ELECTRONIC DEVICES AND CIRCUIT THEORY

BIPOLAR JUNCTION

TRANSISTORS

ELECTRONIC DEVICES AND CIRCUIT THEORY

INTRODUCTION TO TRANSISTORS โ‘ Beside diodes, the most popular semiconductor devices is transistors. โ‘ Transistors are often said to be the most significant invention of the 20 th Century. โ‘ Transistors are the building blocks of the digital revolution. โ‘ Without transistors, the technological wonders you use everyday โ€“ cellphones, computers, cars โ€“ would be vastly different, if they existed at all. โ‘ Transistors are more complex and can be used in many ways. โ‘ Most important feature: can amplify signals ad act as switch. โ‘ Amplification can make weak signal strong (make sound louder and signal levels greater). โ‘ In general, they provide a function called Gain.

INTRODUCTION TO TRANSISTORS โ‘ HISTORY OF TRANSISTORS

  • In the mid 1940s, a team of scientists working for Bell Technology Labs were working to discover a device to replace the then present vacuum tube technology.
  • Vacuum tubes were the only technology available at that time to amplify signals or serve as switch devices in electronics.
  • CONS: very expensive, consume a lot of power, gave off too much heat and unreliable
  • In 1947, John Bardeen and Walter Brattain devised the first โ€œpoint contactโ€ transistor.

INTRODUCTION TO TRANSISTORS โ‘ Two primary classes of transistor:

  1. Bipolar Junction Transistors (BJTs)
  2. Field-Effect Transistors (FETs) โ‘ Difference between NPN/PNP and NMOS/PMOS is the type of semiconductor (N-type/P-type) used at each terminal.

BIPOLAR JUNCTION TRANSISTORS โ‘ BJTs are essentially two back-to-back PN junctions. โ‘ Two types:

  1. NPN 2. PNP

TRANSISTOR CONSTRUCTION โ‘ BJT is bipolar because both holes (+) and electrons (-) will take part in the current flow through the device. โ‘ N-type regions contains free electrons (negative carriers) โ‘ P-type regions contains free holes (positive carriers) โ‘ The transistor regions are: โ‘ Emitter (E) โ€“ send the carriers into the base region and then on to the collector โ‘ Base (B) โ€“ acts as control region. It can allow none, some or many carriers to flow โ‘ Collector (C) โ€“ collects the carrier

BJT MODES OF OPERATION โ‘ There are two junction in bipolar junction transistor.

**1. Emitter-Base Junction

  1. Collector-Base Junction** โ‘ Each junction can be forward or reverse biased independently. โ‘ Thus, there are different modes of operation: โ‘ Forward Active โ‘ Cut off โ‘ Saturation

OPERATION OF PNP TRANSISTOR IN ACTIVE MODE โ‘ With the external sources, VEE and VCC, connected: โ‘ The EBJ is forward biased. โ‘ The BCJ is reverse biased.

CURRENTS IN A TRANSISTOR โ‘ The minority current is called the leakage current and is given by ICO (IC with emitter terminal open)

COMMON BASE CONFIGURATION โ‘ INPUT CHARACTERISTICS โ‘ This curve shows the relationship between input current (IE) and input voltage (VBE) for three output voltage levels (VCB).

COMMON BASE CONFIGURATION โ‘ OUTPUT CHARACTERISTICS โ‘ This graph demonstrates the output current (IC) to an output voltage VCB for various levels of input current (IE).

APPROXIMATIONS โ‘ EMITTER AND COLLECTOR CURRENTS: IC โ‰… IE โ‘ BASE-EMITTER VOLTAGE: VBE = 0. 7 V (For Silicon)

ALPHA โ‘ ALPHA ( ๐œถ) is the ratio of IC to IE: โ‘ Ideally, ๐œถ = 1. โ‘ In reality, ๐œถ is between 0. 9 and 0. 998. โ‘ ALPHA ( ๐œถ) in the AC mode:
