tools have been developed to monitor and analyze the performance of parallel applications [ZaSt95, Voss97, JiFL98, WuNa98, XuMN99, BePr99, Jins00], only few of them target multithreaded Java programs. Different approaches are used to carry on the instrumentation process. Paradyn [XuMN99] allows users to insert and remove instrumentation probes during program execution by dynamically relocating the code and adding pre- and post- instrumentation code. Jinsight [Jins00] works with traces generated by an instrumented Java Virtual Machine (JVM). [BePr99] base their work on the instrumentation of the Java source code, thus requiring the recompilation of the application. All of them report different metrics that measure and breakdown, in some way, the application performance. However, none of them enables a fine-grain analysis of the multithreaded execution and the scheduling issues involved in the execution of the threads that come from the Java application. The Java Instrumentation Suite (JIS) enables this detailed analysis of the application behavior by recording the state of each thread along the execution of the application. The instrumentation is done using dynamic code interposition at the JVM level (avoiding modifications in the source code and its recompilation).
Current implementations of the JVM allow Java threads to be scheduled by the virtual machine itself (the so-called green threads model ) or by the operating system (the so-called native threads model ). When using green threads, the operating system does not know anything about threads that are handled by the virtual machine. From the point of view of the operating system, there is a single process and a single thread; it is up to the virtual machine to handle all the details of the threading API. In the native threads model, threads are scheduled by the operating system that is hosting the virtual machine. JIS allows the analysis of threaded applications running on these two execution models.
To our knowledge, it is the first tool that handles the Java thread scheduling representation of an application. JIS is a part of Barcelona Java Suite (BJS) currently under development at CEPBA. The main purpose of BJS is to serve as platform for doing research on scheduling mechanisms and policies oriented towards the efficient execution of multithreaded Java applications on parallel servers.
The remaining of this paper is as follows. Section 2 describes the basic components of JIS. Some preliminary experiments using JIS are reported in Section 3. The paper is concluded in Section 4 and outlines our future research activities in this topic.
2. JIS basics
JIS makes use of two components previously developed at the CEPBA: DITools [SeNC00] and Paraver [LGPC96]. DITools is a set of tools bringing an environment in which dynamically linked executables can be extended at runtime with unforeseen functionality. Code interposition is used in JIS to instrument the code of the JVM. References to specific functions of the dynamically linked libraries used by the JVM are captured and probed. This instrumentation does not require any special compiler support and makes unnecessary to rebuild neither the bytecode of the application nor the executable of the JVM. The probes executed with the intercepted calls generate a trace file with all the information that is required to analyze and visualize the execution of the threaded application. Paraver serves as the visualization tool. It allows the user to navigate through the trace and to do an extensive quantitative analysis. Figure 1 shows the interaction of the above mentioned components in JIS.
ß Information relative to actions performed by a thread, like for instance processor yield, entry (exit) to (from) code protected by a mutual exclusion, notify on a monitor (to awake a previously blocked thread on that monitor for a wait), among others. ß And in general, the invocation of any method in the Java Thread API, like for instance sleep and interrupt.
2.2. Code interposition
Dynamic linking is a feature available in many modern operating systems. Program generation tools (compilers and linkers) support dynamic linking via the generation of linkage tables. Linkage tables are redirection tables that allow delaying symbol resolution to run time. At program loading time, a system component fixes each pointer to the right location using some predefined resolution policies. Usually, the format of the object file as well as these data structures are defined by the system Application Binary Interface (ABI). The standardization of the ABI makes possible to take generic approaches to dynamic interposition.
The monitoring methodology is based on the fact that the JVM invokes a set of run-time services at key places in order to use threads or to synchronize them. The required knowledge about the execution environment can be expressed using a state transition graph, in which each transition is triggered by a procedure call and/or a procedure return. Figure 2 presents the state transition graph for application threads for both execution models (green and native threads) considered in this work, in which nodes represent states, and edges correspond to procedure calls (indicated by a + sing) or procedure returns (indicated by a - sign) causing a state transition. We can also monitor internal threads of the JVM (like the finalizer, garbage collector, ...). In this case, the invocation of other procedures (like InitializeFinalizerThread, InitializeGCThread, ...) are used to trigger the transition to the INIT state instead of the invocation of procedure java_lang_Thread_start.
