Excel Cheat Scheet
Last updated July 2018 Faye Brockwell
See https://staff.brighton.ac.uk/is/training/Pages/Excel/formulae.aspx for videos and exercises to accompany this quick reference card.
Formulae & Functions Basics
When building a formula: All formulae and functions begin with = Use your mouse to select a cell or range of cells to be used in a formula
The operators for building formulae are:
BODMAS rules apply to arithmetic ( B rackets O ver D ivision, then
M ultiplication, then A ddition, then S ubtraction).
Avoid typing variables (such as tax rates) in formulae; instead type the
variable in a separate cell and refer to that cell in the formula
To repeat a formulae down a column, build the formula in the first cell of
the column, then use autofill to copy the formula down the column.
Functions follow the format =name(arguments) where:
name the name of the function (e.g. SUM, VLOOKUP) arguments the cell or range references containing the values used in the function
Where a function contains more than one argument, each argument
must be separated by a , (comma).
Text criteria in an argument must be surrounded by “” (quotation marks)
Checking for formulae
If you are using a spreadsheet set up by someone else, before typing data into a cell, check whether the cell contains a formula. If a cell contains a formula, the cell will usually show the result of the formula. The formula itself can be seen in the formula bar.
Click on the cell to select it. The formula bar will display the content of the selected cell.
If the cell does contain a formula, double click on the cell. This will colour any cells on the current worksheet that feed into that formula, to help you work out what that formula does and how it works.
Always press ESC to stop checking/editing a cell containing a formula. This guarantees that you will leave the formula as you found it.
Do NOT click your mouse elsewhere on the sheet to stop checking as this may break the formula. How to check which cells on a sheet contain formulae There is a way to show all formulae on a worksheet before you start using it: On the Formulas tab, click on the Show Formulas icon Any cells with formulae will show the formula instead of the result To switch this off, go back to the Formulas tab and click on the Show Formulas icon
The shortcut for this is CTRL `
Last updated July 2018 Faye Brockwell
How to check what a formula is doing Use this technique to check that your formulae are doing what you think: Click on the cell containing the formula.
Click once on the formula in the formula bar. The cells used in the formula will be colour coded within the sheet, making it easy to spot mistakes.
Building a formula to add
- Click in the cell where the result of the formula will appear
- Type =
- Click on the first cell containing data to be included in the sum
- Type +
- Click on the next cell containing data to be included in the sum
- Repeat steps 4 and 5 as required.
- Press ENTER on the keyboard.
Autosum to add row or column totals
This only works where the total is to appear at the end of the column or row of data. This technique will not work across worksheets.
Select the range of cells to add up
On the Home tab, click on the Autosum icon The total will be put in the cell at the end of the selected cells.
Building a formula to subtract
- Click in the cell where the result of the formula will appear
- Type =
- Click on the first cell containing data to be included in the calculation
- Type –
- Click on the next cell containing data to be included in the calculation
- Press ENTER on the keyboard.
Building a formula to multiply or divide
- Click in the cell where the result of the formula will appear
- Type =
- Click on the first cell containing data to be included in the calculation
- Type * to multiply or / to divide
- Click on the next cell containing data to be included in the calculation
- Press ENTER on the keyboard.
Building a formula to calculate a percentage
To calculate a percentage, use the % sign within your formula.
A formula to calculate 20% of cell E2 would read =E2*20%
Last updated July 2018 Faye Brockwell
Absolute references for common variables
Avoid typing variables (such as tax rates) in formulae; instead type the variable in a separate cell and refer to that cell in the formula.
The advantage of this is that, should the variable change, you only need update one cell and all formulae referencing that cell will updated automatically. The disadvantage is that if you copy a formula that references that variable cell, your formula will not work properly unless you make the referenc e to the variable cell absolute (instead of relative )
There are 2 ways to make a formula absolute (which you choose is up to you): Naming the variable cell Using $ signs to indicate that a cell reference is absolute
Name cells or ranges for easier to read formulas This technique has the advantage that formulae become easier to read. The disadvantage is not many people understand the technique.
Select the cell or range you want to name Click in the Name box (left of the formula bar) Type the name and press ENTER
To use, simply type the name wherever you would use a cell or range reference in a formula. e.g. =SUM(Wages)
$$ signs to make a cell reference absolute The alternative to naming a cell is to use dollar signs within the cell reference to make the cell reference for the variable value absolute.A quick way to do this: Click on the cell containing the formula Click once on the cell reference in the formula bar Press F4 to add 2 dollar signs to your cell reference. Eg D2 will become $D$2. You can type the dollar signs in manually.
Mixed cell references
When copying formulae to other cells, sometimes you only want to anchor the column letter or row number of a cell reference within the original formula. This is achieved by changing the position of the dollar signs mentioned above. A quick way to do this: Click on the cell containing the formula Click once on the cell reference in the formula bar Press F4 until the cell reference meets your requirements (see below) Relative v absolute v mixed cell references
This table shows how the different $ sign positions affect the cell references in a formula when copied to another column and down a row:
Original cell reference...
