Source System
[Sender
Devices]
Medium
[Channel]
Destination
System
[Receiver Devices]
Sender Device Transmitter Transition
System Receiver Destination
Device
Digital Signal Digital Signal
Analog Signal Analog Signal
Communication Model
Prepare for your exams
Study with the several resources on Docsity
Earn points to download
Earn points by helping other students or get them with a premium plan
Guidelines and tips
Prepare for your exams
Study with the several resources on Docsity
Earn points to download
Earn points by helping other students or get them with a premium plan
Data Communication Model , Lecture notes of Data Communication Systems and Computer Networks
Simple model of data transfers from transmitter to Receiver .
Typology: Lecture notes
2017/2018
1 / 4
This page cannot be seen from the preview
Don't miss anything!
Related documents
Partial preview of the text
Download Data Communication Model and more Lecture notes Data Communication Systems and Computer Networks in PDF only on Docsity!
Source System [Sender Devices]
Medium [Channel]
Destination System [Receiver Devices]
Sender Device (^) Transmitter Transition System
Receiver Destination Device
Digital Signal (^) Analog Signal Analog Signal Digital Signal
Communication Model
Source or Transmitter Device
Application Layer
Communication Layer
Network Layer
Application Layer
Communication Layer
Network Layer
It is a Software Application like :GUI [ Graphical User Interface] or Shell like DOS [Disk Operating System] that take data from User.
This layer take date ex.( text , audio , video , etc.. ) and Convert it in to Binary signals [Digital Signals ] in packets ,framers like( 0101010111010101 ) and transfer this signals in to the modem or Network. This Layer take Binary Signals [Digital Signals ] and Convert it in to Analog Signals to can be transfers in the Medium or Channel.
Example : Data Communication Model Sending Text “Hello” Sending Text on WhatsApp: Hello Application Layer that convert “hello” with ASCII Code to “01001000 01100101 01101100 01101100 01101111” It send to the modem as Digital Signal.