This transition graph is then used to derive the interposition routines used to keep track of the state in the performance monitoring backend. These routines are simple wrappers of functions that change the thread state, emit an event and/or save thread information in the internal structures of JIS. These wrappers can perform instrumentation actions before (_PRE) and/or after (_POST) the call being interposed. The two following codes show simple examples of procedure wrappers:
void setCurrentThread_wrapper(sys_thread_t * th) { setCurrentThread_PRE ((long)th); setCurrentThread(th); } int pthread_cond_wait_wrapper(pthread_cond_t *p, pthread_mutex_t *m) { pthread_cond_wait_PRE ((long)p,(long)m); ret = pthread_cond_wait(p,m); pthread_cond_wait_POST ((long)p,(long)m); return ret; }
(a) (b) Figure 2. State transition graph for (a) green threads and (b) native threads.
The interposition of other functions lead to the generation of an event in the trace and/or to an update of the internal structures of the instrumentation system (e.g. pthread_mutex_unlock, pthread_cond_signal, pthread_cond_broadcast, sched_yield). These functions do not provoke a direct change in the state of any other thread.
2.3. Instrumentation library
For each action being traced, the tracing environment internally finds which Java thread made the call and the time at which it was done. Timestamps associated to transitions and events are obtained using platform-specific mechanisms (for instance the high-resolution memory-mapped clock) offered by the system.
This data is written (optionally with additional parameters) to an internal buffer for each thread (i.e. there is no need for synchronization locks or mutual exclusion inside the parallel tracing library). The data structures used by the tracing environment are also arranged at initialization time in order to prevent interference among threads (basically, to prevent false sharing). The user can specify the amount of memory used for each thread buffer. When the buffer is full, the runtime system automatically dumps it to disk.
The instrumentation library provides the following services: ß initlib - Initialize the library internal data structures to start a parallel trace receiving as parameters: 1) the maximum number of threads participating in the execution, 2) the maximum amount of memory that the library has to reserve for each thread buffer, and 3) the mechanism used to obtain timestamps. ß changestate - Change the state of a thread. ß pushstate - Store the current state of a thread in a private stack and change to a new one. ß popstate - Change the state of a thread to the one obtained from the private stack.
INIT
RUN
BLOCKED CONDVARIN
BLOCKED MUTEXIN
STOPPED
READY + setCurrentThread
INIT
RUN
BLOCKED CONDVARIN
BLOCKED MUTEXIN
STOPPED
(a)
(b) Figure 3. (a) Thread Creation when running the DHPC_ThreadBench with green threads. (b) Paraver What/Where Window.
Figure 3a shows one of the windows from Paraver displaying a fragment of the trace from an instrumented run using green threads. Notice that the analysis of the application is done at the thread level: each horizontal line in the window represents the activity of an individual thread, internal to JVM (like CLOCK, IDLE, garbage collector GC, ...) or reflecting the user application itself like (like MAIN, USERn, ...) along the time (horizontal axis, in microseconds). Different colors are used to reflect the different states described in Table 1. Figure 3.a shows the point where the MAIN thread is creating 8 additional threads. Notice that two of them (USER7 and USER8) reuse internal thread structures from previous threads and the rest (USER13 – USER18) are new; due to this reuse the JVM takes less time in the creation of the two first ones. We can also observe that at this point, the four threads (USER9 – USER12) that were executing are still queued in the ready queue (they have not finalized their execution because they have not detected that the MAIN thread has updated a shared variable that signals their termination). Once the MAIN thread finishes the creation of threads, it blocks waiting for the termination of the activated parallelism. At this point, threads USER9 – USER12 execute, detect that the shared variable has
been set, and terminate. After that, a sequence in which each of the 8 threads (USER7 – USER and USER13 – USER18) awakes, does some computation and yields follows.
The tracing performed allows the user to interact with Paraver and ask for information related with monitors over which specific actions are performed. For instance, Figure 3.b shows the Paraver What/Where window with this information for one of the events.
Figure 4.a shows a Paraver window with the complete execution of the benchmark using native threads. Figure 4.b shows the execution of the benchmark when transitioning from 4 to 8 threads. Notice that, as it occurred with green threads, the creation of new threads (USER8 – USER11) takes more time (around 10 ms) than the creation of threads (USER4 – USER7) that reuse already created internal thread structures (around 1.5 ms).
(a)
(b) Figure 4. Thread Creation when running the DHPC_ThreadBench with native threads.
Figure 6. LUAppl running with native threads after setting the concurrency level.
