Effectively Prioritizing Tests in
Development Environment
Amitabh Srivastava & Jay Thiagarajan
Cyntrica Eaton
November 26, 2002
Motivation
? After initial development, software will
frequently change.
? Change management is critical to maintaining
software utility.
? Small changes in one part of the program
may have subtle, undesired effects in other
seemingly unrelated parts of the program.
Key Approach
? Effectively Prioritizing Tests…..
? Run the right test at the right time ? Focusing testing efforts on parts of the program affected by change. ? New defects probably result of new modifications
? ….in Development Environment
? Technique must be fast, useful, and easily integrated into the development process. ? Estimate program change based on comparisons of binary representations of code.
Echelon: Basic Idea
Binary Change Analysis
Coverage Analysis
Test Prioritization
Old Binary Coverage
Prioritized List of Test Cases
List of Blocks not Covered by Testing
Old Binary
New Binary
Remaining Presentation
?Features of Echelon
?Test Prioritization Sequence
?Empirical Evaluation
Features of Echelon
? Prioritizing Tests
? Calculating Program Change
? Utilizing Program Binaries
? Providing Test Coverage Information
? General Practicality
Prioritizing Tests
?Prioritizes tests into an ordered
sequence based on program change.
?Does not permanently discard tests like
minimization techniques presented in
[4][13][19][30].
?Allows use of a non-precise algorithm that
works well in practice.
Calculating Program Change
? Computes changes between programs at a
very fine granularity using an accurate binary
matching algorithm.
? The paper points out other works in test selection [1][3][4][20][28] and test prioritization [6][8][17][31] that also use program change as a guiding factor.
? Cites how differences in techniques affect the estimation of program change.
Calculating Program Change
?Source code differencing
?Data and control flow analysis
?Coarse-grained code entities
Calculating Program Change
? Source Code Differencing [6][8][28]
? Simple and fast
? Can be accomplished with commonly available tools like “diff” in Unix
? Erroneously marks a procedure as changed even if variables were only renamed.
? Fails to determine the set of affected procedures when header files that define macros and methods have been modified.
Calculating Program Change
? Coarse-grained techniques [5]
? Uses functions, global variables, type definitions, etc. to identify which parts of the program might be affected by the changes.
? According to [11], estimations of program change based on coarse-grained entities [5] may select more tests than statement or control flow based techniques.
Calculating Program Change
? Data and control flow analysis [1][20]
? Difficult in a language such as C++/C which contains pointers, casts, and aliasing.
? Flow analysis is expensive in large commercial systems [9][21] and should not be used unless the techniques will be helpful for other analyses[9].
Step 2: Coverage Analysis
Binary Change Analysis
Coverage Analysis
Test Prioritization
Old Binary Coverage
Prioritized List of Test Cases
List of Blocks not Covered by Testing
Old Binary
New Binary
Step 2: Coverage Analysis
? Determine which impacted blocks in the new
version are likely to be covered by an existing
test.
? Old modified blocks ? Check to see if the test covered the matching block in the old binary using the cover information of the old binary.
? New blocks ? A test may cover a new block if it covers at least one of its immediate predecessor blocks and at least one of its immediate successor blocks, skipping in both cases, any intermediate new blocks.
Step 2: Coverage Analysis
Predecessor Blocks (P)
Successor Blocks (S)
New Block (N)
Interprocedural edge
Step 3: Test Prioritization
Binary Change Analysis
Coverage Analysis
Test Prioritization
Old Binary Coverage
Prioritized List of Test Cases
List of Blocks not Covered by Testing
Old Binary
New Binary
Step 3: Test Prioritization
? By now, Echelon has predicted the set of
impacted blocks that will be covered by each
test.
? Uses the impacted block set for each test as
a basis for prioritization.
? Iteratively finds a short sequence of tests
which cover the maximum amount of
impacted blocks.
