Overview of Last Lecture!
- Boolean Functions!
- Examples!
- Boolean Functions Practical examples!
Today’s Lecture Outline!
- Gate Implementation!
- Minimization of function!
- Algebraic Manipulations!
- Complement of a Boolean function!
Gate Implementation (Examples)! A B C F 0 0 0 0 0 0 1 0 0 1 0 0 0 1 1 0 1 0 0 0 1 0 1 1 1 1 0 1 1 1 1 1
Gate Implementation (Examples)!
A B F 0 0 1 0 1 0 1 0 0 1 1 0
The following is an example of a non-minimized function:! F 2 = x’y’z + x’yz + xy’! Minimization of the F 2 ! !
Minimization of the F
!
The function can be minimized as follows: x’y’z + x’yz + xy’ = = x’z · (y’ + y) + xy’ by postulate: 4(a) = x’z · 1 + xy’ 5(a) = x’z + xy’ 2(b)
Algebraic Manipulation!
- By reducing the number of terms, the number of literals (single variable) or both in a Boolean function, it is possible to obtain a simpler circuit, as each term requires a gate and each variable within the term designates an input to the gate! ! F 1 = x’y’z + x’yz + xy’ contains 3 terms and 8 literals! F 2 = x’z + xy’ contains 2 terms and 4 literals.!
Example Manipulations!
- The following are some example
manipulations:!
- x(x’ + y) = ?! " x(x’ + y) = xx’ + xy = 0 + xy = xy! !
- x + x’y = ?! " x + x’y = (x + x’)(x + y) = 1(x + y) = x + y!
- (x + y)(x + y’) = ?! (x + y)(x + y’) = x + xy + xy’ + yy’ = x(1 + y + y’) = x!
- xy + x’z + yz = ?! " " " "= xy + x’z + yz(x + x’)! " " " "= xy + x’z + xyz + x’yz! " " " "= xy(1 + z) + x’z(1 + y)! " " " "= xy + x’z!
- (x + y)(x’ + z)(y + z) = ?! " " " " "= (x + y)(x’ + z)!
Complement of a Function (Example)!
If F 1 = A+B+C Then F 1 ’ =(A+B+C)' = (A+X)’ let B+C = X = A'X' by DeMorgan's = A'(B+C)' = A'(B'C') by DeMorgan's = A'B'C' associative
Complement of a Function (More Examples)!
(x'yz' + x'y'z)' = (x'yz')' (x‘y'z)' = (x+y'+z) (x+y+z') [x(y'z'+yz)]' = x' + ( y'z'+yz)' = x' + (y'z')' (yz)' = x' + (y+z) (y'+z') A simpler procedure take the dual of the function (interchanging AND and OR operators and 1’s and 0’s) and complement each literal. {DeMorgan’s Theorem}! x'yz' + x'y'z! "The dual of function is (x'+y+z') (x'+y'+z)! "Complement of each literal: (x+y'+z)(x+y+z')!
