Security

Nelli Gordon and Sean Vakili May 10th^2011

What is Bluetooth?

 Bluetooth is an open standard for short-range radio

frequency (RF) communication. Bluetooth technology is

used primarily to establish wireless personal area

networks (WPAN), commonly referred to as ad hoc or

peer-to-peer (P2P) networks.

 Bluetooth is a low-cost, low-power technology that

provides a mechanism for creating small wireless

networks on an ad hoc basis, known as piconets.

Origin of the name

Bluetooth was named after a late 900s king, Harald

Blåtand (Harald Bluetooth) King of Denmark and Norway.

He is known for his unification of previously warring tribes

from Denmark (including Scania, present-day Sweden,

where the Bluetooth technology was invented), and

Norway. Bluetooth likewise was intended to unify different

technologies, such as computers and mobile phones.

History

 The Bluetooth specification was developed in 1994 by

Jaap Haartsen and Sven Mattisson, who were working

for Ericsson in Lund, Sweden. The specification is based

on frequency-hopping spread spectrum technology.

 The specifications were formalized by the Bluetooth

Special Interest Group (SIG). The SIG was formally

announced on May 20, 1998. Today it has a membership

of over 14,000 companies worldwide. It was established

by Ericsson, IBM, Intel, Toshiba and Nokia, and later

joined by many other companies.

More Bluetooth devices

Why do we need Bluetooth (key benefits of Bluetooth technology are):  Cable replacement. Bluetooth technology replaces a variety of cables, such as those traditionally used for peripheral devices (e.g., mouse and keyboard connections), printers, and wireless headsets and ear buds that interface with personal computers (PC) or mobile telephones.  Ease of file sharing. A Bluetooth-enabled device can form a piconet to support file sharing capabilities with other Bluetooth devices, such as laptops.  Wireless synchronization. Bluetooth provides automatic synchronization between Bluetooth- enabled devices. For example, Bluetooth allows synchronization of contact information contained in electronic address books and calendars.  Internet connectivity. A Bluetooth device with Internet connectivity can share that access with other Bluetooth devices. For example, a laptop can use a Bluetooth connection to have a mobile phone establish a dial-up connection, so that the laptop can access the Internet through the phone.

Bluetooth Device Classes of Power Management Type Power Power Level Designed Operating Range Sample Devices Class 1 High 100 mW (20 dBm) Up to 91 meters (300 feet) AC-powered devices (USB dongles, access points) Class 2 Medium 2.5 mW (4 dBm) Up to 9 meters (30 feet) Battery- powered devices (mobile devices, Bluetooth adapters, smart card readers) Class 3 Low 1 mW (0 dBm) Up to 1 meter ( feet) Battery- powered devices (Bluetooth adapters)

Bluetooth Spy Phone Spy Software

 http://www.youtube.com/watch?v=9qMdiguTluQ

Confidentiality In addition to the Security Modes, Bluetooth provides a separate confidentiality service to thwart eavesdropping attempts on the payloads of the packets exchanged between Bluetooth devices. Bluetooth has three Encryption Modes, but only two of them actually provide confidentiality. The modes are as follows:  Encryption Mode 1 —No encryption is performed on any traffic.!  Encryption Mode 2 —Individually addressed traffic is encrypted using encryption keys based on individual link keys; broadcast traffic is not encrypted.!  Encryption Mode 3 —All traffic is encrypted using an encryption key based on the master link key. Encryption Modes 2 and 3 use the same encryption mechanism.

Trust Levels, Service Levels, and Authorization In addition to the four security modes, Bluetooth allows two levels of trust and three levels of service security. The two Bluetooth levels of trust are trusted and untrusted. A trusted device has a fixed relationship with another device and has full access to all services. An untrusted device does not have an established relationship with another Bluetooth device, which results in the untrusted device receiving restricted access to services.  Service Level 1— Requires authorization and authentication. Automatic access is granted only to trusted devices; untrusted devices need manual authorization.  Service Level 2— Requires authentication only; authorization is not necessary. Access to an application is allowed only after an authentication procedure.  Service Level 3— Open to all devices, with no authentication required. Access is granted automatically.

Threats Bluetooth technology and associated devices are susceptible to general wireless networking threats, such as: Denial of service attacks Eavesdropping Man-in-the-middle attacks Message modification Resource misappropriation They are also threatened by more specific Bluetooth-related attacks that target known vulnerabilities in Bluetooth implementations and specifications.

Blue Threats

 Bluesnarfing - Forces a connection to a Bluetooth

device, allowing access to data stored on the device and

even the device s international mobile equipment

identity (IMEI)

 Bluejacking - Initiated by an attacker sending

unsolicited messages to a user of a Bluetooth-enabled

device to entice the user to respond. Resembles spam

and phishing attacks conducted against email users.

 Bluebugging - Security flaw in the firmware allows

attacker to use the commands of the device without

informing the user

Risk Mitigation/Countermeasures

 Security measures  organizational security policy  aware of responsibilities  pre-cautionary measures  inventory list of devices and addresses

Risk Mitigation/Countermeasures

(continued)

 Units set to lowest necessary power level to minimize

range

 Complex pin codes

 Undiscoverable by default

 Maximum key size encryption

 Mutual authentication

 Service-level security mode 3 (most secure)

 Install software patches & upgrades
