C-14 Solutions
1. Package Design
Data Structures
� An array of nine integers
Subprograms
� Function to accept 9 integers
� Procedure to display the array in row major order
� Procedure to display the array in column major order
� Procedure to sort the array using the bubble sort algorithm
Algorithms
Accept_Numbers:
For I in 1 .. 9
Accept an integer
Store it in an array
Row_Major_Display:
For I in 1 .. 9
Display Element in Array(I);
If I mod 3 = 0 then
New_Line
Given the elements are in row-major order, the position locations are sequential.
Column_Major_Display:
For I in 1 .. 3
For J in 1 .. 3
Location_In_Array := I + (J-1)*3
Display Element in Array(Location_In_Array)
New_Line
If the elements are in column-major order, the locations in the one-dimensional
array have to be computed.
Bubble_Sort:
For I in 1 .. Array’Value(1)-1
For J in I+1 .. Array’Value(1)
If Array(I) > Array(J)
Swap the values
Note that the algorithm will sort the array in ascending order.
docsity.com
pf3
pf4
pf5
pf8
pf9
pfa
pfd
pfe
pff

Partial preview of the text

Download My_Array_Package and My_Aircraft: Ada Code for Array Processing and Aircraft Information and more Exercises Engineering in PDF only on Docsity!

C-14 Solutions

1. Package Design

Data Structures

� An array of nine integers

Subprograms

� Function to accept 9 integers

� Procedure to display the array in row major order

� Procedure to display the array in column major order

� Procedure to sort the array using the bubble sort algorithm

Algorithms

Accept_Numbers:

For I in 1 .. 9

Accept an integer

Store it in an array

Row_Major_Display:

For I in 1 .. 9

Display Element in Array(I);

If I mod 3 = 0 then

New_Line

Given the elements are in row-major order, the position locations are sequential.

Column_Major_Display:

For I in 1 .. 3

For J in 1 .. 3

Location_In_Array := I + (J-1)*

Display Element in Array(Location_In_Array)

New_Line

If the elements are in column-major order, the locations in the one-dimensional

array have to be computed.

Bubble_Sort:

For I in 1 .. Array’Value(1)-

For J in I+1 .. Array’Value(1)

If Array(I) > Array(J)

Swap the values

Note that the algorithm will sort the array in ascending order.

2. Code Listing

Package Listing

Package Specification

GNAT 3.13p (20000509) Copyright 1992-2000 Free Software Foundation, Inc.

Checking: c:/docume~2/joeb/desktop/16070/codeso~1/my_array_package.ads (source file time stamp: 2003-10-08 13:48:58)

  2. -- Package specification of a package to
  3. -- 1. Create an array of 9 integers
  4. -- 2. Display the array as a 3x3 matrix
  5. -- i. assuming row-major order
  6. -- ii. assuming column-major order
  7. -- 3. Bubble Sort the 1-D array
  9. -- Specifier : Joe B
  10. -- Date Last Modified : 10/07/
  13. package My_Array_Package is
  15. type My_Array is array (1 .. 9) of Integer;
  18. function Create_Array return My_Array;
  20. procedure Display_Row_Major(Input_Array : in My_Array);
  23. procedure Display_Column_Major(Input_Array : in My_Array);
  26. procedure Bubble_Sort (Input_Array : in out My_Array);
  27. end My_Array_Package;

29 lines: No errors

Package Body

GNAT 3.13p (20000509) Copyright 1992-2000 Free Software Foundation, Inc.

Compiling: c:/docume~2/joeb/desktop/16070/codeso~1/my_array_package.adb (source file time stamp: 2003-10-08 13:54:40)

  2. -- Package implementation of My_Array_Package
  3. -- Programmer : Joe B
  1. Temp := Input_Array(I);
  2. Input_Array(I) := Input_Array(J);
  3. Input_Array(J) := Temp;
  4. end if;
  5. end loop;
  6. end loop;
  7. end Bubble_Sort;
  9. end My_Array_Package;

72 lines: No errors

Test Program Listing

GNAT 3.13p (20000509) Copyright 1992-2000 Free Software Foundation, Inc.

