CS 61B: Lecture 19
Monday, October 11, 2010
Today’s reading: Sierra & Bates, p. 664.
ENCAPSULATED LISTS (a case study in encapsulation)
==================
Homeworks 3, 4, and 5 introduced you to three different implementations of
linked lists, each fundamentally different.
With the Homework 3 lists, if an application writer wants to query the identity
of every item in the list without modifying the list, it takes time
proportional to the square of n, the number of items in the list (i.e.,
Theta(n^2) time), because you have to use nth(i) to identify each item in time
proportional to i.
The lists in Homeworks 4 and 5 allow an application to directly hold a node in
a list. By alternating between the next() method and the item field or method,
you can query all the list’s items in Theta(n) time. Similarly, if an
application holds a node in the middle of a list, it can insert or delete c
items there in time proportional to c, no matter how long the list is.
The Homework 5 lists (SList and DList) are well-encapsulated, whereas the
Homework 4 DList has flaws. I will discuss these flaws today to illustrate why
designing the really good list ADTs of Homework 5 was tricky. Let’s ask some
questions about how lists should behave.
(1) What happens if we invoke l.remove(n)--but the node n is in a different
list than l?
In Homework 4, Part II asks whether it is possible for an application to
break the DList invariants. One way to do this is to mismatch nodes and
lists in method calls. When an application does this, the "size" field of
the wrong list is updated, thereby breaking the invariant that a list’s
size field should be correct. How can we fix this?
ADT interface answer: The methods remove(), insertAfter(), etc. should
always update the right list’s "size" field.
Implementation answer: It’s unacceptably slow to walk through a whole
list just to see if the node n is really in the list l. Instead, every
node should keep a reference to the list that contains it. In Homework 5,
each ListNode has a "myList" field.
(2) Should insertAfter(), remove(), etc. be methods of List or ListNode?
Normally, we expect the methods that modify a data structure (like a List)
to be methods within that data structure’s class. However, if we define
methods like insertAfter() and remove() in the ListNode class, rather than
the List class, we completely avoid the question of what happens if
they’re invoked for a node that’s not in "this" list. This way, the
interface is more elegant.
ADT interface answer: the list methods are divided among List and
ListNode.
Some methods of List | Some methods of ListNode
|
public boolean isEmpty() | public Object item()
public void insertFront(Object item) | public ListNode next()
public ListNode front() | public void insertAfter(Object item)
Implementation answer: again, each node has a "myList" field so we can
update a list’s "size" field when we call n.remove(), n.insertAfter(),
etc.
(3) What happens if we invoke l.remove(n), then l.insertAfter(i, n)?
Another way to trash the DList invariants is to treat a node that’s been
removed from a list as if it’s still active. If we call insertAfter on a
node we’ve already removed, we may mangle the pointers.
AARGHH!!!
--- --- --- --- --- --- ---
|x|<->|n|<->|y| --remove()-> |x|<----->|y| --insertAfter()-> |x|---------->|y|
--- --- --- --- --- --- ---
^ ^ ^ ^
| --- | | --- --- |
\---|n|---/ \--|n|<->| |<-/
--- --- ---
The result violates the invariant that if x.next == y, then y.prev == x.
We would prevent the pointer mangling if remove(n) set n’s pointers to
null, but that wouldn’t stop insertAfter() from incrementing the list’s
"size" field (or throwing a NullPointerException), which is not a
reasonable result.
Calling remove(n) twice on the same node also corrupts "size".
How can we fix this?
ADT interface answer: After n.remove() is executed, removing n from the
list, n is considered to be an "invalid" node. Any attempt to use n,
except to call n.isValidNode(), throws an exception.
Why do we change the node, rather than erasing the reference to it?
First, the remove() method can’t erase the reference, which is passed by
value. Second, there might be lots of other references to the same node,
and we need to erase all of them too! All those other references could be
used to corrupt the data structure if the node itself isn’t neutralized.
Implementation answer: When an item is removed from a list, the
corresponding ListNode’s "myList" reference is set to null. This is just
a convenient way to mark a node as "invalid". The "next" and "prev"
references are also set to null. These steps eliminate opportunities for
accidentally corrupting a list as illustrated above. (Also, they help
Java’s garbage collection to reclaim unused DListNodes. We’ll discuss
garbage collection near the end of the semester.)
Any ListNode whose "myList" reference is null is considered "invalid",
and any attempt to use it will incite an exception.
