Communication Networks
Foundations
Data Communications and Computer Networks: A Business User's Approach, Eighth Mnoneleli Mno Nogwina
Introduction
Who today has not used a computer network? What computer network have you used? Data Communications and Computer Networks: A Business User's Approach, Eighth
Network Types
- (^) Network definitions
- (^) Personal Area Network (PAN)
- (^) Local Area Network (LAN)
- (^) Campus Area Network (CAN)
- (^) Metropolitan Area Network (MAN)
- (^) Wide Area Network (WAN)
- (^) Internet, Intranet, Extranet Data Communications and Computer Networks: A Business User's Approach, Eighth
Network Components
- (^) Node/host / station - any device that can communicate on the network
- (^) Media - cable or wireless
- (^) Intranetwork devices - facilitate connections between nodes (switch)
- (^) Segment - linked together by an intranetwork device
- (^) Backbone - fast link between other segments
- (^) Internetwork devices โ joins separate networks (router)
- (^) Subnets - logical grouping of hosts within a single network Data Communications and Computer Networks: A Business User's Approach, Eighth
Protocols
- (^) Rules for exchanging data
- (^) Addressing โ where data should go
- (^) Encapsulation โ how data should be packaged for transmission - (^) Header - (^) Payload Data Communications and Computer Networks: A Business User's Approach, Eighth
Clients and Servers
- (^) Clients or workstations are computers on the network that allow users to request shared resources on servers.
- (^) A server provides shared resources on the network and allows clients to access this information Data Communications and Computer Networks: A Business User's Approach, Eighth
Clients and Servers
- (^) Advantages of server-based networks
- (^) Performance
- (^) Security
- (^) Administration
- (^) Scalability
- (^) Disadvantages of server-based networks - (^) High cost - (^) Complexity Data Communications and Computer Networks: A Business User's Approach, Eighth
Peer-to-Peer Networks
- (^) Machines can be both server and client
- (^) Less reliable and more difficult to secure
- (^) Easy and cheap to set up but difficult to manage and expand Data Communications and Computer Networks: A Business User's Approach, Eighth
Network Topologies
- (^) Point-to-point
- (^) One-to-one link
- (^) Physically cabled or switched
- (^) Point-to-multipoint
- (^) One-to-many
- (^) Topology for legacy network products
- (^) On modern networks, saves bandwidth when broadcasting the same content to multiple nodes Data Communications and Computer Networks: A Business User's Approach, Eighth
Bus Topology
- (^) Physical bus means all nodes attach to one cable
- (^) Logical bus means that all nodes connected to the same segment receive the same signals
- (^) Multipoint / shared bandwidth
- (^) Limited number of nodes
- (^) Faults cause widespread problems
- (^) Obsolete as a physical topology
- (^) Wi-Fi is an example of a logical bus Data Communications and Computer Networks: A Business User's Approach, Eighth
Ring Topology
Data Communications and Computer Networks: A Business User's Approach, Eighth
- (^) Nodes are connected in a ring
- (^) Signal travels from node-to-node around the ring
- (^) Not used on LANs but remains current on WANs (SONET)
Mesh Topology
- (^) Full mesh means that each node is connected to every other node
- (^) n( n-1)/2 to calculate number of links required by โnโ nodes
- (^) Partial mesh more commonly deployed - Fewer physical links required - Nodes relay (route) communications to provide interconnections between all nodes - Provides redundancy and fault tolerance - Architecture of the internet Data Communications and Computer Networks: A Business User's Approach, Eighth
Network Communication Models
Data Communications and Computer Networks: A Business User's Approach, Eighth The Open Systems Interconnection (OSI) model and the Transmission Control Protocol/Internet Protocol (TCP/IP) model are both models for structuring network communication, but they have different purposes and structures.
OSI Model
Data Communications and Computer Networks: A Business User's Approach, Eighth
- (^) The OSI model is a conceptual framework that divides network communications functions into seven layers.
- (^) Each with specific responsibilities.
- (^) To facilitate interoperability between different systems and technologies.
