A Comprehensive Approach to

Normalization and Denormalization

Normalization overview

• E.F. Codd proposed three normal forms:

The first, second, and third normal forms

• 1NF, 2NF and 3NF are based on the functional dependencies among the attributes of a relation
• Boyce-Codd normal form was proposed by Boyce and Codd and is known as a stronger definition of 3NF

Normalization of data

 based on set of functional dependencies (FD) and Prime Key(PK) you analyze the relation schemas to achieve two desirable properties:

1. Minimizing data redundancy
2. Minimizing insertion, deletion and update anomalies

 Therefore the ideal goal of DB design will be developing a fully normalized relational schema, preferably in BCNF.

Using normal forms

• Decomposed the relation when a NF test fails

starting from 1NF.

• Disclaimers to use of normal forms:

1. Do not guarantee good database design.

2. Sometimes highest normal form may not be the best design for performance reasons.

Continued…

• Problem solved?

Make attributes for the locations if you know

the possible number of locations.

• Better solution?

Make a new table with dname and dlocation

• This is the preferred solution

Normalizing the relation into 2NF

• Based on the concept of a full functional dependency.
• A FD X -> Y is a full functional dependency if removal of any attribute from X means that the dependency does not hold any more.
• A partial dependency can occur only if the determinate is composite.
• Partial dependency, if there is some attribute A in X that can be removed from X and the dependency still holds.

• Normalize the EMP_PROJ table
• Steps:

1. Figure out the dependencies, noting the determinates that is any attribute(s) on which some other attribute(s) are dependent)
2. Put each determinate in a table by itself.
3. Include in each table the attributes that are dependent on that determinate

SSN PNUMBER hours ename pname plocation

EMP_PROJ

Normalizing the relation int o 3NF

EMP_DEPT

 Analyze the EMP_DEPT relation:

1. In 1NF?
2. In 2NF?
3. Still a problem? 4)Identify the problem.  The problem with the EMP_DEPT table  DNAME depends on DNUM, not the prime key.(transitive dependency)  X-> Y is a transitive dependency if there is a set of attributes Z of the relation and both X -> Z and Z ->Y hold.

 A relation is in 3NF if every non-key attribute is:  In 2NF).  Non transitively dependent on the prime key.

ename SSN bdate address dnumber dname dmgrssn

Generalizing the definition of 2NF and

3NF

 To assure we do not have update anomalies we need to extend this definition to include all candidate key rather than just PK.

 Disallowed partial dependencies on any key in 2NF.  Disallowed transitive dependencies on any key in 3NF

 Simpler definition for 3NF:

 Every nonprime attribute must be: Fully functionally dependent on every key Non transitively dependent on every key

Boyce-Codd Normal Form

• Simpler, yet stricter form of 3NF.
• A relation is in BCNF if and only if every determinate is a candidate key.
• Decomposed into an equivalent set of BCNF if relation is not in BCNF.
• If relations have a composite candidate key, one of whose members are determined by a non prime attribute are in 3NF but not in BCNF.

Summary

• In general, it is best to have a relational

schema in BCNF.

• If that is not possible, 3NF will do.
• 2NF and 1NF are not considered good

relation schema designs.

• They allow too much data redundancy which

leads to update anomalies.

Denormalization

• Jovial Remark, “Normalize until it hurts, and denormalize until it works”.
• Easier to query but reintroduce data redundancies.
• Always improves data retrieval performance.
• Example: R: EMPLOYEE

Employee of a larger corporation have access to a handful of mutual fund companies for their retirement investment

Emp# Name Age Salary M_fund# Fund_nm Fund_mgr

Continued…

• However, if there are thousands of employees and just a handful of these retirement mutual funds.
• Query requiring only mutual fund data will execute rather inefficiently in denormalized design.
• In contrary, denormalization might not improve data retrieval performance in certain situation.
