Balanced Trees

CMSC 420: Lecture 7

Balance

left height(u) =

0 if LEFT(u) = NULL

1 + height(LEFT(u)) otherwise

u height (LEFT(u)) left_height (u) right_height defined analogously balance (u) := right_height (u) - left_height (u) Positive when right subtree is taller than left subtree 0 when the trees are the same height Negative when left subtree is taller than right subtree

Examples

0 +

- balance (u) := right_height (u) - left_height (u) 0 0 0 0 0 0 (^0 ) 0 +1 (^0 ) **-

-2** (^0) - NOT an AVL tree

Properties & Notes

• All leaves have balance = 0
• AVL tree with^ n^ nodes has height O(log^ n ). ⇒ (^) find will run in O(log n ) time if AVL has binary search tree property.
• insert ,^ delete^ can be implemented in O(log^ n ) time. ⇒ Good structure to implement dictionary or sorted set ADTs.

u

AVL Insert

• First, do a standard BST insert: do a find and add node where you “fall off the tree.”
• Walk insertion path back up to root, updating balances.
• If node was added to the left subtree, decrement balance by 1, otherwise increment balance by 1. Stop when node’s height doesn’t change.
• If a balance becomes +2 or -2, fix it. m n s t x **0 0

0

0 0 -**

u

The Easy Cases

n h h- -1 → 0 u n h h 0 → + Node was added to the shorter subtree Subtrees were equal, now slightly unbalanced The symmetric cases (when left subtree was shorter, e.g.) are handled the same way.

Left, Left Case

u n h i

- h h Too tall! Too short! u n h i h h Right rotation (aka clockwise rotation) 0 0 - Why does obey BST ordering?

Symmetric Left Rotation:

n i n i Left rotation (aka counterclockwise rotation) Only a constant # of pointers need to be updated for a rotation: O(1) time

The Critical Node

• Rotations leave subtree rooted at critical node balanced with unchanged height. The critical node is the node on the insertion path closest to the leaves with balance ≠ 0 **0 0

0 -** critical node

Rotations preserve height of critical subtree

n h i h h 0 0 n h i

- h (^) h - height = h + height = h + n h+ i - k h h - h+ + n h+ i k h h h+ 0 + height = h +3 height = h +3 0 Left, Left Case: Left, Right Case:

AVL Trees

• Nice Features:

   Worst case O(log _n_ ) performance guarantee

  • Fairly simple to implement

• Problem though:

   Have to maintain extra balance factor storage at each node.

• Splay trees (Sleator & Tarjan, 1985)

   remove extra storage requirement,

  • even simpler to implement,
  • heuristically move frequently accessed items up in tree
  • amortized O(log n ) performance
  • worst case single operation is Ω( n )

Splay Trees

• find (T, k):^ splay (T, k). If^ root (T) =^ k , return^ k , otherwise return not found.
• insert (T, k):^ splay (T, k). If^ root (T) =^ k , return^ duplicate! ; otherwise, make k the root and add children as in figure.
• concat (T 1 , T 2 ): Assumes all keys in T 1 are < all keys in T 2. Splay (T 1 , ∞). Now root T 1 contains the largest item, and has no right child. Make T 2 right child of T 1.
• delete (T,^ k ):^ splay (T,^ k ). If root^ r^ contains^ k ,^ concat (LEFT( r ), RIGHT( r )).

splay (T, k ): if k ∈ T, then move k to the root. Otherwise, move

either the inorder successor or predecessor of k to the root.

Without knowing how splay is implemented, we can implement our usual operations as follows: j j k
