Ct ARTIFACTS

They can arise from

Physics of X-rays

  • (^) Patient motion
  • (^) Hardware/equipment limitations
  • (^) Image reconstruction errors
  • (^) Operator technique
  • (^) Artifacts reduce image quality, diagnostic accuracy, and may mimic or obscure pathology.

Beam Hardening Artifact

Cause

  • (^) X-ray beams contain photons of various energies.
  • (^) As the beam passes through the patient, low-energy photons are absorbed first, leaving a “harder” (higher energy) beam.
  • (^) This causes nonlinear attenuation, especially through dense materials (bone, contrast media).
  • (^) 🔹 Appearance
  • (^) Cupping artifact: Center of a homogeneous object appears less dense than edges.
  • (^) Streaks or dark bands between dense structures (e.g., skull base, dental fillings).

HOW TO REMOVE THIS ARTIFACT

  • (^) ✅ Use pre-filtration (bowtie filters) to harden the beam before it enters the patient.

✅ Proper calibration and water correction phantom scans.

✅ Avoid scanning two dense bones in the same plane when possible (e.g., raise chin in head CT).

Metal Artifacts

🔹 Cause

  • (^) Metallic implants (dental fillings, prostheses, surgical clips) cause:
    • (^) Photon starvation (metal blocks X-rays)
    • (^) Beam hardening
    • (^) Scatter
    • (^) Streaking in reconstructed images

🔹 Appearance

  • (^) Bright and dark streaks radiating from metallic objects.
  • (^) Often seen in dental, hip, or spine regions.

Correction / Removal

  • (^) ✅ Use Metal Artifact Reduction (MAR) software.
  • ✅ Apply Dual-energy CT (reconstructs at higher keV levels).
  • ✅ Use thin slices and high kVp (1️⃣ 2️⃣ 0– 1️⃣ 4️⃣ 0 kVp).
  • ✅ Proper patient positioning (avoid metal in the scan plane).
  • ✅ Replace removable metal (e.g., dentures, jewelry) before scanning.

Correction / Removal

✅ Shorten scan time (use faster scanners or spiral CT). ✅ Instruct patient to hold breath during scanning. ✅ Use immobilization aids. ✅ ECG gating for cardiac CT. ✅ Sedation for uncooperative or pediatric patients if necessary.

Partial Volume Artifact

Cause

  • (^) When a voxel contains more than one tissue type, CT averages the densities.
  • (^) Common at boundaries between bone and soft tissue or air and tissue.

🔹 Appearance

  • (^) Blurring or incorrect attenuation values at edges (e.g., bone–soft tissue interface).

Correction / Removal

✅ Use thin slices (smaller voxel size). ✅ Optimize reconstruction algorithms. ✅ Position anatomy of interest at center of slice. ✅ Use multiplanar reformation (MPR) to confirm unclear regions.

Correction / Removal

  • (^) Perform detector calibration regularly.
  • ✅ Replace defective detector elements.
  • ✅ Use built-in ring correction algorithms.
  • ✅ Ensure homogeneous phantom calibration before clinical scanning.

Presented By:

  • (^) Syed Dawood Zahoor (9050)
    • (^) Jawad Ali (901️⃣ 5)
  • (^) Abdullah Nasir (9086)
  • (^) Saeedullah (8980)
  • (^) Tabinda Javed (91️⃣ 5 4️⃣ )