...when copied becomes Effect
D2 E
Both the column and the row coordinates change as the formula is copied $D2 $D
The column coordinate is fixed, but the row coordinate changes D$2 E$
The column coordinate changes, but the row coordinate is fixed. $D$2 $D$2 Both the column and row coordinates remain fixed
Last updated July 2018 Faye Brockwell
Function Used for Format Example Tips
SUM
Add values in a range of cells =SUM(range of cells to add)^ =SUM(A1:A10) AVERAGE
Average the values in a range of cells =AVERAGE(range of cells to average)^ =AVERAGE(A1:A10)
MAX
Find the highest value in a range of cells
=MAX(range of cells) =MAX(A1:A10)
MIN
Find the lowest value in a range of cells =MIN(range of cells)^ =MIN(A1:A10)
IF
Display different information depending on the outcome of a condition test
=IF(condition test, what to display if outcome is true, what to display if outcome is false)
=IF(A1>20, “Great!”,”Oops!”) or =IF(A1>20, A1E1,A1)*
AND
Test that more than one condition is true. Test result is TRUE only if all conditions are met.
=AND(condition test 1 , condition test 2, ...) =AND(A1>20,B1=”Gold”)
TRUE and FALSE are the only possible answers. To change the content of a cell as the result of an AND function, use the AND function as the condition test in an IF statement
OR
Test that more than one condition is true. Test result is TRUE if any of the conditions are met.
=OR(condition test 1 , condition test 2, ...) =OR(A1>20,B1=”Gold”)
COUNT Count numerical cells^ =COUNT(range of cells to count)^ =COUNT(A1:A10)
COUNT does not count cells containing text, use COUNTA for this
COUNTA Count cells^ =COUNTA(range of cells to count)^ =COUNTA(A1:A10) COUNTBLANK Count empty cells^
=COUNTBLANK(range of cells to count) =COUNTBLANK(A1:A10 )
COUNTIF
Count cells that meet a certain condition
=COUNTIF(range of cells to count,critera to satisfy)
=COUNTIF(A1:A10,”>20”)
Counts all cells containing a value greater than 20
COUNTIFS
Count cells only if multiple conditions are met
=COUNTIFS( range of cells for criteria check 1, criteria 1 to satisfy, range of cells for criteria check 2, criteria 2 to satisfy,...)
=COUNTIFS(A1:A10,”Gold”,B1:B10,”>20”) Counts number of rows where column A contains the word Gold AND column B is greater than 20
Can use pivot table instead.
Last updated July 2018 Faye Brockwell
Flash Fill (Excel 2013 & 2016 only)
This tool is amazing for working with text in databases. In earlier versions, you needed to know several text functions to achieve the same results. Type the desired result in the first cell of the series and press ENTER Start typing the desired result in the second cell in the series. Excel should suggest content for that and all other ce lls in the column. Press ENTER to fill the column.
Some examples:
To merge first name and last name in one column Type the full name in the first cell of a new column Start typing the full name in the second cell of the new column Press ENTER when Excel suggests the full name for every cell in the column
To extract the initials from 2 columns Type the initials in the first cell of a new column Start typing the initials in the second cell of the new column Press ENTER when Excel suggests the initials f or every cell in the column
TOP TIP: if the technique above does not work: Type the desired result in the first cell of the series and press ENTER. Type the desired result in the second cell in the series and press ENTER. Select both cells. Use the Autofill technique to copy the cells down column.
Click on the icon and choose Flash Fill.
To split the contents of a column into 2 columns
For example, you can separate a column of full names into first and last name columns. Insert a new column to the right of the column you want to spl it Select the column that you want to split On the Data tab click on the text to columns icon In the pop-up window, check that Delimited is selected and click on Next In the Delimiters section, indicate what separates the first bit of text from the second. o E.g. if a space separates first and last name, click on Space o The example shows how to indicate that 2 pieces of information are separated by a hyphen o Click on Next and then on Finish
Last updated July 2018 Faye Brockwell
Colour all cells containing a formula (Excel 2013
only)
This may help you keep track of where you have added formulae to a sheet.
Click on to select the entire worksheet.
On the Home tab, click on Conditional Formatting and choose New Rule.
In the list, click to choose Use a formula to determine which cells to format In the formula box type =ISFORMULA(A1) Click on the Format button. Choose the format you require. e.g. to colour all cells containing a formula: o Click on the Fill tab o Click on a colour for the cell o Click OK. Click OK.
All cells containing a formula will be coloured.
Recommended PivotTables (Excel 2013 and 2016)
Excel Pivot Tables summarise data without the need to build complex formulae. From Excel 2013 on, the Recommended PivotTables tool will suggest simple Pivot Tables to summarise your data without the need to know the details of how to build a PivotTable.
Click anywhere within the table of data. Click on the INSERT tab. Click on the Recommended PivotTables icon.
Click on the suggested PivotTables on the left of the pop-up window to see the table in more detail.
To create a PivotTable, click on the PivotTable you require and click OK.
The PivotTable will be created on its own worksheet.
Creating a chart from a Pivot Table Once you’ve created a simple Pivot Table using the steps above, creating a chart to go with it is easy: Click on the Pivot Table to select it. On the Pivot Table Tools ANALYZE tab, click on the PivotChart icon Choose a chart type Click OK.
