Module 1

C++ Fundamentals

Table of Contents

CRITICAL SKILL 1.1: A Brief History of C++ .................................................................................................... 2

CRITICAL SKILL 1.2: How C++ Relates to Java and C# .................................................................................... 5

CRITICAL SKILL 1.3: Object-Oriented Programming ...................................................................................... 7

CRITICAL SKILL 1.4: A First Simple Program ................................................................................................ 10

CRITICAL SKILL 1.5: A Second Simple Program ........................................................................................... 15

CRITICAL SKILL 1.6: Using an Operator ....................................................................................................... 17

CRITICAL SKILL 1.7: Reading Input from the Keyboard ............................................................................... 19

Project 1-1 Converting Feet to Meters ....................................................................................................... 24

CRITICAL SKILL 1.8: Two Control Statements .............................................................................................. 26

CRITICAL SKILL 1.9: Using Blocks of Code ................................................................................................... 30

Project 1-2 Generating a Table of Feet to Meter Conversions ................................................................... 33

CRITICAL SKILL 1.10: Introducing Functions ................................................................................................ 35

CRITICAL SKILL 1.11: The C++ Keywords ..................................................................................................... 38

CRITICAL SKILL 1.12: Identifiers................................................................................................................... 39

If there is one language that defines the essence of programming today, it is C++. It is the preeminent language for the development of high-performance software. Its syntax has become the standard for professional programming languages, and its design philosophy reverberates throughout computing.

with local variables, and other improvements. Using structured languages, it became possible to write moderately large programs.

Although there were other structured languages at the time, such as Pascal, C was the first to successfully combine power, elegance, and expressiveness. Its terse, yet easy-to-use syntax coupled with its philosophy that the programmer (not the language) was in charge quickly won many converts. It can be a bit hard to understand from today’s perspective, but C was a breath of fresh air that programmers had long awaited. As a result, C became the most widely used structured programming language of the 1980s.

The Need for C++

Given the preceding discussion, you might be wondering why C++ was invented. Since C was a successful computer programming language, why was there a need for something else? The answer is complexity. Throughout the history of programming, the increasing complexity of programs has driven the need for better ways to manage that complexity. C++ is a response to that need. To better understand the correlation between increasing program complexity and computer language development, consider the following.

Approaches to programming have changed dramatically since the invention of the computer. For example, when computers were first invented, programming was done by using the computer’s front panel to toggle in the binary machine instructions. As long as programs were just a few hundred instructions long, this approach worked. As programs grew, assembly language was invented so that programmers could deal with larger, increasingly complex programs by using symbolic representations of the machine instructions. As programs continued to grow, high-level languages were developed to give programmers more tools with which to handle the complexity.

The first widely used computer language was, of course, FORTRAN. While FORTRAN was a very impressive first step, it is hardly a language that encourages clear, easy-to-understand programs. The 1960s gave birth to structured programming, which is the method of programming encouraged by languages such as C. With structured languages it was, for the first time, possible to write moderately complex programs fairly easily. However, even with structured programming methods, once a project reaches a certain size, its complexity exceeds what a programmer can manage. By the late 1970s, many projects were near or at this point.

In response to this problem, a new way to program began to emerge: object-oriented programming (OOP). Using OOP, a programmer could handle larger, more complex programs. The trouble was that C did not support object-oriented programming. The desire for an object-oriented version of C ultimately led to the creation of C++.

In the final analysis, although C is one of the most liked and widely used professional programming languages in the world, there comes a time when its ability to handle complexity is exceeded. Once a program reaches a certain size, it becomes so complex that it is difficult to grasp as a totality. The

purpose of C++ is to allow this barrier to be broken and to help the programmer comprehend and manage larger, more complex programs.

C++ Is Born

C++ was invented by Bjarne Stroustrup in 1979, at Bell Laboratories in Murray Hill, New Jersey. He initially called the new language “C with Classes.” However, in 1983 the name was changed to C++.

