Bipolar Junction Transistor (BJT)
Has three separately doped regions and two pn junctions.
A single pn junction has two modes of operation – forward bias
- reverse bias
Basic transistor principle:
The voltage between two terminals controls the current through the third terminal.
Since a transistor has two pn junctions
=> four possible bias combinations
Amplifier – forward-active operating mode/
active mode
Active mode – BE is forward biased, and
BC is reverse biased
Block diagram of an electronic system (audio system)
Power Supply
Transducer^ Input^ Amplifier Transducer^ Output
- CD Player
- Microphone
- Receiver
- Speakers
DC Low^ power signal power
High signal power
Common-emitter
Common-collector
Common-base