Compiling: c:/docume~2/joeb/desktop/16070/codeso~1/test_my_array.adb (source file time stamp: 2003- 10-08 14:03:20)

  2. -- Program to test My_Array_Package
  3. -- Programmer : Joe B
  4. -- Date Last Modified : 10/07/
  7. with My_Array_Package;
  8. use My_Array_Package;
  9. with Ada.Text_Io;
  11. procedure Test_My_Array is
  12. New_Array : My_Array_Package.My_Array;
  13. begin
  14. New_Array := Create_Array;
  16. Ada.Text_Io.Put_Line("Displaying unsorted array in Row-Major order");
  17. Display_Row_Major(New_Array);
  19. Ada.Text_Io.Put_Line("Displaying unsorted array in Column-Major order");
  20. Display_Column_Major(New_Array);
  22. Bubble_Sort(New_Array);
  24. Ada.Text_Io.Put_Line("Displaying sorted array in Row-Major order");
  25. Display_Row_Major(New_Array);
  27. Ada.Text_Io.Put_Line("Displaying sorted array in Column-Major order");
  28. Display_Column_Major(New_Array);
  29. end Test_My_Array;

29 lines: No errors

C –15 Solutions

1. Invert a 3x3 Matrix

Data Structure

A new type my_3x3_matrix as a real array (1..3, 1..3)

Subprograms

1. Function to create the matrix

2. Procedure to display the matrix

3. Function to compute the determinant

4. Function to compute the inverse

5. Main program to invert the matrix

Algorithm

Create_Matrix:

For I in 1 .. 3

For J in 1 .. 3

Accept Matrix(I,J)

Return Matrix to the user

Display_Matrix:

For I in 1.. 3

For J in 1.. 3

Display Matrix (I,J);

New_Line

Compute_Determinant:

1. Convert the matrix into a real_matrix (as defined in

Generic_Real_arrays)

2. Compute the determinant using the det function defined in

Generic_Real_Arrays.Operations.

3. Return the computed Value

Compute_Inverse:

1. Convert the matrix into a real_matrix (as defined in

Generic_Real_arrays)

2. Compute the inverse using the Inverse function defined in

Generic_Real_Arrays.Operations.

  1. for J in 1 .. 3 loop
  2. Ada.Text_Io.Put("Please Enter Number in (");
  3. Ada.Text_Io.Put(Integer'Image(I));
  4. Ada.Text_Io.Put(",");
  5. Ada.Text_Io.Put(Integer'Image(J));
  6. Ada.Text_Io.Put(") : ");
  8. Ada.Float_Text_Io.Get(Input_Matrix(I,J));
  9. Ada.Text_Io.Skip_Line;
  10. end loop;
  11. end loop;
  12. return Input_Matrix;
  13. end Create_My_Matrix;
  15. -- user procedure to display the matrix
  16. procedure Display_My_Matrix (
  17. Input_Matrix : in My_3x3_Matrix ) is
  19. begin
  20. for I in 1 .. 3 loop
  21. for J in 1 .. 3 loop
  22. Ada.Float_Text_Io.Put(Input_Matrix(I,J));
  23. end loop;
  24. Ada.Text_Io.New_Line;
  25. end loop;
  26. end Display_My_Matrix;
  28. -- function to compute the inverse
  29. function My_Inverse (
  30. Input_Matrix : My_3x3_Matrix )
  31. return My_3x3_Matrix is
  32. -- local variable to convert the user defined matrix to the package defined
  33. -- matrix
  34. My_Real_Matrix : My_Real_Array.Real_Matrix (1 .. 3, 1 .. 3);
  35. Output_Matrix : My_3x3_Matrix;
  37. begin
  38. -- do type conversion from user defined type to package defined type
  39. for I in 1.. 3 loop
  40. for J in 1 .. 3 loop
  41. My_Real_Matrix(I,J) := Input_Matrix(I,J);
  42. end loop;
  43. end loop;
  44. -- compute inverse using the generic package function
  45. My_Real_Matrix := My_Real_Array_Operations.Inverse(My_Real_Matrix);
  46. -- reconvert back to user defined type
  47. for I in 1.. 3 loop
  48. for J in 1 .. 3 loop
  49. Output_Matrix(I,J) := My_Real_Matrix(I,J);
  50. end loop;
  51. end loop;
  52. --return computed inverse
  53. return Output_Matrix;
  55. end My_Inverse;
  58. function My_Determinant (
  1. Input_Matrix : My_3x3_Matrix )
  2. return Float is
  3. My_Real_Matrix : My_Real_Array.Real_Matrix (1 .. 3, 1 .. 3);
  4. begin
  5. -- do type conversion from user defined type to package type
  6. for I in 1.. 3 loop
  7. for J in 1 .. 3 loop
  8. My_Real_Matrix(I,J) := Input_Matrix(I,J);
  9. end loop;
  10. end loop;
  11. -- compute the determinant and return to user
  12. return (My_Real_Array_Operations.Det(My_Real_Matrix));
  13. end My_Determinant;
  15. begin
  17. -- create and display the matrix
  18. Ada.Text_Io.Put_Line("Please Enter the Matrix : ");
  19. A := Create_My_Matrix;
  21. Ada.Text_Io.Put_Line("Created Matrix : ");
  22. Display_My_Matrix(A);
  24. Ada.Text_Io.New_Line;
  26. -- compute determinant
  27. Det := My_Determinant(A);
  29. -- check for singularity
  30. if Det = 0.0 then
  31. Ada.Text_Io.Put_Line("Cannot invert the matrix");
  32. else
  33. -- compute inverse and display
  34. B := My_Inverse(A);
  36. Ada.Text_Io.New_Line;
  37. Ada.Text_Io.Put_Line("Inverted Matrix : ");
  38. Display_My_Matrix(B);
  39. end if;
  41. end Pset_4_Inversion;

