Construction Scheduling

Manual

Prepared by Construction Management

• 1.0 Introduction
  • 1.1 Definitions
• 2.0 Scheduling Software
• 3.0 Standard Practices
• 4.0 Standard Coding
  • 4.1 Work Breakdown Structure (WBS) Milestones.........................................
    • 4.1.1 Work Breakdown Structure
  • 4.2 Standard Activity Codes
    • 4.2.1 RESP Responsibility
    • 4.2.2 County Codes
    • 4.2.3 Classification of Work - Bridge Items
    • 4.2.4 Classification of Work - Road Items
  • 4.3 AREP Project Area
• 5.0 Standard Factors
• 6.0 Level of Detail Required on a Construction Schedule
• 7.0 Designer Contract Time Determination
  • 7.1 Final Submission...............................................................................
  • 7.2 Designer Standard Naming of Projects
  • 7.3 Multi - Year Funding
  • 7.4 Determining Start of Construction:
  • 7.6 Table A............................................................................................
  • 7.6 Table B............................................................................................
  • 7.6 Table C............................................................................................
  • 7.6 Table D
  • 7.7 Acceleration of Construction Schedules
    • 7.7.1 Increased Production Rates
  • 7.8 Designer Narrative
• 8.0 Contractor Procedure
  • 8.1 Contractor Standard Naming of Projects
  • 8.2 Time Impact Evaluation (TIE)
• Appendix A
• Appendix B
• Appendix C
• Appendix D
  • Sample 1 Time Impact Evaluation (TIE) - Form DC-186
  • Sample 2 Time Impact Evaluation (TIE) - Form DC-186

Lane Occupancy – When a Contractor occupies a lane(s) in proceeding with their work. The Contractor will pay a Lane Occupancy Charge (per direction) for the period of time a lane is unavailable to the traveling public beyond the allowable lane closure time limits.

Late Dates – “Drop dead dates”. The latest an activity can start or finish without effecting the end date of the project. Calculated by the computer during the backward pass.

Milestone - A type of activity used to represent the beginning or the end of a major stage, or an important event in a project. Start and finish milestones cannot have durations.

Predecessor - An activity that must occur before another activity. A predecessor activity controls the start or finish date of its successors. An activity can have multiple predecessors.

Preliminary Schedule – Initial schedule prior to the baseline schedule reflecting how the contractor plans to proceed with constructing a project.

Recovery Plan – Contractor’s plan to bring the project back on schedule. This includes a revised CPM schedule and additional manpower and equipment.

Relationships Types

Finish to Start - The successor activity can begin only when the current activity completes Finish to Finish – The finish of the successor activity depends on the finish of the current activity

Start to Start – The start of the successor activity depends on the start of the current activity Start to Finish – The successor activity cannot finish until the current activity starts

Remaining Duration – The time needed to complete an activity.

Successor - An activity that must occur after another activity. An activity can have multiple successors, each with a different relationship to it. Every activity must have a successor except the project’s finish milestone.

Time Impact Evaluation (TIE) Form DC-186 - A form provided by the NJDOT that facilitates a simplified analysis procedure used to award Contract Time due for delays that were not the responsibility of the Contractor. A fragnet is associated with the modeling of the effects of the delay. A CPM schedule that is able to show the pure CPM calculation differences between a schedule that does not include a delay and one that does include a fragnet modeling the delay. The difference in Contract Time between the non-impacted schedule and that of the schedule with the impact is considered to be the impact of the delay for a potential Contract Time extension.

Total Float - The amount of time an activity can be delayed without delaying the project finish date.

Updated Schedule – A schedule that truly reflects the current means and method how the project is progressing.

Work Breakdown Structure (WBS) - A deliverable-oriented grouping of project elements, which organizes and defines the total scope of the project. Each descending level represents an increasingly detailed definition of a project component.

Working Schedule – A schedule utilized for duration of a project for creation of the baseline schedule and updates.

Work Package - A deliverable at the lowest level of the work breakdown structure. A work package contains activities.

2.0 Scheduling Software

The New Jersey Department of Transportation, Capital Program Management has adopted the use of Primavera software in XER format as the standard format for progress schedules. This software and format will be updated as newer versions become available. At Final Design, the Designer will develop a construction schedule for the proposed project. See Appendix A for an example of a Primavera Schedule view.

The Contractor will submit a preliminary and baseline construction schedule and submit bi-monthly schedule updates. All construction schedules will conform to the requirements of this manual.

3.0 Standard Practices

In developing a schedule, three basic items make CPM scheduling work: Clearly defined activities Realistic duration’s Good logic

Other good practices include:

Negative lags will not be permitted. Do not use a Finish to Start relationship with a lag. An activity must be added to represent the lag time. A project has one beginning and one end. All activities have a predecessor and successor except the project’s start and finish milestones. No "Open Ends" will be permitted. Durations of work activities do not exceed the update cycle. The Department requires the update cycle to be prepared bi-monthly. "Suspension of Dates" will not be permitted. An activity must be added. If an activity has a Start-to-Start relationship - it is to be closed with a Finish-to-Finish or Finish-to-Start relationship. (No open ends) The completion date of the CPM schedule is the completion date in Subsection 108. of the project's Special Provisions, which is be input as a Finish Milestone with a Late Finish Constraint. All intermediate milestones (Interim Completion Dates) required in the Contract are to be shown in proper logical sequence and input as either the “Start- no-Earlier-Than” or “Finish-no-Later-Than” date. Mandatory Finish and Mandatory Starts are not to be used. When updating, all "Out of Sequence" activities are to be corrected to reflect the current construction operations. Original durations will not be changed from the approved Baseline Schedule.

4.0 Standard Coding

As a means of monitoring progress schedules, the Department has developed with the Consultant and Construction industries common coding structure and procedures to be utilized from design through construction. The Designer and Contractor is required to utilize the Primavera template project containing the latest standard coding provided from the Department’s web site. Details regarding template usage are provided in Appendix C.

P.PP Permits P.PP.01 Environmental P.PP.02 Dewatering P.MS Material Submittals (Long Lead Items) P.MS .01 Concrete P.MS .02 Structural Steel P.MS .03 Asphalt P.MS .04 Electrical P.MS .05 Sheeting/Cofferdam P.WD Working Drawings P.WD .01 Bridge Working Drawings P.WD.01.01 Bridge Working Drawings Requiring Design P.WD.01.01.01 Structural Steel Working Drawings P.WD.01.01.02 Structural Bearings P.WD.01.01.03 Prestressed Concrete Beams P.WD.01.01.04 Prestressed Concrete Piles P.WD.01.01.05 Expansion Dams P.WD.01.01.06 Cofferdams P.WD.01.01.07 Sheeting P.WD.01.01.08 Machinery for Movable Bridges P.WD.01.01.09 Electrical Items for Movable Bridges P.WD.01.01.10 Precast Concrete Culverts P.WD.01.01.11 Steel Bridge Deck Forms P.WD.01.01.12 Prefabricated Modular Walls P.WD.01.01.13 Mechanical Stabilized Earth (MSE) Walls P.WD.01.01.14 Concrete Crib Walls P.WD.01.01.15 Alternate Retaining Wall Design P.WD.01.01.16 Temporary Structures P.WD.01.01.17 Temporary Shielding P.WD.01.01.18 Electrical Items not pre-approved P.WD.01.02 Bridge Working Drawings Not Requiring Design P.WD.01.02.01 Structural Steel Working Drawings P.WD.01.02.02 Structural Bearings P.WD.01.02.03 Prestressed Concrete Beams P.WD.01.02.04 Prestressed Concrete Piles P.WD.01.02.05 Expansion Dams P.WD.01.02.06 Cofferdams P.WD.01.02.07 Machinery for Movable Bridges P.WD.01.02.08 Electrical Items for Movable Bridges P.WD.01.02.09 Strip Seals P.WD.01.02.10 Armored Deck Joints P.WD.01.02.11 Bridge Storm Drains P.WD.01.02.12 Sign Support Structures P.WD.01.02.13 GA Sign Support Posts P.WD.01.02.14 Noise Barriers P.WD.01.02.15 Bridge Railings and Fencing Anchorages P.WD.01.02.16 Sign Legends P.WD.02 Road Working Drawings P.WD.02.01 Road requiring design P.WD.02.01.01 Impact attenuators P.WD.02.01.02 Sheeting

