Reconfigurable Computing
Part II
Roadmap of Presentation
Static and Dynamic Configurable Systems
Piperench: A Reconfigurable Architecture and Compiler
Objectives of Static Configuration
- Improvement of Performance
- Optimizing the utilization of resources (gates & power consumption....)
An Application of Static
Configuration: SPYDER
A reconfigurable co-processor adaptable to given application in a transparent way The application is written with a high level language, compiler generates the best description for the hardware
User Configuration
First aim was transparent HW configuration The user just determines the operators in a high level language
Compiler then generates the corresponding code and does operations based on maximal parallelism.
SPYDER Architecture
Another Static Configuration
Application: RENCO
A reconfigurable network computer for improved performance of the system RENCO adds the power of reconfiguration to the network computer. User can download not only his/her application but also the processor configuration
Hardware
Composed of two parts:
- A conventional network computer with a processor: Motorola MC68EN
RENCO’s μ-processor has high communication capabilities, integrated memory controller, and many SW tools are available.
- A reconfigurable part: A cluster of FPGAs connected to their own memories and processor buses
RENCO Block Diagram
Software
Network computer requires a good OS for networking
For reconfigurable part many SW tools are availale(synthesizer, monitor for resource access & configuration loading, debugger etc) Java(Kaffe) is used for source code. HW libraries are built accordingly So like other reconfigurable systems SW is much harder than HW!
Objective of DYNAMIC
Configuration
To handle changing and/or incomplete specifications
An Application of Dynamic
Configuration: FIREFLY
Based on the idea of applying the biological principle of natural evolution to artificial systems
A genetic algorithm is iterative procedure that starts with a random initial population
Structure
Firefly is based on cellular automata model consisting of an array of cells whose states are updated in every evolutionary step. A rule table, concerning the neighbour’s state, exists for the determination of the next state
After some steps iteration leads the cells to oscillate between all 0’s and all 1’s. Firefly inherits its name from this phenomenon
Hardware
Firefly has 56 cells consisting of FPGA’s as the evolution platform. Firefly is a machine in which all the system evolution is carried out online, that is in hardware! Evolution rules and state of a cell are stored in D-flipflops.