Weights
Step 3: Test Prioritization
T
T
T
T
T
Impacted Blocks
Prioritized List
Step 3: Test Prioritization
Weights
Impacted Blocks
Prioritized List
T T
T
T
T
Step 3: Test Prioritization
Weights
Impacted Blocks
Prioritized List
T T
T
T
T
Step 3: Test Prioritization
Weights
Impacted Blocks
T
T
T
T
Prioritized List
T
Step 3: Test Prioritization
Weights
Impacted Blocks
T
T
T
Prioritized List
T T
Step 3: Test Prioritization
Weights
Impacted Blocks
Prioritized List
T T
T
T
T
Step 3: Test Prioritization
Weights
Impacted Blocks
T
T
T
Prioritized List
T T
Step 3: Test Prioritization
Weights
Impacted Blocks
Prioritized List
T T
T T T
Sequence #
Sequence #
Empirical Evaluation
?Performance
?Test sequence characteristics
?Predicted blocked coverage accuracy
?Effectiveness
?Early detection of defects when tests run in
prescribed, prioritized order.
Performance of Echelon
No. of Tests 3128 3128
File Size (bytes) 8,880,128 8,880,
Blocks 668,068 668,
Functions 31,020 31,
Date December 2000 January 2001
Version 1 Version
Performance of Echelon
Number of 1,
sequences
Time taken by 210 seconds
Echelon
Tests in first seq. 16 Tests
Impacted Blocks 176 Blocks
Covered
Total
Old
New 220
378
158
Impacted Blocks
Performance Analysis
?How many sequences of tests were
formed?
?How many tests are in each sequence?
?How accurate is Echelon?
Performance Analysis Number of Tests in Each Sequence
First Sequence: 16 tests
Cover a common routine
Performance of Echelon
Number of 1,
sequences
Time taken by 210 seconds
Echelon
Tests in first seq. 16 Tests
Impacted Blocks 176 Blocks
Covered
Total
Old
New 220
378
158
Impacted Blocks
Performance Analysis Number of Impacted Blocks in Each Sequence
Maximum number of covered blocks
Performance Analysis
?Accuracy
?How many blocks that were predicted to be
covered by a test were not covered?
?How many blocks that were expected to
remain uncovered were actually
uncovered?
Performance Analysis Incorrectly Predicted False Positives
Performance Analysis
Successor Blocks (S)
New Block (N)
False positives can be explained by instances where there was also a direct path from the predecessor to the successor of a new block.
Performance Analysis Incorrectly Predicted False Negatives
Cited References
[13] M. J. Harrold, R. Gupta and M. L. Soffa , "A Methodology for Controlling the Size of a Test Suite", ACM Trans. Software Eng. And Methodology, vol. 2, no. 3, pp. 270-285, July 1993.
[17] G. Rothermel , R. H. Untch and M. J. Harrold, "Prioritizing Test Cases For Regression Testing", IEEE trans. On Software Engineering, vol. 27, no. 10, Oct. 2001
[19] G. Rothermel , M. J. Harrold, J. Ostrin and C. Hong, "An Empirical Study of the Effects of Minimization on the Fault Detection Capabilities of Test Suites", Proc. Int'l Conf. Software Maintenance, pp. 34-43, Nov. 1998.
[20] G. Rothermel and M. J. Harrold, "A Safe, Efficient Regression Test Selection Technique", ACM Trans. Software Eng. And Methodology, vol. 6, no. 2, pp. 173-210, Apr. 1997.
[28] F. Vokolos and P. Frankl , "Pythia : a regression test selection tool based on text differencing", Int'l conference on reliability, Quality and Safety of SoftwareIntensive Systems, May 1997.
[30] W. E. Wong, J. R. Horgan , S. London, and A. P. Mathur, "Effect of Test Set Minimization on Fault Detection Effectiveness", Software-Practice and Experience, vol. 28. no. 4, pp. 347-369, Apr. 1998.
[31] W. E. Wong, J. R. Horgan , S. London, and H. Agrawal , "A Study of Effective Regression Testing in Practice", Proc. Eighth Int'l Symposium Software Reliability Eng., pp. 230-238, Nov. 1997.