P.WD.02.01.03 Electrical items not pre-approved P.WD.02.02 Road not requiring design P.WD.02.02.01 Impact attenuators P.WD.02.02.02 Sign legends P.WD.02.02.03 Recycled/synthetic routed spacers U Utility

UVER Verizon Communications

4.2.2 County Codes

Code County 0100 Atlantic County 0101 Absecon City 0102 Atlantic City 0103 Brigantine City 0104 Buena Borough 0105 Buena Vista Township 0106 Corbin City 0107 Egg Harbor City 0108 Egg Harbor Township 0109 Estell Manor City 0110 Folsom Borough 0111 Galloway Township 0112 Hamilton Township 0113 Hammonton Town 0114 Lindwood City 0115 Longport Borough 0116 Margate City 0117 Mullica Township 0118 Northfield City 0119 Pleasantville City 0120 Port Republic City 0121 Somers Point City 0122 Ventnor City 0123 Weymouth Township 0200 Bergen County 0201 Allendale Borough 0202 Alpine Borough 0203 Bergenfield Borough 0204 Bogota Borough 0205 Carlstadt Borough 0206 Cliffside Park Borough 0207 Closter Borough 0208 Cresskill Borough 0209 Demarest Borough 0210 Dumont Borough 0212 East Rutherford Borough 0213 Edgewater Borough 0211 Elmwood Park Borough 0214 Emerson Borough 0215 Englewood City 0216 Englewood Cliff Borough 0217 Fair Lawn Borough 0218 Fairview Borough 0219 Fort Lee Borough 0220 Franklin Lakes Borough 0221 Garfield City

0222 Glen Rock Borough 0223 Hackensack City 0224 Harrington Park Borough 0225 Hasbrouck Heights Borough 0226 Haworth Borough 0227 Hillsdale Borough 0228 Hohokus Borough 0229 Leonia Borough 0230 Little Ferry Borough 0231 Lodi Borough 0232 Lyndhurst Township 0233 Mahwah Township 0234 Maywood Borough 0235 Midland Park Borough 0236 Montvale Borough 0237 Moonachie Borough 0238 New Milford Borough 0239 North Arlington Borough 0240 Northvale Borough 0241 Norwood Borough 0242 Oakland Borough 0243 Old Tappan Borough 0244 Oradell Borough 0245 Palisades Park Borough 0246 Paramus Borough 0247 Park Ridge Borough 0248 Ramsey Borough 0249 Ridgefield Borough 0250 Ridgefield Park Village 0251 Ridgewood Village 0252 River Edge Borough 0253 Rivervale Township 0254 Rochelle Park Township 0255 Rockleigh Borough 0256 Rutherford Borough 0257 Saddle Brook Township 0258 Saddle River Borough 0259 South Hackensack Township 0260 Teaneck Township 0261 Tenafly Borough 0262 Teterboro Borough 0263 Upper Saddle River Borough 0264 Waldwick Borough 0265 Wallington Borough 0266 Washington Township 0267 Westwood Borough 0268 Woodcliff Lake Borough 0269 Wood Ridge Borough 0270 Wyckoff Township 0300 Burlington County 0301 Bass River Township

