Deep Learning and Embeddings

(Remote) Lecture 18

COVID-19 Accommodations

• Classes, assignments, exams, etc. all remote through the rest of the semester - For this class, this will mean diligence in working remotely with teammates - PC5 (Cooperative Testing) has been moved back another week (now due 4/6) - PC6 (Sprint Review 3) will now be delivered as a YouTube video (now also 4/6) - PC7 (Final Presentations) will be a scheduled telecon with all of your team members, me, and one of the IAs (forthcoming) - Look at the Piazza post; you can schedule a 30 minute block on my calendar via the link there - Try to have most/all your team members present for that
• Grades now P/NRC with option to uncover letter grade

Recap: Applying to Conversational AI

• Intent Classification
  • Data: tuples of (utterance, intent class)
  • Model: clustering, SVM, rules;
  • Inference: mapping from model output to intent class label
• Slot Extraction
  • Data: tuples of (token position, slot label)
  • Model: n-grams, RNN
  • Inference: RNN output mapped back to a vocabulary

One Slide Summary: Deep Learning and

Embeddings

• Machine Learning is driven by applied statistics
  • Simple linear models are more interpretable (e.g., best-fit line)
  • More complex models yield better accuracy (trading off interpretability)
• Deep Learning is used in the NLP space to accurately represent language and classify intents and slots - Deep learning allows black-boxing of inputs to eliminate the need to derive costly features or rules - In particular, Recurrent Neural Networks and derivatives are state-of-the-art for NLU tasks
• Embeddings are numerical representations of NLU elements
  • Expressed as fixed-dimensional vectors
  • We say that we embed a token, sentence, or utterance into a vector space called the embedding space

Machine Learning

• AI is an application of Machine Learning
• ML is an application of statistics to make predictions from existing data

Machine Learning

• AI is an application of Machine Learning
• ML is an application of statistics to make predictions from existing data

?

Machine Learning

• Decision Trees can be used to classify inputs (e.g., tall vs. not tall; high risk vs. low risk)
• Example: cardiovascular risk
  • Perhaps doctors have access to tons of old medical histories.
  • Might notice clusters in data (i.e., domain expertise ): - Minimum systolic <= 90 -> high risk of death - Old with sinus tachycardia rhythm -> high risk

Machine Learning

• We use ML to teach software to make predictions
• Software learns from existing data

Supervised learning Labeled data (e.g., tall vs. short)

Unsupervised learning Unlabeled data (e.g., just points of data)

( 20 y.o., 6ft, tall ) ( 20 y.o., 5ft, short )

( 20 y.o., 6ft ) ( 20 y.o., 5ft )

Labeled Data

Labeled / Unlabled Data

Machine Learning algorithm

Learned model (^) Prediction

Training Prediction

Machine Learning in an NLU Context

0

1

2

3

0 0.5 1 1.5 2 2.5 3

“I want a burger”

“I want a chicken sandwich”

“What’s in your Caesar salad?”

“Tell me the nutrition in a milkshake.”

A Model allows us to quantify utterances. Depending on the specific model, we can visualize data

Order_food intent class

Get_nutrition_info intent class

X: Feature 1

Y: Feature 2

Machine Learning in an NLU Context

0

1

2

3

0 0.5 1 1.5 2 2.5 3

“I want a burger”

“I want a chicken sandwich”

“What’s in your Caesar salad?”

“Tell me the nutrition in a milkshake.”

14

A Model allows us to quantify utterances. Depending on the specific model, we can visualize data

Order_food intent class

Get_nutrition_info intent class

X: Feature 1

Y: Feature 2

How do we pick features? (hint: it’s hard)

Deep Learning Crash Course

• Deep Learning is a catch-all phrase that refers to Neural Networks that have multiple layers (c.f. deep pipeline from architecture)

Deep Learning Crash Course

• Deep Learning is a catch-all phrase that refers to Neural Networks that have multiple layers (c.f. deep pipeline from architecture)

“depth” = more layers^17

Neural Network

• We use Deep Neural Networks (DNNs) to perform classification of intents, slot mapping, and slot-value pairing - DNNs can learn from (or “notice”) patterns in data that are not immediately obvious to human domain knowledge experts
• DNNs benefit from data
  • As long as features are represented, DNNs can learn which ones are important

Deeper in NNs

• Each cell in a NN is a simple combination of floating-point inputs
