Data Center Network Topologies:

VL2 (Virtual Layer 2)

Hakim Weatherspoon

Assistant Professor, Dept of Computer Science

CS 5413: High Performance Systems and Networking

September 26, 2014

Slides used and adapted judiciously from COS-561, Advanced Computer Networks At Princeton University

Goals for Today

  • VL2: a scalable and flexible data center network
    • A. Greenberg, J. R. Hamilton, N. Jain, S. Kandula, C. Kim, P. Lahiri, D. A. Maltz, P. Patel, and S. Sengupta. ACM Computer Communication Review (CCR), August 2009, pages 51-62.

Conventional DCN Problems

  • Static network assignment
  • Fragmentation of resource
    • Poor server to server connectivity
    • Traffics affects each other
    • Poor reliability and utilization

CR CR

AR AR AR AR

S S

S S

S S

S S

S S

S S

I want more

I have spare ones, but… 1:

1:

1:

Objectives:

  • Uniform high capacity:
    • Maximum rate of server to server traffic flow should be limited only by capacity on network cards
    • Assigning servers to service should be independent of network topology
  • Performance isolation:
    • Traffic of one service should not be affected by traffic of other services
  • Layer-2 semantics:
    • Easily assign any server to any service
    • Configure server with whatever IP address the service expects
    • VM keeps the same IP address even after migration
  • Traffic matrix analysis:
    • Poor summarizing of traffic patterns
    • Instability of traffic patterns
  • Failure characteristics:
    • Pattern of networking equipment failures: 95% < 1min, 98% < 1hr, 99.6% < 1 day, 0.09% > 10 days
    • No obvious way to eliminate all failures from the top of the hierarchy

Measurements and Implications of DCN

Virtual Layer 2 Switch (VL2)

  • Design principle:
    • Randomizing to cope with volatility:
      • Using Valiant Load Balancing (VLB) to do destination independent traffic spreading across multiple intermediate nodes
    • Building on proven networking technology:
      • Using IP routing and forwarding technologies available in commodity switches
    • Separating names from locators:
      • Using directory system to maintain the mapping between names and locations
    • Embracing end systems:
      • A VL2 agent at each server

VL2 Goals and Solutions

Objective Approach Solution

2. Uniform high capacity between servers

Enforce hose model using existing mechanisms only

Employ flat addressing

1. Layer- **semantics

  1. Performance** Isolation

Guarantee bandwidth for hose-model traffic

Flow-based random traffic indirection (Valiant LB)

Name-location separation & resolution service

TCP

11^ “Hose”: each node has ingress/egress bandwidth constraints

Name/Location Separation

ToR 3 payload

y x

Servers use flat names

Switches run link-state routing and maintain only switch-level topology

Cope with host churns with very little overhead

ToR 4 z payload^ y^ z

ToR 1 ToR 2 ToR 3 ToR (^4)

ToR payload^ y, z 3 z

Directory Service … xToR 2 yToR 3 zToR 4 …

Lookup & Response

… xToR 2 yToR 3 zToR 3 …

  • Allows to use low-cost switches
  • Protects network and hosts from host-state churn
  • Obviates host and switch reconfiguration

12

Valiant Load Balancing: Indirection

x y

T 3 y payload z

T 5 z payload

I (^) ANY I (^) ANY I (^) ANY

IANY

Cope with arbitrary TMs with very little overhead

Links used for up paths Links used for down paths

T 1 T 2 T 3 T 4 T 5 T (^6)

[ ECMP + IP Anycast ]

  • Harness huge bisection bandwidth
  • Obviate esoteric traffic engineering or optimization
  • Ensure robustness to failures
  • Work with switch mechanisms available today
    1. Must spread traffic
    2. Must ensure dst independence

Equal Cost Multi Path Forwarding

14

VL2 Directory System

RSM

DS

RSM

DS

RSM

DS

Agent

Agent

...... Directory

Servers

RSM Servers

  1. Reply 2. Reply
    1. Lookup

“Lookup”

  1. Ack
  2. Set 4. Ack (6. Disseminate)
  3. Replicate
  4. Update

“Update”

Evaluation

  • Fairness:
    • 75 nodes
    • Real data center workload
    • Plot Jain’s fairness index for traffics to intermediate switches

Time (s)

0 100 200 300 400 500

1.

Fairness Index 0.94^ Aggr1^ Aggr2^ Aggr

Evaluation

  • Performance isolation:
    • Two types of services:
      • Service one: 18 servers do single TCP transfer all the time
      • Service two: 19 servers starts a 8GB transfer over TCP every 2 seconds
      • Service two: 19 servers burst short TCP connections

Perspective

  • Studied the traffic pattern in a production data center and find the traffic patterns
  • Design, build and deploy every component of VL2 in an 80 server testbed
  • Apply VLB to randomly spreading traffics over multiple flows
  • Using flat address to split IP addresses and server names

Critique

  • The extra servers are needed to support the VL2 directory system,:
    • Brings more cost on devices
    • Hard to be implemented for data centers with tens of thousands of servers.
  • All links and switches are working all the times, not power efficient
  • No evaluation of real time performance.
