Shivkumar Kalyanaraman
1
Experimental Networking (ECSE
Lab 1, Basic Linux and Networking
Commands
Shiv Kalyanaraman
Yong Xia (TA)
http://www.ecse.rpi.edu/Homepages/shivkuma
Aug 29, 2002
Shivkumar Kalyanaraman
2
Basic Commands
Linux commands
Networking commands and tools
Socket programming
An introduction project
Preview of the next lab
Shivkumar Kalyanaraman
4
Internet Protocols Stack
IP
TCP
UDP ATM
Satellite Ethernet
^
Packet-switched network ^
IP is the glue ^
Hour-glass architecture-^
all hosts and routers run IP
-^
IP runs over everything
^
Common IntermediateRepresentation
ICMP Cable
Shivkumar Kalyanaraman
5
TCP / UDP / IP
IP^
Unreliable, best-effort service
Connectionless: no per-packet or per-session state information insidenetwork, each IP packet is deliveredindependent of all other packets
Like post-office (USPS) mail
Shivkumar Kalyanaraman
7
TCP / UDP / IP
TCP^
Many versions: Tahoe, Reno, SACK, Vegas
Connection-oriented:
per-session
state
variables maintained at end-hosts (but not innetwork, unlike circuit-switched and virtual-circuit approaches)^
Aka
end-to-end
“connection” or
“association”
Reliably setup and tear down the end-to-end association
Shivkumar Kalyanaraman
8
TCP (contd)
^
Reliable:
uses:
^
ACKs (“sender
: receiver correctly got this packet”),
^
checksum (“receiver
: is this packet is correct or
wrong?”) and window (multiple packets in flight: pipelined) ^
Byte-stream:
no application-packet boundary like UDP
^
Congestion control:
reduce demand during overload,
to ensure stable statistical multiplexing of the network
Shivkumar Kalyanaraman
10
A Router Model
Input and output queues (buffers)
Switch fabric (forwarding / routing)
Scheduler
queue 1 queue 2^ …… queue k
Classifier
buffer management
I^1 I^2 I^ m
O^1 O^2 On
router
Shivkumar Kalyanaraman
11
Basic Networking Commands
^
ping – check if machine is alive ^
ifconfig – interface (ip addr / mask) configuration ^
arp – link / network layer address mapping ^
netstat – status info of network configuration ^
telnet – remote terminal ^
ftp – file transfer tool ^
route – set static route of a machine ^
traceroute – gather route information ^
tcpdump – dump packet header ^
nslookup – resolve DNS name of target hostname Key : What can you infer
about the network or end-to-
end properties
with these commands?
Shivkumar Kalyanaraman
13
Some Miscellaneous Hints
^
To check default gateway/static routes without beingdependent on DNS:
netstat -rn
^
If you get an error saying command not found, set thepath:
export PATH=$PATH:
^
Common directories where programs are found:
/usr/sbin, /sbin, /usr/bin, /usr/local/bin
^
If you have root and want to start/stop/restart thenetworking modules : /etc/init.d/network start /etc/init.d/network stop /etc/init.d/network restart
Shivkumar Kalyanaraman
14
Project: Measuring RTT
^
Write program to measure round-trip time between two endhost on the Internet;^
Refer to ping: write a simple wrapper program.. ^
Propose a model for RTT prediction, i.e., give a sequenceof RTT measures, estimate the next RTT value.^
Measure several values of RTT. What can you sayabout the samples? If they are variable, what can youdo to reduce the variability of the RTT estimate? Time series model
