DATA AND FILE STRUCTURES

Binary tree

  • (^) A binary tree is composed of zero or more nodes
  • (^) Each node contains:
    • (^) A value (some sort of data item)
    • (^) A reference or pointer to a left child (may be null), and
    • (^) A reference or pointer to a right child (may be null)
  • (^) A binary tree may be empty (contain no nodes)
  • (^) If not empty, a binary tree has a root node
    • (^) Every node in the binary tree is reachable from the root node by a unique path
  • (^) A node with neither a left child nor a right child is

called a leaf

  • (^) In some binary trees, only the leaves contain a value

Size and depth

• The size of a binary tree

is the number of nodes in

it

  • (^) This tree has size 12

• The depth of a node is its

distance from the root

  • (^) a is at depth zero
  • (^) e is at depth 2

• The depth of a binary tree

is the depth of its deepest

node

  • (^) This tree has depth 4

a

b c

d e f

g h i j k

l

Tree Example: UNIX Directory

Tree Traversal (Definition)

• The process of systematically visiting all the

nodes in a tree and performing some

computation at each node in the tree is called a

tree traversal.

• There are two methods in which to traverse a

tree:

1. Breadth-First Traversal.

2. Depth-First Traversal:

  • (^) Preorder traversal
  • (^) Inorder traversal (for binary trees only)
  • (^) Postorder traversal

Tree Traversal Methods

  • (^) Pre-order
    1. Visit node // first
    2. Recursively visit left subtree
    3. Recursively visit right subtree
  • (^) In-order
    1. Recursively visit left subtree
    2. Visit node // second
    3. Recursively right subtree
  • (^) Post-order
    1. Recursively visit left subtree
    2. Recursively visit right subtree
    3. Visit node // last

Depth-first Preorder Traversal

H

D

B

A

C

E

G

I

K M O

N

L

J

F

H D B A C F E G L J I K N M O

N-L-R

Depth-first Inorder Traversal

H

D

B

A

C

E

G

I

K M O

N

L

J

F

L-N-R

A B C D E F G H I J K L M N O

. Note: An inorder traversal of a BST visits the keys sorted in increasing order

Tree Traversal Methods

• Breadth-first

BFS(Node n) {

Queue Q = new Queue();

Q.enqueue(n); // insert node into Q

while ( !Q.empty()) {

n = Q.dequeue(); // remove next node

if ( !n.isEmpty()) {

visit(n); // visit node

Q.enqueue(n.Left()); // insert left subtree in Q

Q.enqueue(n.Right()); // insert right subtree in Q

Breadth-First Traversal

H

D

B

A

C

E

G

I

K M O

N

L

J

F

H D L B F J N A C E G I K M O

Tree Traversal Examples

• Pre-order

  • (^) 44, 17, 32, 78,

• In-order

  • (^) 17, 32, 44, 48,

• Post-order

  • (^) 32, 17, 48, 62,

• Breadth-first

  • (^) 44, 17, 78, 32,

Binary search tree

Sorted

order!

Binary Tree Sort

• The Binary Tree Sort works on a simple

concept: The value at the root of a tree is

always greater than all the values in its left

subtree and less than or equal to all the

values in its right subtree.

• We can search for a value by comparing

that value to the root, and if the value is

smaller, examine the left subtree, and if the

value is larger examine the right subtree.

Binary Tree Sort

• The first step, then, is to take all the values

and build a binary search tree.

• The basis of this process is a function to

insert a new value into an existing binary

search tree.

left subtree exists?

YES

NO

attach value

as a left

subtree

try the left

subtree

Binary Tree Sort

value < value at root?

NO

YES

right subtree exists?

YES

NO

attach value

as a right

subtree

try the right

subtree

Value must be in

the left subtree

Value must be in

the right subtree
