connected in some ways so as to be able to exchange data. -Each of the devices on the network can be thought of as a node; each
node has a unique address.
-Addresses are numeric quantities that are easy for computers to work
with, but not for humans to remember. Example: 204.160.241.
-Some networks also provide names that humans can more easily
remember than numbers. Example: www.javasoft.com, corresponding to the above numericaddress.
NIC
addr
NIC
addrN
NIC
addr
…
Ports -An IP address identifies a host machine on the Internet.-An IP port will identify a specific application running on an Internet host
machine. -A port is identified by a number, the
port number
-The number of ports is not functionally limited, in contrast to serial
communications where only 4 ports are allowed.
-There are some port numbers which are dedicated for specific
applications.
79
Finger
23
Telnet
110
POP3 (e-mail)
25
SMTP (e-mail)
70
Gopher
20 and 21
FTP
80
HTTP
Port numbers
Applications
packet switching
-Messages are broken into units called
packets
, and sent from one
computer to the other. -At the destination, data are extracted from one or more packets and
used to reconstruct the original message. -Each packet has a maximum size, and consists of a header and a data
area. -The header contains the addresses of the source and destination
computers and sequencing information necessary to reassemblethe message at the destination.
1001….
00010000111…
packet
header
data
Sharedbus
(a) Ethernet LAN
Ring
(b) Token Ring LAN
Dual ring
(c) FDDI LAN
Network connectivity type
Speed
Transmission timefor 10 Mbytes
(Telephone) dial-up modem
14.4 Kbps
90 min
ISDN modem
56/128 Kbps
45/12min
T1 connection
1.54 Mbps
50s
Ethernet
10 Mbps
9s
Token ring
4/16 Mbps
Fast Ethernet
100 Mbps
FDDI
100 Mbps
Gigabit Ethernet
1 Gbps
ATM
25Mbps/2.4Gbs
Toronto branch
Ethernet LAN
Router
Vancouver branch
Token Ring LAN
Gateway
FrameRelayATM
T1 line
NY headquaters
Bridge/Route
Token Ring LAN
Router
Bridge
Bridge/Router
Ethernet
Network Topology Diagram The specification of the network topology diagram requires thedefinition of the characteristics and entities underlying the network:-Geographical locations of the different components or subnets
involved in the network.
-Description of the LAN topology-Description of the WAN topology-Description of the network connectors such as routers, bridges,
repeaters, and gateways.
S: MAIL FROM: [email protected]: 250 OKS: RCPT TO: [email protected]: 250 OKS: DATAR: 354 Beginning of mail; ending by <
CRLF>.
S: Blah blah blahS: …etc.S:
Request For Comments (RFC):
specifications of the protocols involved
in Internet Communications.-Example
sample of RFC 821 describing communications betweenSMTP server and client.
14
nth layer(n-1)th layer…
nth layer(n-1)th layer…
Network
-Protocols are designed based on a layered architecture such as the OSI
reference model. -Each entity at a layer
n
communicates only with entities at layer
n-
-The data exchanged, known as Protocol Data Unit (PDU), goes back
and forth through the layers, each layer adds or removes its own headerand vice-versa. Therefore a layer
n
PDU may become a layer
n-
data.
OSI Layers
Physical layer
(
defines the physical characteristics of the network)
Data-link layer
(provides safe
communication of data over the physical network)
Network layer
(handles connection to the
network by the higher layers)
Transport layer
(provides end-to-end errors detection and correction
)
Session layer
(manages sessions among applications
)
Presentation layer
(provides standard data representations for applications
)
Application layer
(applications connected to the network)
Physical layer:
ensures a safe and efficient travel of data; consists of
electronic circuits for data transmission etc. Data link layer:
in charge of data encapsulation under the form of
packets and their interpretation at the physical layer. Network layer:
in charge of packets transmission from a source A to a
destination B. Transport layer:
in charge of the delivery of packets from a source A
to a destination B Session layer:
in charge of the management of network access.
Presentation layer:
determines the format of the data transmitted to
applications, data compressing/decompressing, encrypting etc. Application layer:
contains the applications which are used by the
end-user, such as Java, Word etc.
Network layer -Provides the same functionality as the physical, the data link and
network layers in the OSI model.
-Mapping between IP addresses and network physical addresses.-Encapsulation of IP datagrams, e.g packets, in format understandable
by the network. Internet layer -Lies at the heart of TCP/IP.-Based on the Internet Protocol (IP), which provides the frame for
transmitting data from place
to place
Transport layer -Based on two main protocols: TCP (Transmission Control Protocol)
and UDP (User Datagram protocol)
Application layer -Combines the functions of the OSI application, presentation, and
session layers.
-Protocols involved in this layer: HTTP, FTP, SMTP etc.
Network (Arpanet), in 1966 in USA.
-Consists of connecting several computer networks based on different
protocols -Requires the definition of a common interconnection protocol on top
the local protocols. -The
Internet Protocol (IP)
plays this role, by defining unique addresses
for a network and a host machine.
FTP
Telnet
SNMP
SMTP
TCP/UDP
IP
Ethernet
Arpanet
Token ring