Stroustrup built C++ on the foundation of C, including all of C’s features, attributes, and benefits. He also adhered to C’s underlying philosophy that the programmer, not the language, is in charge. At this point, it is critical to understand that Stroustrup did not create an entirely new programming language. Instead, he enhanced an already highly successful language.

Most of the features that Stroustrup added to C were designed to support object-oriented programming. In essence, C++ is the object-oriented version of C. By building upon the foundation of C, Stroustrup provided a smooth migration path to OOP. Instead of having to learn an entirely new language, a C programmer needed to learn only a few new features before reaping the benefits of the object-oriented methodology.

When creating C++, Stroustrup knew that it was important to maintain the original spirit of C, including its efficiency, flexibility, and philosophy, while at the same time adding support for object-oriented programming. Happily, his goal was accomplished. C++ still provides the programmer with the freedom and control of C, coupled with the power of objects.

Although C++ was initially designed to aid in the management of very large programs, it is in no way limited to this use. In fact, the object-oriented attributes of C++ can be effectively applied to virtually any programming task. It is not uncommon to see C++ used for projects such as editors, databases, personal file systems, networking utilities, and communication programs. Because C++ shares C’s efficiency, much high-performance systems software is constructed using C++. Also, C++ is frequently the language of choice for Windows programming.

The Evolution of C++

Since C++ was first invented, it has undergone three major revisions, with each revision adding to and altering the language. The first revision was in 1985 and the second in 1990. The third occurred during the C++ standardization process. Several years ago, work began on a standard for C++. Toward that end, a joint ANSI (American National Standards Institute) and ISO (International Standards Organization) standardization committee was formed. The first draft of the proposed standard was created on January 25, 1994. In that draft, the ANSI/ISO C++ committee (of which I was a member) kept the features first defined by Stroustrup and added some new ones. But, in general, this initial draft reflected the state of C++ at the time.

Soon after the completion of the first draft of the C++ standard, an event occurred that caused the standard to be greatly expanded: the creation of the Standard Template Library (STL) by Alexander Stepanov. The STL is a set of generic routines that you can use to manipulate data. It is both powerful

that is directly executed by the CPU. Thus, it is tied to a specific CPU and operating system. If you want to run a C++ program on a different system, you need to recompile it into machine code specifically targeted for that environment. To create a C++ program that would run in a variety of environments, several different executable versions of the program are needed.

Java and C# achieve portability by compiling a program into a pseudocode, intermediate language. In the case of Java, this intermediate language is called bytecode. For C#, it is called Microsoft Intermediate Language (MSIL). In both cases, this pseudocode is executed by a runtime system. For Java, this runtime system is called the Java Virtual Machine (JVM). For C#, it is the Common Language Runtime (CLR). Therefore, a Java program can run in any environment for which a JVM is available, and a C# program can run in any environment in which the CLR is implemented.

Since the Java and C# runtime systems stand between a program and the CPU, Java and C# programs incur an overhead that is not present in the execution of a C++ program. This is why C++ programs usually run faster than the equivalent programs written in Java or C#.

Java and C# were developed in response to the unique programming needs of the online environment of the Internet. (C# was also designed to simplify the creation of software components.) The Internet is connected to many different types of CPUs and operating systems. Thus, the ability to produce cross- platform, portable programs became an overriding concern.

The first language to address this need was Java. Using Java, it is possible to write a program that runs in a wide variety of environments. Thus, a Java program can move about freely on the Internet. However, the price you pay for portability is efficiency, and Java programs execute more slowly than do C++ programs. The same is true for C#. In the final analysis, if you want to create high-performance software, use C++. If you need to create highly portable software, use Java or C#.

One final point: Remember that C++, Java, and C# are designed to solve different sets of problems. It is not an issue of which language is best in and of itself. Rather, it is a question of which language is right for the job at hand.

1. From what language is C++ derived?
2. What was the main factor that drove the creation of C++?
3. C++ is the parent of Java and C#. True or False?

