Chapter 6

Security Kernels

Chapter Overview

• (^) Description
• (^) Secure Communications Processor (Scomp)
  • Architecture
  • (^) Hardware
  • (^) Trusted Operating Program
  • (^) Kernel Interface Package
  • (^) Applications
  • (^) Evaluation
• (^) Gemini Secure Operating System
• (^) Summary

The Security Kernel

• (^) MITRE, 1974, 20 subroutines, 1000 SLOC
  • (^) Showed the what and the how.
  • (^) Focus became verification
  • (^) Three core principles:
    • (^) Implement a specific security policy
    • (^) Define a verifiable protection behavior of the system as a whole
    • (^) The implementation must be shown to be faithful to the security model's design

Secure Communications

Processor (Scomp)

• (^) Kernel-based system
• (^) Designed to implement Multic's MLS requirements.
• (^) Original idea was to build an emulator to allow execution on an ordinary OS (UNIX).
• (^) Ended up with new API that provided the necessary security.

Scomp Architecture

SCOMP Architecture notes

• (^) Accesses to protected resources are mediated using an MLS policy: - (^) App requests hardware descriptor sufficient to access resource. - (^) If granted, security kernel builds the descriptor (object+permissions) and returns a reference
• (^) Isolation/tamperproofing provided by ring mechanism. Rings and transitions are implemented in hardware.
• (^) Verification was part of the process.

SCOMP Hardware 2

• (^) Each process includes a descriptor base root:
  • (^) References memory and I/O descriptors
  • (^) Used for mediating memory and I/O references.
  • (^) DMA is authorized on a per-transaction basis. - (^) I/O descriptors are built by kernel. - (^) Hardware does all authorizations. - (^) Drivers are not part of kernel! (more efficient and secure)

SCOMP Security Protection

Module

SCOMP Trusted Operating

Program Security Kernel

• (^) Memory management, process scheduling, interrupt management, audit and reference monitor. 10K SLOC mostly in Pascal.
• (^) Objects consist of processes, segments, devices, identified by a unique 64 bit id.
• (^) Access control similar to Multics, but ring brackets allow for owner/group/others
• (^) 38 gates to enter ring 0

SCOMP Trusted Software 1

• (^) Two types:
  • (^) Trusted not to violate system or integrity goals: e.g. secure loader is trusted to load a process for any subject that ensure correct enforcement of information flows.
  • (^) Trusted to maintain security policy correctly: e.g. user authentication.
  • (^) 23 processes implement trusted functions: 11K SLOC in C

Scomp Kernel Interface Package

(SKIP) 1

• (^) Uniform interface for user applications to

access trusted functions.

• (^) Two parts
  • (^) SKIP functions
  • (^) SKIP libraries

Scomp Kernel Interface Package

(SKIP) 2

• (^) SKIP functions do trusted operations on user level objects - (^) Files via a hierarchical file system - (^) Process management - (^) Concurrent I/O through an event mechanism
• (^) Allowed to manipulate system state, so trusted not to violate MLS requirements, like trusted software.
• (^) In ring 2, invoked via gates

Scomp Applications

• (^) Unix??
• (^) Mail guard
• (^) Secure Office Management System

Scomp Evaluation 1: Complete

Mediation

• (^) How does the reference monitor interface ensure that all security operations are mediated correctly? - (^) All mediation done in hardware
• (^) Does the reference monitor interface mediate security-sensitive operations on all system resources? - (^) Initial access to file data depends on access to I/O
• (^) How do we verify that the reference monitor provides complete mediation? - (^) Hardware.