0412 Collingswood Borough 0413 Gibbsboro Borough 0414 Gloucester City 0415 Gloucester Township 0416 Haddon Township 0417 Haddonfield Borough 0418 Haddon Heights Borough 0419 Hi Nella Borough 0420 Laurel Springs Borough 0421 Lawnside Borough 0422 Lindenwold Borough 0423 Magnolia Borough 0424 Merchantville Borough 0425 Mount Ephraim Borough 0426 Oaklyn Borough 0427 Pennsauken Township 0428 Pine Hill Borough 0429 Pine Valley Borough 0430 Runnemede Borough 0431 Somerdale Borough 0432 Stratford Borough 0433 Tavistock Borough 0434 Voorhees Township 435 Waterford Township 0436 Winslow Township 0437 Woodlynne Borough 0500 Cape May County 0501 Avalon Borough 0502 Cape May City 0503 Cape May Point Borough 0504 Dennis Township 0505 Lower Township 0506 Middle Township 0507 North Wildwood City 0508 Ocean City 0509 Sea Isle City 0510 Stone Harbor Borough 0511 Upper Township 0512 West Cape May Borough 0513 West Wildwood Borough 0514 Wildwood City 0515 Wildwood Crest Borough 0516 Woodbine Borough 600 Cumberland County 0601 Bridgeton City 0602 Commercial Township 0603 Deerfield Township 0604 Downe Township 0605 Fairfield Township 0606 Greenwich Township 0607 Hopewell Township

0608 Lawrence Township 0609 Maurice River Township 0610 Millville City 0611 Shiloh Borough 0612 Stow Creek Township 0613 Upper Deerfield Township 0614 Vineland City 0700 Essex County 0701 Belleville Township 0702 Bloomfield Township 0703 Caldwell Borough Township 0704 Cedar Grove Township 0705 Ease Orange City 0706 Essex Fells Township 0707 Fairfield Township 0708 Glen Ridge Township 0709 Irvington Township 0710 Livingston Township 0711 Maplewood Township 0712 Millburn Township 0713 Montclair Township 0714 Newark City 0715 North Caldwell Township 0716 Nutley Township 0717 Orange City Township 0718 Roseland Borough 0719 South Orange Village Township 0720 Verona Township 0721 West Caldwell Township 0722 West Orange Township 0800 Gloucester County 0801 Clayton Borough 0802 Deptford Township 0803 East Greenwich Township 0804 Elk Township 0805 Franklin Township 0806 Glassboro Borough 0807 Greenwich Township 0808 Harrison Township 0809 Logan Township 0810 Mantua Township 0811 Monroe Township 0812 National Park Borough 0813 Newfield Borough 0814 Paulsboro Borough 0815 Pitman Borough 0816 South Harrison Township 0817 Swedesboro Borough 0818 Washington Township 0819 Wenonah Borough 0820 West Deptford Township

1107 Lawrence Township 1108 Pennington Borough 1109 Princeton Borough 1110 Princeton Township 1111 Trenton City 1112 Washington Township 1113 West Windsor Township 1200 Middlesex County 1201 Carteret Borough 1202 Cranbury Township 1203 Dunellen Borough 1204 East Brunswick Township 1205 Edison Township 1206 Helmetta Borough 1207 Highland Park Borough 1208 Jamesburg Borough 1209 Metuchen Borough 1210 Middlesex Borough 1211 Milltown Borough 1212 Monroe Township 1213 New Brunswick City 1214 North Brunswick Township 1215 Old Bridge Township 1216 Perth Amboy City 1217 Piscataway Township 1218 Plainsboro Township 1219 Sayreville Borough 1220 South Amboy City 1221 South Brunswick Township 1222 South Plainfield Borough 1223 South River Borough 1224 Spotswood Borough 1225 Woodbridge Township 1300 Monmouth County 1301 Aberdeen Township 1302 Allenhurst Borough 1303 Allentown Borough 1304 Asbury Park City 1305 Atlantic Highlands Borough 1306 Avon By The Sea Borough 1307 Belmar Borough 1308 Bradley Beach Borough 1309 Brielle Borough 1310 Colts Neck Township 1311 Deal Borough 1312 Eatontown Borough 1313 Englishtown Borough 1314 Fair Haven Borough 1315 Farmingdale Borough 1316 Freehold Borough 1317 Freehold Township