Answer Key:

1. C++ is derived from C.
2. Increasing program complexity was the main factor that drove the creation of C++.
3. True.

CRITICAL SKILL 1.3: Object-Oriented Programming

Central to C++ is object-oriented programming (OOP). As just explained, OOP was the impetus for the creation of C++. Because of this, it is useful to understand OOP’s basic principles before you write even a simple C++ program.

Object-oriented programming took the best ideas of structured programming and combined them with several new concepts. The result was a different and better way of organizing a program. In the most general sense, a program can be organized in one of two ways: around its code (what is happening) or around its data (who is being affected). Using only structured programming techniques, programs are typically organized around code. This approach can be thought of as “code acting on data.”

Object-oriented programs work the other way around. They are organized around data, with the key principle being “data controlling access to code.” In an object-oriented language, you define the data and the routines that are permitted to act on that data. Thus, a data type defines precisely what sort of operations can be applied to that data.

To support the principles of object-oriented programming, all OOP languages, including C++, have three traits in common: encapsulation, polymorphism, and inheritance. Let’s examine each.

Encapsulation

Encapsulation is a programming mechanism that binds together code and the data it manipulates, and that keeps both safe from outside interference and misuse. In an object-oriented language, code and data can be bound together in such a way that a self-contained black box is created. Within the box are all necessary data and code. When code and data are linked together in this fashion, an object is created. In other words, an object is the device that supports encapsulation.

Ask the Expert

Q: I have heard the term method applied to a subroutine. Is a method the same as a function?

A: In general, the answer is yes. The term method was popularized by Java. What a C++ programmer

calls a function, a Java programmer calls a method. C# programmers also use the term method. Because it is becoming so widely used, sometimes the term method is also used when referring to a C++

Inheritance

Inheritance is the process by which one object can acquire the properties of another object. This is important because it supports the concept of hierarchical classification. If you think about it, most knowledge is made manageable by hierarchical (that is, top-down) classifications. For example, a Red Delicious apple is part of the classification apple, which in turn is part of the fruit class, which is under the larger class food. That is, the food class possesses certain qualities (edible, nutritious, and so on) which also, logically, apply to its subclass, fruit. In addition to these qualities, the fruit class has specific characteristics (juicy, sweet, and so on) that distinguish it from other food. The apple class defines those qualities specific to an apple (grows on trees, not tropical, and so on). A Red Delicious apple would, in turn, inherit all the qualities of all preceding classes and would define only those qualities that make it unique.

Without the use of hierarchies, each object would have to explicitly define all of its characteristics. Using inheritance, an object need only define those qualities that make it unique within its class. It can inherit its general attributes from its parent. Thus, it is the inheritance mechanism that makes it possible for one object to be a specific instance of a more general case.

1. Name the principles of OOP.
2. What is the basic unit of encapsulation in C++?
3. What is the commonly used term for a subroutine in C++?

Answer Key:

1. Encapsulation, polymorphism, and inheritance are the principles of OOP.
2. The class is the basic unit of encapsulation in C++.
3. Function is the commonly used term for a subroutine in C++.

Ask the Expert

Q: You state that object-oriented programming (OOP) is an effective way to manage large programs.

However, it seems that OOP might add substantial overhead to relatively small ones. As it relates to C++,

is this true?

A: No. A key point to understand about C++ is that it allows you to write object-oriented programs, but

does not require you to do so. This is one of the important differences between C++ and Java/C#, which employ a strict object-model in which every program is, to at least a small extent, object oriented. C++ gives you the option. Furthermore, for the most part, the object-oriented features of C++ are transparent at runtime, so little (if any) overhead is incurred.

