Part 2  Access Control 1

Authorization

Part 2  Access Control 2

Authentication vs

Authorization

 Authentication  Who goes there?

o Restrictions on who (or what) can access system

 Authorization  Are you allowed to do that?

o Restrictions on actions of authenticated users

 Authorization is a form of access control

 Authorization enforced by

o Access Control Lists o Capabilities

Part 2  Access Control 4

Are You Allowed to Do That?

 Access control matrix has all relevant info

 But how to manage a large access control (AC) matrix?

 Could be 1000’s of users, 1000’s of resources

 Then AC matrix with 1,000,000’s of entries

 Need to check this matrix before access to any resource is allowed

 Hopelessly inefficient

Part 2  Access Control 5

Access Control Lists (ACLs)

 ACL: store access control matrix by column  Example: ACL for insurance data is in blue

rx rx r --- ---

rx rx r rw rw

rwx rwx r rw rw

rx rx rw rw rw

OS

Accounting program

Accounting data

Insurance data

Payroll data

Bob

Alice

Sam

Accounting program

Part 2  Access Control 7

ACLs vs Capabilities

Access Control List Capability

 Note that arrows point in opposite directions!  With ACLs, still need to associate users to filess

file

file

file

file

file

file

r

Alice r

Bob

Fred

w r

---

rw r r

Alice

Bob

Fred

r w rw

---

r r r

---

r

Part 2  Access Control 8

Confused Deputy

 Two resources

o Compiler and BILL file (billing info)

 Compiler can write file BILL

 Alice can invoke compiler with a debug filename

 Alice not allowed to write to BILL

 Access control matrix

x ---

rx rw

Compiler (^) BILL

Alice

Compiler

Part 2  Access Control 10

Confused Deputy

 Compiler acting for Alice is confused

 There has been a separation of authority from the purpose for which it is used

 With ACLs, difficult to avoid this problem

 With Capabilities, easier to prevent problem o Must maintain association between authority and intended purpose o Capabilities make it easy to delegate authority

Part 2  Access Control 11

ACLs vs Capabilities

 ACLs o Good when users manage their own files o Protection is data-oriented o Easy to change rights to a resource  Capabilities o Easy to delegate o Easy to add/delete users o Easier to avoid the confused deputy o More difficult to implement o The “Zen of information security”  Capabilities loved by academics o Capability Myths Demolished

Part 2  Access Control 13

Classifications and Clearances

 Classifications apply to objects

 Clearances apply to subjects

 US Department of Defense uses 4

levels of classifications/clearances

TOP SECRET

SECRET

CONFIDENTIAL

UNCLASSIFIED

Part 2  Access Control 14

Clearances and Classification

 To obtain a SECRET clearance requires a routine background check

 A TOP SECRET clearance requires extensive background check

 Practical classification problems

o Proper classification not always clear o Level of granularity to apply classifications o Aggregation  flipside of granularity

Part 2  Access Control 16

Multilevel Security (MLS)

 MLS needed when subjects/objects at different levels use same system

 MLS is a form of Access Control

 Military/government interest in MLS for many decades o Lots of funded research into MLS o Strengths and weaknesses of MLS relatively well understood (theoretical and practical) o Many possible uses of MLS outside military

Part 2  Access Control 17

MLS Applications

 Classified government/military information

 Business example: info restricted to

o Senior management only o All management o Everyone in company o General public

 Network firewall

o Keep intruders at low level to limit damage

 Confidential medical info, databases, etc.

Part 2  Access Control 19

Bell-LaPadula

 BLP security model designed to express essential requirements for MLS

 BLP deals with confidentiality

o To prevent unauthorized reading

 Recall that O is an object, S a subject

o Object O has a classification o Subject S has a clearance o Security level denoted L(O) and L(S)

Part 2  Access Control 20

Bell-LaPadula

 BLP consists of

Simple Security Condition : S can read O if and only if L(O)  L(S) *-Property ( Star Property ): S can write O if and only if L(S)  L(O)

 No read up, no write down
