Configure IPSec Encryption Tasks

Task 1—Prepare for IKE and IPSec.Task 2—Configure IKE.Task 3—Configure IPSec.Task 4—Test and Verify IPSec.

Tasks to Configure IPSec Encryption

Steps to Complete

Task 1—Prepare for IPSec

Step 1—Determine IKE (IKE phase one) policy.Step 2—Determine IPSec (IKE phase two) policy.Step 3—Check the current configuration.

show running-configurationshow crypto isakmp

policy

show crypto map

Step 4—Ensure the network works without encryption.

ping

Step 5—Ensure access lists are compatible with IPSec.

show access-lists

Determine the following policy details:

Key distribution method

Authentication method

IPSec peer IP addresses and hostnames

IKE phase 1 policies for all peers

Encryption algorithm

Hash algorithm

IKE SA lifetimeGoal: Minimize misconfiguration

Step 1—Determine IKE

(IKE Phase One) Policy

IKE Policy Example

E0/1 172.30.1.

Site 1

Site 2

E0/1 172.30.2.

A

B

10.0.1.

10.0.2.

Internet

RouterA

RouterB

Encryption AlgorithmHash AlgorithmAuthentication MethodIKE SA Lifetime

Site 1

DES 86400 seconds MD

Site 2

DES

MD

Pre-shared keys

Parameter

768-bit D-H

Key Exchange

Pre-shared keys768-bit D-H86400 seconds

Peer IP Address

172.30.2.

172.30.1.

Determine the following policy details:

IPSec algorithms and parameters foroptimal security and performance

Transforms and, if necessary, transformsets

IPSec peer details

IP address and applications of hosts to beprotected

Manual or IKE-initiated SAs

Goal: Minimize misconfiguration

Step 2—Determine IPSec

(IKE Phase Two) Policy

IPSec Policy Example

Peer IP addressTraffic (packet) typeto be encrypted

Site 1 TCP

Site 2 TCP

Transform set

ESP-DES, Tunnel

ESP-DES, Tunnel

Policy SA establishment

ipsec-isakmp

ipsec-isakmp

Peer hostname

RouterB

RouterA

172.30.2.

172.30.1.

Hosts to be encrypted

10.0.1.

10.0.2.

E0/1 172.30.1.

Site 1

Site 2

E0/1 172.30.2.

A

B

10.0.1.

10.0.2.

Internet

RouterA

RouterB

Identify IPSec Peers

Cisco Router

Remote user with

Cisco Secure

VPN Client

Other vendor’s

IPSec peers

Cisco Routers

Cisco Secure

PIX Firewall

CA server

Step 3—Check Current Configuration

(cont.)

show crypto map •

View any configured crypto maps.

router#

router# show crypto mapCrypto Map "mymap" 10 ipsec-isakmp

Peer = 172.30.2.2Extended IP access list 102

access-list 102 permit ip host 172.30.1.2 host 172.30.2.

Current peer: 172.30.2.2Security association lifetime: 4608000 kilobytes/3600 secondsPFS (Y/N): N

Transform sets={ mine, }

Step 3—Check Current Configuration

(cont.)

show crypto ipsec transform-set

View any configured transform sets.

router# router# show crypto ipsec transform-set

mine

Transform set mine: { esp-des

will negotiate = { Tunnel,

Step 5—Ensure Access Lists Are

Compatible with IPSec

routerA# show access-listsaccess-list

102 permit ahp

host

172.30.2.

host

172.30.1.

access-list

102 permit esp host

172.30.2.

host

172.30.1.

access-list

102 permit udp host

172.30.2.

host

172.30.1.

eq

isakmp

IKE

AH

ESP

Ensure protocols 50 and 51, and UDP port 500 traffic arenot blocked at interfaces used by IPSec.

E0/1 172.30.1.

Site 1

Site 2

E0/1 172.30.2.

A

B

10.0.1.

10.0.2.

Internet

RouterA

RouterB

Task 2—Configure IKE

Step 1—Enable or Disable IKE

router(config)# no crypto isakmp enablerouter(config)# crypto isakmp enable

Globally enables or disables IKE at your router.

IKE is enabled by default.

IKE is enabled globally for all interfaces at the router.

Use the

no

form of the command to disable IKE.

An ACL can be used to block IKE on a particular interface. router(config)#

[no] crypto isakmp enable

Step 2—Create IKE Policies

crypto

isakmp

policy

priority

Defines an IKE policy, which is a set ofparameters used during IKE negotiation

Invokes the config-isakmp command mode

router(config)#

router(config)#

crypto

isakmp

policy
