Earlier Lecture

  • We have seen the schematic and the working of a Gifford – McMahon Cryocooler ( W. E. Gifford and H. O. Mc Mahon , 1950).
  • It has a valve mechanism to generate the pressure pulse. The relation between the pressure pulse and the expander – displacer motion is vital.
  • The basic components are Compressor, Flex lines, Regenerator(s), Displacer(s), Valve mechanism.
  • A GM system can reach much lower temperatures as compared to a Stirling system.

Topic : Cryocoolers

  • Pulse Tube (PT) Cryocooler
  • Working of a Pulse Tube Cryocooler
  • PT Classification
  • Stirling, GM and PT – A Comparison and Applications.
  • Phasor Analysis

Outline of the Lecture

  • In the earlier lectures, we have seen a regenerative type Stirling and GM systems.
  • These systems have a mechanical expander – displacer to displace the working gas.
  • The displacers are either free moving or driven by an external mechanism.

Introduction

Q  0 (^) , T 0

Qc , Tc

W  0

Stirling

Q  0 (^) , T 0

Qc , Tc

W  0

G – M

Pulse Tube Cryocooler

  • Consider the schematic of a Stirling system as shown in the figure.
  • In a Pulse Tube cryocooler, the mechanical displacer is removed and an oscillating gas flow in the thin walled tube produces cooling.
  • This gas tube is called as Pulse Tube and this phenomenon is called as Pulse Tube action.

Q  0 (^) , T 0

Qc , Tc

W  0

PT

Cryocooler

PSM

Working of PT Cryocooler

  • The components of a PT system are Compressor, Heat exchangers, Regenerator, Pulse tube and Phase Shift Mechanism ( PSM ).
  • The details and the requirement of the Phase Shift Mechanism ( PSM ) is explained at the later part of the lecture.
  • During pressurization, the high pressure gas flows across the regenerator and into the pulse tube.

Q  0 (^) , T 0

Qc , Tc

W  0

PT

Cryocooler

PSM

Working of PT Cryocooler

  • The cold gas, during depressurization, transfers cold to the regenerator matrix, which is used to precool the gas.
  • The Hot End temperature at the top is maintained at ambient using water.
  • The cooling effect produced at the bottom end, also called as Cold End , is lifted by using a heat exchanger.
  • Also, the After Cooler temperature at the top is maintained at ambient.

Q  0 (^) , T 0

Qc , Tc

W  0

PT

Cryocooler

PSM

Working of PT Cryocooler

  • The gas movement in the PT does not need any mechanical drive.
  • Hence, the vibrations in the PT Cryocooler are less as compared to Stirling and GM Cryocoolers.
  • The schematic of the PT Cryocooler, with three heat exchangers, namely, After cooler ( AC ), Cold end heat exchanger ( CHX ), Hot end heat exchanger ( HHX ) is as shown in the next slide.

Q  0 (^) , T 0

Qc , Tc

W  0

PT

Cryocooler

PSM

Pulse Tube Cryocooler

Advantages

  • No moving parts in the expander, hence, less vibrations.
  • No sealing requirement at low temperature.
  • High reliability.

Disadvantages

  • No reliability data due to less history.
  • Orientation effects.

Q  0 (^) , T 0

Qc , Tc

W  0

PT

Cryocooler

PSM

Pulse Tube Cryocooler

Uses

  • Cooling of infrared sensors.
  • Space applications.
  • Re-condensing of LHe and LN 2.
  • Gas liquefaction.

Recent Developments

  • Reached below 4 K.
  • Miniaturization.

Q  0 (^) , T 0

Qc , Tc

W  0

PT

Cryocooler

PSM

PT Classification

Pulse Tube Cryocooler

Stirling Gifford McMahon

Geometry Phase Shift

Inline (^) U – Type Coaxial (^) Annular

Orifice Inertance Tube Double Inlet Valve

Low Frequency

High Frequency

Very High Frequency

Frequency

Basic

PT Classification

  • Depending upon the usage of valves, Pulse Tube cryocooler can either be - Stirling type PT Cryocooler - GM type PT Cryocooler
  • Stirling systems are high frequency machines where as, GM systems are of low frequency.
  • Each of the systems has its own advantages and disadvantages.

Regenerator Pulse Tube

AC CHX HHX

Valve

PT Classification

  • The gas does not change the direction of flow. Hence, the pressure losses are minimum.
  • This arrangement delivers best performance as compared to others.
  • The cold end is at the center of the system.
  • The system is less compact since it occupies huge space (length wise). Inline

PT Classification

  • The gas flow undergoes a 180 degree change in flow direction. Due to which the system exhibits pressure drop.
  • The cold end is exposed and it is easily accessible.
  • The system is more compact and it occupies less space.
  • The performance is dependent upon the sharpness of the bend. U – Type