3.3. Instrumentation overhead
The instrumentation process of JIS introduces some overhead during the execution of the application. Once the application is finished, the instrumentation library joins the per-thread buffers into a single trace (ordered in time) suitable for visualized with Paraver. This adds an extra overhead to the whole execution time of the job that does not have any impact in the trace. For the LUAppl benchmark, the overhead introduced when using green threads was less than 5% in the total execution time. The overhead when using native threads was larger (around 20%) but, from our point of view, still acceptable.
4. Conclusions and future work
In this paper we have presented the design of JIS (Java Instrumentation Suite), a set of tools designed to analyze the behavior of threaded applications running on the JVM. It uses a tracing mechanism, based on dynamic code interposition that is applied at the JVM level. It does not require access to the source code of the threaded application and does not require any modification in the JVM.
JIS allows a detailed time-analysis of the application and visualizes the thread scheduling activity done by the JVM. We have shown the usefulness of the JIS environment with a couple of simple benchmarks.
This instrumentation is in fact a first step in the design of a platform for doing research on scheduling mechanisms and policies oriented towards optimizing the execution of multithreaded Java applications on parallel servers. For instance, in this paper we have shown the performance improvement when the application informs the supporting thread layer about its concurrency level.
Acknowledgments
We acknowledge the European Center for Parallelism of Barcelona (CEPBA) for supplying the computing resources for our experiments. Special thanks are to Albert Serra who is the heart in the development of the DITools. Ministry of Education of Spain has supported this work under contracts TIC98-511 and TIC97-1445CE.
References
[BePr99] A. Bechini and C.A. Prete. Instrumentation of Concurrent Java Applications for Program Behaviour Investigation, In proceedings of 1 st^ Annual Workshop on Java for High- performance Computing, 1999 ACM International Conference on Supercomputing ICS. Rhodes (Greece), June 1999.
[JiFL98] M. Ji, E, Felton and K. Li. Performance Measurements for Multithreaded Programs. ACM SIGMETRICS/Performance, 1998.
[Jins00] W. Pauw, O. Gruber, E. Jensen, R. Konuru, N. Mitchell, G. Sevitsky, J. Vlissides and J. Yang. Jinsight: Visualizing the execution of Java programs. IBM Research Report, February 2000.
[Klem99] R. Klemm. Practical guideline for boosting java server performance. In proceedings of the ACM Java Grande Conference, St. Francisco (CA), June 1999.
[LGPC96] J. Labarta, S. Girona, V. Pillet, t. Cortés and L. Gregoris. DiP: A Parallel Program Development Environtment. In proceedings of the 2th. Int. Euro-Par Conference. Lyon (France). August 1996.
[MaCH99] J. Mathew, P. Coddington and K. Hawick. Analysis and Development of Java Grande Benchmarks. In Proceedings of the ACM Java Grande Conference, St. Francisco (CA), June
[OlAN00] J. Oliver, E. Ayguadé and N. Navarro. Towards an efficient exploitation of loop-level parallelism in Java. In Proceedings of the ACM Java Grande Conference, St. Francisco (CA), June 2000.
[SeNC00] A. Serra, N. Navarro and T. Cortés. DITools: Application-level Support for Dynamic Extension and Flexible Composition. In Proceedings of the USENIX Annual Technical Conference, June 2000.
[Voss97] A. Voss. Instrumentation and Measurement of Multithreaded Applications. PhD Thesis. Institut fuer Mathematische Maschinen und Datenverarbeitung, Universitaet Erlangen- Nuernberg, Germany. January 1997.
[WuNa98] P. Wu and P. Narayan. Multithreaded Performance Analysis with Sun WorkShop Thread Event Analyzer. Authoring and Development Tools, Sunsoft, Technical White Paper. April
[XuMN99] Z. Xu, B. Miller and O. Naim. Dynamic Instrumentation of Threaded Applications. In proceedings of the 1999 ACM SIGPLAN Symposium on Principles and Practice of Parallel Programming.
[ZaSt95] Q. Zhao and J. Stasko. Visualizing the Execution of Threads-based Parallel Programs. Technical Reprot GIT-GVU-95-01, Georgia Institute of Technology, Atlanta, GA. January
J. Guitart, J. Torres, E. Ayguadé, J. Oliver and J. Labarta, Java Instrumentation Suite: Accurate Analysis of Java Threaded Applications. 2nd Workshop on Java for High Performance Computing (part of the 14th ACM International Conference on Supercomputing ICS'00), Santa Fe, New Mexico (USA). May 7, 2000.
