SPECIFICATION SHEET
DELL EMC SC SERIES
EXPANSION ENCLOSURES
Versatile, high-performance storage
SCALE ON DEMAND
Dell EMC SC Series expansion enclosures help you store more data and reduce overall TCO by seamlessly increasing the capacity of your SC arrays. Extend the value of each storage investment with enterprise-ready solutions designed to maintain great performance, even as your environment scales to multiple petabytes per array.^1
FUTURE FLEXIBILITY
Intermix different drive types (SAS, NL-SAS and SSD) in the same enclosure, with a variety of expansion form factor options, including ultra-dense enclosures. Adding a new enclosure is simple — the new drives can be automatically assimilated into the existing virtualized pool or set up as their own standalone pool. Easily evolve from one configuration to another without having to replace drives.
ADVANCED EFFICIENCY
SC Series expansion enclosures also help lower power requirements and protect your data with high-efficiency, hot-swappable power supplies and advanced cooling. Each enclosure helps you leverage SC Series technology advantages, such as Federation, Intelligent Data Reduction and RAID tiering to lower costs and save storage space. Additionally, award-winning installation and support services ensure deployment goes smoothly and your SC environment continues to meet your needs over time.
Specifications below are arranged in the following sections,
according to array model.
Expansion for
SC SC SC SC SC 4020 SC7020F SC5020F
Expansion for
SCv30 00 SCv3 020
Expansion for
SCv SCv 2020 SCv2 080
SC All-Flash
SC Hybrid
Dell EMC SC Series
Expansion Enclosures
Expansion for SC9000, SC8000, SC7020, SC5020, SC4020, SC7020F, SC5020F
SC400 SC420 SC420F SC
SUPPORTED
CONTROLLERS
SC9000, SC 8000 *,
SC7020, SC5020,
SC 4020 *
- Note this 12Gb SAS enclosure supports the legacy SC8000 and SC4020 arrays, but will run at 6Gb speed.
SC9000, SC 8000 *,
SC7020, SC5020,
SC 4020 *
- Note this 12Gb SAS enclosure supports the legacy SC8000 and SC4020 arrays, but will run at 6Gb speed.
SC7020F, SC5020F SC9000, SC 8000 *,
SC7020, SC5020,
SC 4020 *
- Note this 12Gb SAS enclosure supports the legacy SC8000 and SC4020 arrays, but will run at 6Gb speed.
CONTROLLER-
ENCLOSURE
CONNECTION
(DUAL MODULES)
12Gb SAS 12Gb SAS 12Gb SAS 12 Gb SAS
DRIVE SLOT SIZE 3.5”
MAX DRIVES PER
ENCLOSURE
MAX RAW CAPACITY
PER ENCLOSURE
120 TB 368.64TB 368.64TB 600 TB
FORM FACTOR 2U^ 2U^ 2U^4 U^ (5U with cable mgmt)
INTERMIXED DRIVE
TYPE SUPPORT
Yes Yes Yes 7.2K HDD only
SAS DRIVE SUPPORT
(Available on new enclosure purchases)
3.5” HDD
4TB, 7.2K
6TB, 7.2K
6TB, 7.2K SED
8TB, 7.2K
10TB, 7.2K
10 TB, 7.2K SED
2.5” HDD
600GB, 15K
600GB, 15K SED
1.2TB, 10K
900GB, 1 5 K SED
900GB, 15K
900GB, 10K
1TB, 7.2K
1.8TB, 10K
1.8TB, 10K SED
2.5” Write-intensive SSD 800GB 1.6TB 1.6TB SED
2.5” Read-intensive SSD 960GB 1.92TB 1.92TB SED 3.84TB 7.68TB 15.36TB
2 .5” Write-intensive SSD 800GB 1.6TB 1.6TB SED
2.5” Read-intensive SSD 960GB 1.92TB 1.92TB SED 3.84TB 7.68TB 15.36TB
3.5” HDD
6TB, 7.2K
8 TB, 7.2K
10TB, 7.2K
10 TB, 7.2K SED
Expansion for SCv3000 Series
SCv300 SCv320 SCv
SUPPORTED
CONTROLLERS
SCv 3000 , SCv3020 SCv3000, SCv 3020 SCv3000, SCv
CONTROLLER-
ENCLOSURE
CONNECTION
(DUAL MODULES)
12 Gb SAS
DRIVE SLOT SIZE 3.5”^ 2.5”^ 3.5”
MAX DRIVES PER
ENCLOSURE
MAX RAW CAPACITY
PER ENCLOSURE
120 TB 92.16TB 600 TB
FORM FACTOR 2U^ 2U^4 U^ (5U with cable^ mgmt. tray)
INTERMIXED DRIVE
TYPE SUPPORT
Yes Yes Yes
SAS DRIVE SUPPORT
(Available on new enclosure purchases)
3.5” HDD
1.8TB, 10 K
4TB, 7.2K
6TB, 7.2K
8TB, 7.2K
10TB, 7.2K
10TB, 7.2K SED
2.5” HDD
6 00GB, 15K
9 00GB, 15K
900GB, 15K SED
9 00GB, 10K
900GB, 10K
1 TB, 7.2K
1.2TB, 10K
1.8TB, 10K
1.8TB, 10K SED
2.5” Write-intensive SSD 8 00GB 1.6TB 1.6TB SED
2.5” Read-intensive SSD 480GB 960GB 1.92TB 1.92TB SED 3.84TB
3.5” HDD
4TB, 7.2K
6TB, 7.2K
8TB, 7.2K
10TB, 7.2K
10TB, 7.2K SED
CHASSIS
HEIGHT X WIDTH X
DEPTH
8.79 cm (3.46 in) x 48.2 cm (18.98 in) x 59.4 cm (22.67 in)
8.79 cm (3.46 in) x 48.2 cm (18.98 in) x 54.1 cm (21.3 in)
22.23 cm (8. 75 in) w/cable mgmt tray 17.5 cm(6.89 in) w/o tray x 4 4. 45 cm (17.5 in) x 92.46 cm (36.4 in) fully configured. 87.63 cm (34.5 in) chassis only.
