Chapter 2 Basic Physics of Semiconductors
2.1 Semiconductor materials and their properties
2.2 PN-junction diodes
2.3 Reverse Breakdown
Charge Carriers in Semiconductor
To understand PN junction’s IV characteristics, it is
important to understand charge carriers’ behavior in solids,
how to modify carrier densities, and different mechanisms
of charge flow.
Periodic Table
This abridged table contains elements with three to five
valence electrons, with Si being the most important.
Electron-Hole Pair Interaction
With free electrons breaking off covalent bonds, holes are
generated.
Holes can be filled by absorbing other free electrons, so
effectively there is a flow of charge carriers.
Free Electron Density at a Given Temperature
Eg , or bandgap energy determines how much effort is
needed to break off an electron from its covalent bond.
There exists an exponential relationship between the free-
electron density and bandgap energy.
0 15 3
0 10 3
15 3 / 2 3
( 600 ) 1. 54 10 /
( 300 ) 1. 08 10 /
/ 2
n T K electrons cm
n T K electrons cm
electrons cm kT
E n T
i
i
g i
Doping (P type)
If Si is doped with B (boron), then it has more holes, or
becomes type P.
Summary of Charge Carriers
First Charge Transportation Mechanism: Drift
The process in which charge particles move because of an
electric field is called drift.
Charge particles will move at a velocity that is proportional
to the electric field.
v E
v E
e n
h p
Current Flow: General Case
Electric current is calculated as the amount of charge in v
meters that passes thru a cross-section if the charge travel
with a velocity of v m/s.
I v W h n q
Velocity Saturation
A topic treated in more advanced courses is velocity
saturation.
In reality, velocity does not increase linearly with electric
field. It will eventually saturate to a critical value.
v
v
b
v
bE
sat
sat
0
0
0
0
Second Charge Transportation Mechanism:
Diffusion
Charge particles move from a region of high concentration
to a region of low concentration. It is analogous to an every day example of an ink droplet in water.
Example: Linear vs. Nonlinear Charge Density
Profile
Linear charge density profile means constant diffusion
current, whereas nonlinear charge density profile means
varying diffusion current.
qD dx
dn J (^) n qDn n
d d
n n L
x
qD N
dx
dn J qD
exp
Einstein's Relation
While the underlying physics behind drift and diffusion
currents are totally different, Einstein’s relation provides a
mysterious link between the two.
q
D kT