131 lines: No errors

Algorithms

Create_Aircraft:

For I in 1 .. 10

Prompt the user to input relevant information

Store the information in Array(I)

Return Array to the main program

Sort_Aircraft:

For I in 1 .. Num_of_Aircraft -

For J in I+1 .. Num_Of_Aircraft

If Array(I).Latitude > Array(J).Latitude

Swap the records in Array(I) and Array(J)

Return sorted array to the user

Compute_Distances:

For I in 2 .. Num_Of_Aircraft

Compute difference in latitudes (dlat)

Compute the differences in longitude (dlon)

Covert the differences into distances using the WGS-

approximations in the handout (dlat_dist, dlon_dist)

Distance between the aircraft = sqrt(dlat_dist^2 + dlon_dist^2)

Display computed distance to the user.

Main Program:

Create aircraft using the Create_Aircraft function

Sort the aircraft

Compute the distances and display it to the user

Code Listing

My_Aircraft Package Specification

GNAT 3.13p (20000509) Copyright 1992-2000 Free Software Foundation, Inc.

Checking: c:/docume~2/joeb/desktop/16070/codeso~1/my_aircraft.ads (source file time stamp: 2003-10- 18:10:40)

  3. -- Package to specify aircraft parameters and the

  4. -- related subprograms

  5. -- Specifier : Joe B

  6. -- Date Last Modified : 10/07/

  8. package My_Aircraft is

  9. Num_of_Aircraft : constant Integer := 10;

  11. type Aircraft_Information is

  1. record
  2. Aircraft_Number : Integer;
  3. Latitude : Float;
  4. Longitude : Float;
  5. Heading : Float;
  6. Velocity : Float;
  7. end record;
  9. type Aircraft_Array is array (1 .. Num_Of_Aircraft) of Aircraft_Information;
  11. Latitude_Conversion : constant Float := 1852.24;
  12. Longitude_Conversion : constant Float := 1314.13 ;
  14. function Get_Aircraft_Info return Aircraft_Array;
  16. procedure Sort_Aircraft (
  17. Input_Array : in out Aircraft_Array );
  19. procedure Compute_Distances (
  20. Input_Array : in Aircraft_Array );
  21. end My_Aircraft;

32 lines: No errors

My_Aircraft Package Body

GNAT 3.13p (20000509) Copyright 1992-2000 Free Software Foundation, Inc.

Compiling: c:/docume~2/joeb/desktop/16070/codeso~1/my_aircraft.adb (source file time stamp: 2003-10- 08 18:26:26)

  3. -- Package body for My_Aircraft

  4. -- Programmer: Joe B

  5. -- Date Last Modified : 10/07/

  7. with Ada.Text_Io;

  8. with Ada.Integer_Text_Io;

  9. with Ada.Float_Text_Io;

  10. with Ada.Numerics.Elementary_Functions;

  12. package body my_aircraft is

  15. function Get_Aircraft_Info return Aircraft_Array is

  16. Output_Array : Aircraft_Array;

  17. begin

  18. for I in 1 .. Num_of_Aircraft loop

  19. Ada.Text_Io.Put("Please Enter Information of Aircraft");

  20. Ada.Text_Io.Put(Integer'Image(I));

  21. Ada.Text_Io.New_Line;

  23. Ada.Text_Io.Put("Aircraft Id : ");

  24. Ada.Integer_Text_IO.Get(Output_Array(I).Aircraft_Number);

  25. Ada.Text_Io.Skip_Line;

  27. end Compute_Distances;

  28. end My_Aircraft;

87 lines: No errors

Main Program

GNAT 3.13p (20000509) Copyright 1992-2000 Free Software Foundation, Inc.

Compiling: c:/docume~2/joeb/desktop/16070/codeso~1/test_my_aircraft.adb (source file time stamp: 2003- 10-08 18:12:00)

  2. -- Program to test My_Aircraft
  3. -- Programmer : Joe B
  4. -- Date Last Modified : 10/07/
  7. with My_Aircraft;
  9. procedure Test_My_Aircraft is
  10. Test_Aircraft : My_Aircraft.Aircraft_Array;
  12. begin
  14. Test_Aircraft := My_Aircraft.Get_Aircraft_Info;
  15. My_Aircraft.Sort_Aircraft (Test_Aircraft);
  16. My_Aircraft.Compute_Distances(Test_Aircraft);
  18. end Test_My_Aircraft;

20 lines: No errors
