THE CEMENT

MANUFACTURING

PROCESS

1. RAW GRINDING : The raw materials are very finely ground in order to produce the raw mix.
   1. RAW GRINDING

Raw grinding and burning

2. BURNING
3. BURNING : The raw mix is preheated before it goes into the kiln, which is heated by a flame that can be as hot as 2000 °C. The raw mix burns at 1500 °C producing clinker which, when it leaves the kiln, is rapidly cooled with air fans. So, the raw mix is burnt to produce clinker : the basic material needed to make cement. conveyor Raw mix kiln cooling preheating clinker storage at the plant Raw mill

1.GRINDING : The clinker and the gypsum are very finely ground giving a “pure cement”. Other secondary additives and cementitious materials can also be added to make a blended cement.

1. GRINDING

Grinding, storage, packing, dispatch

2. STORAGE, PACKING, DISPATCH
3. STORAGE, PACKING, DISPATCH :The cement is stored in silos before being dispatched either in bulk or in bags to its final destination. clinker storage Gypsum and the secondary additives are added to the clinker. silos dispatch bags Finish grinding