1318 Hazlet Township 1319 Highlands Borough 1320 Holmdel Township 1321 Howell Township 1322 Interlaken Borough 1323 Keansburg Borough 1324 Keyport Borough 1325 Little Silver Borough 1326 Loch Arbour Village 1327 Long Branch City 1328 Manalapan Township 1329 Manasquan Borough 1330 Marlboro Township 1331 Matawan Borough 1332 Middletown Township 1333 Millstone Township 1334 Monmouth Beach Borough 1335 Neptune Township 1336 Neptune City Borough 1337 Ocean Township 1338 Oceanport Borough 1339 Red Bank Borough 1340 Roosevelt Borough 1341 Rumson Borough 1342 Sea Bright Borough 1343 Sea Girt Borough 1344 Shrewsbury Borough 1345 Shrewsbury Township 1346 South Belmar Borough 1347 Spring Lake Borough 1348 Spring Lake Heights Borough 1349 Tinton Falls Borough 1350 Union Beach Borough 1351 Upper Freehold Township 1352 Wall Township 1353 West Long Branch Boro 1400 Morris County 1401 Boonton Town 1402 Boonton Township 1403 Butler Borough 1404 Chatham Borough 1405 Chatham Township 1406 Chester Borough 1407 Chester Township 1408 Denville Township 1409 Dover Town 1410 East Hanover Township 1411 Florham Park Borough 1412 Hanover Township 1413 Harding Township 1414 Jefferson Township

1526 Point Pleasant Beach Borough 1527 Seaside Heights Borough 1528 Seaside Park Borough 1529 Ship Bottom Borough 1530 South Toms River Borough 1531 Stafford Township 1532 Surf City Borough 1533 Tuckerton Borough 1600 Passaic County 1601 Bloomingdale Borough 1602 Clifton City 1603 Haledon Borough 1604 Hawthorne Borough 1605 Little Falls Township 1606 North Haledon Borough 1607 Passaic City 1608 Paterson City 1609 Pompton Lakes Borough 1610 Prospect Park Borough 1611 Ringwood Borough 1612 Totowa Borough 1613 Wanaque Borough 1614 Wayne Township 1615 West Milford Township 1616 West Paterson Borough 1700 Salem County 1701 Alloway Township 1702 Carneys Point Township 1703 Elmer Borough 1704 Elsinboro Township 1705 Lower Alloways Crk. Township 1706 ManningtonTownship 1707 Oldsman Township 1708 Penns Grove Borough 1709 Pennsville Township 1710 Pilesgrove Township 1711 Pittsgrove Township 1712 Quinton Township 1713 Salem Township 1714 Upper Pittsgrove Township 1715 Woodstown Borough 1800 Somerset County 1801 Bedminster Township 1802 Benards Township 1803 Benardsville Borough 1804 Bound Brook Borough 1805 Branchburg Township 1806 Bridgewater Township 1807 Far Hills Borough 1808 Franklin Township 1809 Green Brook Twonship

1810 Hillsborough Township 1811 Manville Borough 1812 Millstone Borough 1813 Montgomery Township 1814 North Plainfield Borough 1815 Peapack-Gladstone Borough 1816 Raritan Borough 1817 Rocky Hill Borough 1818 Somerville Borough 1819 South Bound Brook Borough 1820 Warren Township 1821 Watchung Borough 1900 Sussex County 1901 Andover Borough 1902 Andover Township 1903 Branchville Borough 1904 Byram Township 1905 Frankford Township 1906 Franklin Borough 1907 Fredon Township 1908 Green Township 1909 Hamburg Borough 1910 Hampton Township 1911 Hardyston Township 1912 Hopatcong Borough 1913 Lafayette Township 1914 Montague Township 1915 Newton Town 1916 Ogdensburg Borough 1917 Sandyston Township 1918 Sparta Township 1919 Stanhope Borough 1920 Stillwater Township 1921 Sussex Borough 1922 Vernon Township 1923 Walpack Township 1924 Wantage Township 2000 Union County 2001 Berkeley Heights Township 2002 Clark Township 2003 Cranford Township 2004 Elizabeth City 2005 Fanwood Borough 2006 Garwood Borough 2007 Hillside Township 2008 Kenilworth Borough 2009 Linden City 2010 Mountainside Borough 2011 New Providence Borough 2012 Plainfield City 2013 Rahway City
