COMPUTER
NETWORKS
Lecture-
Review Lecture 26
Subnet and Classless Addressing
Subnet/Address Mask
CIDR Notation
Special IP Addresses
Protocol Addresses and Packet
Delivery
Protocol address are abstractions provided by software.
Physical network hardware does not know how to locate a computer from it protocol address.
The protocol address of the next hop must be translated to an equivalent hardware address before a packet can be sent.
Address Resolution
Mapping between a protocol address and a
hardware address is called Address Resolution.
A host or router uses address resolution
when it needs to send a packet to another computer on the same physical network.
A computer never resolves the address of
a computer that attaches to a remote network. Docsity.com
Address Resolution
A resolves protocol address for B for protocol messages from an application on A sent to an application on B.
A does not resolve a protocol address for F.
Through the internet layer, A delivers to F by routing through R 1 and R 2.
A resolves R 1 hardware address.
Network layer on A passes packet containing destination protocol address F for delivery to R1.
Address Resolution Techniques
Address resolution algorithms can be
grouped into three basic categories:
Table lookup
Closed-form computation
Message Exchange
Address Resolution Techniques
Message Exchange
Computers exchange messages
across a network to resolve an
address.
One computer sends a message that
requests an address binding
(translation) and another computer
sends a reply that contains the
requested information.
Address Resolution with Table
Lookup
Resolution requires a data structure
that contains information about address binding.
A separate address binding table is used
for each physical network.
The chief advantage of the table look up
approach is generality, a table can store the address bindings for an arbitrary set of computers. Docsity.com
Address Resolution with
Table Lookup
Address Resolution with Table
Lookup
Two standard implementations to
improve computational efficiency:
Hashing
Direct Indexing
Address Resolution with Table
Lookup
Direct Indexing
Less generally known technique.
Possible only in cases where protocols
addresses are assigned from a
compact range.
Address Resolution with Table
Lookup
Address Resolution with
Closed-Form Computation
When a computer connects to a network
that uses configurable address, the local
network administrator must choose a
hardware address as well as an IP address.
The two values can be chosen to make
address resolution trivial. Docsity.com
Address Resolution with
Closed-Form Computation
Example:- Suppose a configurable network
number: 220.123.5.0 / 24
The IP address of first host = 220.123.5.
Hardware Address = 1
The IP address of second host = 220.123.5.
Hardware Address = 2