SCv300 SCv320 SCv
WEIGHT AT MAXIMUM
CONFIGURATION
28.59 kg (63.03 lb) 24 kg (53 lb) 102.05 kg (225 lb)
WEIGHT AT EMPTY 9 kg (19.84 lb) minus drives^ 8.8 kg (19.4 lb) minus drives^ 62 kg (136.68 lb) minus drives
RACK SUPPORT ReadyRails™^ II static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting
Titan 1M/Titan-D 1.2M
POWER
POWER/WATTAGE 580W^ 580W^ 1660W
HEAT DISSIPATION 1980 BTU^ 1980 BTU^ 2177 BTU
VOLTAGE 100-240 VAC^ 100-240 VAC^ 200-240 VAC
FREQUENCY 50/60 Hz^ 50/60 Hz^ 50/60 Hz
AMPERAGE 7.6-3.0A (x2)^ 7.6-3.0A (x2)^ 7.4 A at 241V Max
ENVIRONMENTAL OPERATING CONDITIONS
OPERATING
TEMPERATURE
SC400: 5° to 35°C (41° to 95) with a maximum temperature Gradation of 10°C per hour. SC420: 10° to 35°C (50° to 95) with a maximum temperature Gradation of 10°C per hour. For altitudes above 2950 ft (900 m), the maximum operating temperature is derated 1°F per 550 ft (168 m).
5˚ to 40 ˚C (41˚F to 104 ˚F)
NON-OPERATING
TEMPERATURE
- 40 to 65°C (–40 to 149°F) with a maximum temperature gradation of 20°C per hour)
- 40˚C to 65 ˚C (-40˚F to 149 ˚F)
OPERATING HUMIDITY 8% to 85% (noncondensing) with a maximum humidity gradation of 10% per hour 20 to 80%
NON-OPERATING
HUMIDITY
5% to 95% (non-condensing) 10 to 90%
OPERATING ALTITUDE – 16 to 3048 m (–50 to 10,000 ft^ -16 to 2300 m
(-50 to 7500ft)
NON-OPERATING
ALTITUDE
16 to 10,600 m (–50 to 35,000 ft) -16 to 10,600 m (-50 to 35,000ft)
Expansion for SCv2000 Series
SC100 SC120 SC
SUPPORTED
CONTROLLERS
SCv2000, SCv2020 SCv2000, SCv2020 SCv
CONTROLLER-
ENCLOSURE
CONNECTION
(DUAL MODULES)
6Gb SAS
SC100 SC120 SC
FREQUENCY 50/60 Hz^ 50/60 Hz^ 50/60 Hz
AMPERAGE 7.6-3.0A (x2)^ 7.6-3.0A (x2)^ 8.6-4.3A (x2)
ENVIRONMENTAL OPERATING CONDITIONS
OPERATING
TEMPERATURE
10° to 35°C (50° to 95°F) with no direct sunlight on the equipment; maximum temperature gradation of 20°C per hour
NON-OPERATING
TEMPERATURE
- 40 to 65°C (–40 to 149°F) at a maximum altitude of 12,000 m (39,370 ft)
NON-OPERATING
TEMPERATURE
10% to 80% (non-condensing) with 29°C (84.2°F) maximum dew point
NON-OPERATING
HUMIDITY (NON-
CONDENSING)
5% to 95% (non-condensing) with 33°C (91°F) maximum dew point
INLET TYPE 0 to 3,048 m (0 to 10,000 ft) NOTE: Up to 35°C maximum temperature is reduced by 1°C/300 m (1°F/547 ft) above 950 m (3,117 ft)
