Chapter 10
Error Detection
and
Correction
Docsity.com
Data can be corrupted
during transmission.
Some applications require that
errors be detected and corrected.
Note
Docsity.com
In a single-bit error, only 1 bit in the data
unit has changed.
Note
Docsity.com
Figure 10.1 Single-bit error
Docsity.com
Figure 10.2 Burst error of length 8
Docsity.com
To detect or correct errors, we need to
send extra (redundant) bits with data.
Note
Docsity.com
In this book, we concentrate on block
codes; we leave convolution codes
to advanced texts.
Note
Docsity.com
In modulo-N arithmetic, we use only the
integers in the range 0 to N −1, inclusive.
Note
Docsity.com
10-2 BLOCK CODING
In block coding, we divide our message into blocks, each of k bits, called datawords. We add r redundant bits to each block to make the length n = k + r. The resulting n-bit blocks are called codewords.
Error Detection Error Correction Hamming Distance Minimum Hamming Distance
Topics discussed in this section:
Docsity.com
Figure 10.5 Datawords and codewords in block coding
Docsity.com
Figure 10.6 Process of error detection in block coding
Docsity.com
Let us assume that k = 2 and n = 3. Table 10.1 shows the list of datawords and codewords. Later, we will see how to derive a codeword from a dataword.
Assume the sender encodes the dataword 01 as 011 and sends it to the receiver. Consider the following cases:
- The receiver receives 011. It is a valid codeword. The receiver extracts the dataword 01 from it.
Example 10.
Docsity.com
Table 10.1 A code for error detection (Example 10.2)
Docsity.com
An error-detecting code can detect
only the types of errors for which it is
designed; other types of errors may
remain undetected.
Note
Docsity.com