CRITICAL SKILL 1.4: A First Simple Program

Now it is time to begin programming. Let’s start by compiling and running the short sample C++ program shown here:

/* This is a simple C++ program. Call this file Sample.cpp. */

#include using namespace std;

// A C++ program begins at main(). int main() { cout << "C++ is power programming.";

return 0; }

You will follow these three steps:

1. Enter the program.
2. Compile the program.
3. Run the program.

Before beginning, let’s review two terms: source code and object code. Source code is the human- readable form of the program. It is stored in a text file. Object code is the executable form of the program created by the compiler.

When run, the program displays the following output:

C++ is power programming.

If you are using an Integrated Development Environment, then you can run a program by selecting Run from a menu. Consult the instructions for your specific compiler. For the programs in this book, it is usually easier to compile and run from the command line.

One last point: The programs in this book are console based, not window based. That is, they run in a Command Prompt session. C++ is completely at home with Windows programming. Indeed, it is the most commonly used language for Windows development. However, none of the programs in this book use the Windows Graphic User Interface (GUI). The reason for this is easy to understand: Windows programs are, by their nature, large and complex. The overhead required to create even a minimal Windows skeletal program is 50 to 70 lines of code. To write Windows programs that demonstrate the features of C++ would require hundreds of lines of code each. In contrast, console-based programs are much shorter and are the type of programs normally used to teach programming. Once you have mastered C++, you will be able to apply your knowledge to Windows programming with no trouble.

The First Sample Program Line by Line

Although Sample.cpp is quite short, it includes several key features that are common to all C++ programs. Let’s closely examine each part of the program. The program begins with the lines

/*

This is a simple C++ program.

Call this file Sample.cpp.

*/

This is a comment. Like most other programming languages, C++ lets you enter a remark into a program’s source code. The contents of a comment are ignored by the compiler. The purpose of a comment is to describe or explain the operation of a program to anyone reading its source code. In the case of this comment, it identifies the program. In more complex programs, you will use comments to help explain what each feature of the program is for and how it goes about doing its work. In other words, you can use comments to provide a “play-by-play” description of what your program does.

In C++, there are two types of comments. The one you’ve just seen is called a multiline comment. This type of comment begins with a /* (a slash followed by an asterisk). It ends only when a */ is encountered. Anything between these two comment symbols is completely ignored by the compiler. Multiline comments may be one or more lines long. The second type of comment (single-line) is found a little further on in the program and will be discussed shortly.

The next line of code looks like this:

#include

The C++ language defines several headers, which contain information that is either necessary or useful to your program. This program requires the header iostream, which supports the C++ I/O system. This header is provided with your compiler. A header is included in your program using the #include directive. Later in this book, you will learn more about headers and why they are important.

The next line in the program is

using namespace std;

This tells the compiler to use the std namespace. Namespaces are a relatively recent addition to C++. Although namespaces are discussed in detail later in this book, here is a brief description. A namespace creates a declarative region in which various program elements can be placed. Elements declared in one namespace are separate from elements declared in another. Namespaces help in the organization of large programs. The using statement informs the compiler that you want to use the std namespace. This is the namespace in which the entire Standard C++ library is declared. By using the std namespace, you simplify access to the standard library. (Since namespaces are relatively new, an older compiler may not support them. If you are using an older compiler, see Appendix B, which describes an easy work- around.)

The next line in the program is

// A C++ program begins at main().

This line shows you the second type of comment available in C++: the single-line comment. Single-line comments begin with // and stop at the end of the line. Typically, C++ programmers use multiline comments when writing larger, more detailed commentaries, and single-line comments when short remarks are needed. This is, of course, a matter of personal style.

The next line, as the preceding comment indicates, is where program execution begins.

int main()

All C++ programs are composed of one or more functions. As explained earlier, a function is a subroutine. Every C++ function must have a name, and the only function that any C++ program must include is the one shown here, called main( ). The main( ) function is where program execution begins and (most commonly) ends. (Technically speaking, a C++ program begins with a call to main( ) and, in most cases, ends when main( ) returns.) The opening curly brace on the line that follows main( ) marks the start of the main( ) function code. The int that precedes main( ) specifies the type of data returned by main( ). As you will learn, C++ supports several built-in data types, and int is one of them. It stands for integer.

