A Simple Example in VC++

docsity.com

First Glance at Assembly Language

English: Display the sum of A times B plus C.C++: cout << (A * B + C);Assembly Language:mov eax,Amul Badd eax,Ccall WriteInt

Intel Machine Language:A1 00000000F7 25 0000000403 05 00000008E8 00500000

docsity.com

First Glance at Assembly Language

Low-level language



Each instruction performs a much lower-level taskcompared to a high-level language instruction



Most high-level language instructions need more thanone assembly instruction

One-to-one correspondence between assemblylanguage and machine language instructions



For most assembly language instructions, there is amachine language equivalent

Directly influenced by the instruction set andarchitecture of the processor (CPU)

docsity.com

Comparisons with High-level Languages

Advantages of Assembly Languages  Space-efficiency (e.g. hand-held device softwares, etc)  Time-efficiency(e.g. Real-time applications, etc )  Accessibility to system hardwares(e.g., Network interfaces, device drivers, video games, etc)

Advantages of High-level Languages  Development  Maintenance (Readability)  Portability (compiler, virtual machine) docsity.com

This Course

Why Taking the Course?

Basic Concepts of

Computer

Organization

Computer Design

System

Software

Computer OrganizationComputer Architecture

Assembler, Linker, Loader

Compiler, Operating System, …

AssemblyLanguage

docsity.com

Time Comparison

Number of calls (in millions)

Time (seconds)

Multiplication time comparison on a 2.4-GHz Pentium 4 system

C version

ASM version

docsity.com

Assembly Language

Level 4

Instruction mnemonics that have a one-to-one correspondence to machinelanguage

Calls functions written at the operatingsystem level (Level 3)

Programs are translated into machinelanguage (Level 2)

docsity.com

Operating System

Level 3

Provides services to Level 4 programs

Translated and run at the instruction setarchitecture level (Level 2)

docsity.com

Microarchitecture

Level 1

Interprets conventional machineinstructions (Level 2)

Executed by digital hardware (Level 0)

docsity.com

Digital Logic

Level 0

CPU, constructed from digital logic gates

System bus

Memory

docsity.com

Accessing Parts of Registers

Use 8-bit name, 16-bit name, or 32-bit name

Applies to EAX, EBX, ECX, and EDX

AH AL 16 bits 8 AX EAX 8 8 bits + 8 bits 32 bits docsity.com

Some specialized register uses

General-Purpose



EAX – accumulator (automatically used by divisionand multiplication)



ECX – loop counter



ESP – stack pointer (should never be used forarithmetic or data transfer)



ESI, EDI – index registers (used for high-speedmemory transfer instructions)



EBP – extended frame pointer (stack)

docsity.com

Status Flags

•^

Carry (CF)



unsigned arithmetic out of range

•^

Overflow (OF)



signed arithmetic out of range

•^

Sign (SF)



result is negative

•^

Zero (ZF)



result is zero

•^

Auxiliary Carry (AC)



carry from bit 3 to bit 4 in 8-bit operand

•^

Parity (PF)



sum of 1 bits in least-significant byte is an evennumber

docsity.com

Assembly language Statements

Three types of assembly language statements 

Instructions

Directives

Macros
