SQL Injection

Bochum

Alexander Kornbrust

10-Nov-

Table of Content

! Introduction ! Architecture ! Typical Attackers ! Tools ! SQL Basics ! SQL Injection Basics

The ivory tower solution

Classic solution:

• Clients accessing a database via application server
• No direct access to the database
• Security and business rules are enforced in the application server Security and Business Rules

The ivory tower solution in the real world

Final solution

• Complex architecture
• All types of clients are accessing the database
• Security and business rules only enforced in the first application server S&B rules We need a reporting solution Some people must connect with TOAD New project You have nice data, we will use it We just do a database link Another project Yet another project

Attacker

Attackers

Introduction – Simplified Company Environment

Prod

Dev Staging

Cloned DB

Backup

Enduser

Developer

DBA

Classification Attackers – Curious DBA or Employee

Type: Curious DBA or employee Scenario: Interested in private/sensitive information. Samples:

• Looking up for salary of colleagues, private numbers, emails, account status of politician,…
• Supporting private investigators (PI) Known incidents: Miles & More (Employee was looking up what politicians Identification: Mostly select statements, Few/No traces without audit, Difficult to spot

Classification Attackers – DBA covering it's own fault

Type: DBA covering it's own fault Scenario: Try to remove evidence about a (serious) fault. Probably it's not a good approach to ask the DBA to do the forensics Samples:

• Deleted the wrong user, killed the wrong database session, changed the wrong password… Identification: Easier because timeframe is defined, backups / archive logs disappear, Modification of audit-Table, …

Classification Attackers – Leaving Employees

Type: Leaving employees Scenario: Get as much data/information for the new job as possible. Most common attack Samples:

• Export the production database
• Get customer reports, pricelists, … Identification: Longer timeframe (1-3 month before they left the company), no/little experience in removing traces

Classification Attackers – External Hacker

Type: External Hacker Scenario: Steal interesting stuff. Samples:

• Steal data for a competitor
• Steal credit card information
• Steal Source Code
• Break in just for fun Known Incidents:
• TJX, Cardsystems, Cisco Sourcecode, … Identification: Many traces on the way into the system, attackers often lazy

10 years of SQL Injection…

Introduction

SQL Injection is still the biggest security problem in web applications. This year we can celebrate it's the 10 th anniversary of SQL Injection. Even if the problem is know since 10 years the knowledge especially for exploiting Oracle databases is poor. Most example and tutorials are only for MySQL and SQL Server. Detailed explanations for SQL Injection in web apps with Oracle databases are rare and often buggy. That's why SQL Injection in Oracle is often not exploited… The following presentation shows everything from simple statements to complex queries…

 Netsparker (Web)  Matrixay (Web)  HP Webinspect (Web)  IBM Rational AppScan (Web)  Pangolin (Web)  SQLMap (Web)  Fuzzer (PL/SQL)  Source code scanner Repscan (PL/SQL)  Source code scanner Fortify (PL/SQL) Many custom tools are used by hacker groups / security consultants

Tools to find SQL Injection

Tools / Google

[...]

Search for Oracle Error Message ORA-01756 and PHP