The next line in the program is

cout << "C++ is power programming.";

programmer, then decide whether the suspicion is justified.

Warnings are also used to report such things as inefficient constructs or the use of obsolete features. Generally, you can select the specific type of warnings that you want to see. The programs in this book are in compliance with Standard C++, and when entered correctly, they will not generate any troublesome warning messages.

For the examples in this book, you will want to use your compiler’s default (or “normal”) error reporting. However, you should examine your compiler’s documentation to see what options you have at your disposal. Many compilers have sophisticated features that can help you spot subtle errors before they become big problems. Understanding your compiler’s error reporting system is worth your time and effort.

1. Where does a C++ program begin execution?
2. What is cout?
3. What does #include do?

Answer Key:

1. A C++ program begins execution with main( ).
2. cout is a predefined identifier that is linked to console output.
3. It includes the header , which supports I/O.

CRITICAL SKILL 1.5: A Second Simple Program

Perhaps no other construct is as fundamental to programming as the variable. A variable is a named memory location that can be assigned a value. Further, the value of a variable can be changed during the execution of a program. That is, the content of a variable is changeable, not fixed.

The following program creates a variable called length, gives it the value 7, and then displays the message “The length is 7” on the screen.

As mentioned earlier, the names of C++ programs are arbitrary. Thus, when you enter this program, select a filename to your liking. For example, you could give this program the name VarDemo.cpp.

This program introduces two new concepts. First, the statement

int length; // this declares a variable

declares a variable called length of type integer. In C++, all variables must be declared before they are used. Further, the type of values that the variable can hold must also be specified. This is called the type of the variable. In this case, length may hold integer values. These are whole number values whose range will be at least –32,768 through 32,767. In C++, to declare a variable to be of type integer, precede its name with the keyword int. Later, you will see that C++ supports a wide variety of built-in variable types. (You can create your own data types, too.)

The second new feature is found in the next line of code:

length = 7; // this assigns 7 to length

As the comment suggests, this assigns the value 7 to length. In C++, the assignment operator is the single equal sign. It copies the value on its right side into the variable on its left. After the assignment, the variable length will contain the number 7.

The following statement displays the value of length:

cout << length; // This displays 7

In general, if you want to display the value of a variable, simply put it on the right side of << in a cout statement. In this specific case, because length contains the number 7, it is this number that is displayed

In this program, there is actually no need for the variable area. For example, the program can be rewritten like this:

In this version, the area is computed in the cout statement by multiplying length by width. The result is then output to the screen.

One more point before we move on: It is possible to declare two or more variables using the same declaration statement. Just separate their names by commas. For example, length, width, and area could have been declared like this:

int length, width, area; // all declared using one statement

Declaring two or more variables in a single statement is very common in professionally written C++ code.

1. Must a variable be declared before it is used?
2. Show how to assign the variable min the value 0.
3. Can more than one variable be declared in a single declaration statement?

Answer Key:

1. Yes, in C++ variables must be declared before they are used.
2. min = 0;
3. Yes, two or more variables can be declared in a single declaration statement.

CRITICAL SKILL 1.7: Reading Input from the Keyboard

The preceding examples have operated on data explicitly specified in the program. For example, the area program just shown computes the area of a rectangle that is 7 by 5, and these dimensions are part of the program itself. Of course, the calculation of a rectangle’s area is the same no matter what its size, so the program would be much more useful if it would prompt the user for the dimensions of the rectangle, allowing the user to enter them using the keyboard.

To enable the user to enter data into a program from the keyboard, you will use the >> operator. This is the C++ input operator. To read from the keyboard, use this general form

cin >> var;

Here, cin is another predefined identifier. It stands for console input and is automatically supplied by C++. By default, cin is linked to the keyboard, although it can be redirected to other devices. The variable that receives input is specified by var.

Here is the area program rewritten to allow the user to enter the dimensions of the rectangle:
