© 2002 Sécurité.Org^

Agenda »^ Introduction »^ External Gateway Protocol : BGP »^ Internal Gateway Protocols : OSPF and ISIS »^ Netflow based DDoS detection »^ MPLS and IPv6 »^ Conclusion

docsity.com

© 2002 Sécurité.Org^

What « runs » the Internet? »^ Key protocols^ > BGPv4 (Border Gateway Protocol)> DNS (Domain Name System)> A mix of BGP and DNS in all new/recent technologies- DNS to store the information in new/extended type of records- BGP to distribute the information across the network»^ A few large vendors^ > Limited range of ASIC powered devices> Some well known software release versions/trains(ie S-train)»^ Non-technical stuff : people in the NOCs & coffee :-)

docsity.com

© 2002 Sécurité.Org^

What are the risks, if any? (2) »^ Current, new and future type of attacks^ > Misconfiguration is the most common “attack”> (D)DoS with spoofed source addresses- Kill your network / (IRC) servers- Use of routers as reflectors/amplifiers- No reliable traceback> Short-lived announcements used as source of SPAM/attacks> Advanced routing protocols attacks- Make your (internal/external) routing protocol unstable- Inject new routes/prefixes : MiTM/traffic rerouting attacks> Rootkits and Loadable Kernel Modules- Take control of a device capable of generation thousands ofPPS (packets per second)- Control all the routing protocol traffic

docsity.com

© 2002 Sécurité.Org^

BGP : Protocol description »^ BGP (Border Gateway Protocol)^ > Current version : 4> Listens on port 179/tcp> Optional authentication :- MD5 : adds an option to TCP (digest based on pseudo-header+header+data+shared password)> Point-to-point over directly connected interfaces or multi-hop between (TTL > 1) non adjacent routers> Routing information is exchanged in BGP Update message :

docsity.com

© 2002 Sécurité.Org^

BGP : Risks »^ Where are the risks?^ > Internet Exchanges (“peering points”)- All providers are usually connected to the same sharedinfrastructure (a switch for example)- The filtering policy is usually more “relax” for peerings- Some major ones, no real (geo)diversity anymore> Your direct {up,down}stream(s)> Route reflectors> Multi-hop configurations (Man-in-the-middle attack)> Less likely : some backbone router “out there” in theInternet or some hops away»^ What is never “verified”^ > Origin-AS/prefix relation, “true” AS_path, sourceauthenticity, etc

docsity.com

© 2002 Sécurité.Org^

BGP : Attacks (1) »^ Information gathering^ > Find the eBGP peers :- “Forward” and “reverse” traceroute / ICMP Record Route- Public route-servers and looking glasses- Directly adjacent IPs- IPs often used for loopback interfaces (.1+, .254-)- SNMP> Session parameters may be required :- Source/destination ports (ie. which router initiated theconnection)- Right TTL

docsity.com

© 2002 Sécurité.Org^

BGP : Attacks (3) »^ Attacks against the network^ > Attacks playing with BGP parameters (local-pref, MEDs,communities) ?> Make your BGP sessions flap : make you or otherdestinations unreachable> Announce “more specific routes” of large blocks to increasethe number of prefixes in the global routing table and eat upmemory on all routers> Announce or “remove” some routes/prefixes or change theirattributes> Direct all the traffic to a blackhole, direct it to a specificnetwork (DDoS), create loops, etc.

docsity.com

© 2002 Sécurité.Org^

BGP : Sequence number prediction »^ ISN problems on Cisco routers^ Vulnerable IOS

“Less” vulnerable IOS

> “Fixed” as of 12.0(15) and 12.1(7)> ISNs are (still) time dependant^ Source : http://razor.bindview.com/publish/papers/tcpseq.html

docsity.com

© 2002 Sécurité.Org^

BGP : Filtering policy »^ Filtering recommendations^ > Don’t accept to have only /24> Never accept, announce or redistribute prefixes that arelonger than /24 or de-aggregated blocks> Usemaximum-prefix (ie “full routing table” is currently~110K-114K routes)> Only accept the customer’s allocated prefixes> Don’t filter on AS_path only, but also prefixes (customermay announce a more specific route): this the same asin/egress filtering of IP addresses !> Filter bogon and non-allocated networks> Should you really accept/announce a default route in BGP ?> Have ingress and egress filters to limit the prefixes youreceive/send

docsity.com

© 2002 Sécurité.Org^

BGP : Ingress/egress filtering (1) »^ What you should never route/see/allow through^ > RFC 1918 (10.0.0.0/8, 172.16.0.0/12, 192.168.0.0/16)> 0.0.0.0/x, 127.0.0.0/8> 169.254.0.0/16 (auto-configuration when no DHCP)> 192.0.2.0/24 (Netname: TEST-NET, like example.com)> 192.88.99.0/24 (RFC 3048, used by 6to4 routers)> Multicast blocks (D Class) and Martian networks (E+)> “Hijacked” space by some vendors (192.0.0.192 for printers)> (ARIN) Reserved blocks (bogon networks)> Packets to broadcast addresses or where source ==destination»^ What you should route/let through^ > Your network prefixes (anti-spoofing)

docsity.com

© 2002 Sécurité.Org^

BGP : Security recommendations (1) »^ Security measures^ > Log changes (and think about using IPsec -- CPU and $)> Use MD5, but not the same password with all the peers> Filter and limit the number of prefixes, filter the AS_path> Use a “secondary” or “loopback” IP address for the eBGPsession to hide part of the eBGP session details> Protect routes towards Root Servers (.{root, gtld}-servers.net) : exclude them from the route dampening> Filtering and routing policies are important, but don’t forget:- to harden your router configuration- to use secure in and out-of-band management and monitoringtools/protocols- that physical access to the router gives “full rights” (peeringpoints/data centers)

docsity.com

© 2002 Sécurité.Org^

BGP : Security recommendations (2) »^ Security measures

router^ bgp^65000 no^ bgp^ dampeningbgp^ dampening^ route-map^ dampening-listbgp^ log-neighbor-changesnetwork^ x.x.x.xneighbor^ y.y.y.y^ remote-as^

65001 neighbor y.y.y.y password neighbor y.y.y.y version 4 neighbor y.y.y.y prefix-list^ theirnetworks^ inneighbor y.y.y.y prefix-list^ ournetworks^ outneighbor y.y.y.y maximum-prefix^120000 neighbor y.y.y.y route-map ourASpath^ out ip prefix-list ournetworks seq^5 permit^ x.x.x.x/yip prefix-list ournetworks seq^10 deny^ 0.0.0.0/0^ le^32 ip prefix-list theirnetworks seq^5 permit^ x.x.x.x/yip prefix-list protected-prefixes^ permit^ x.x.x.x/yip prefix-list ^ permit^ x.x.x.x/yip as-path access-list 99 permit^ ^(^ )*$route-map ourASpath permit 10 match as-path 99 route-map dampening-list deny^10 match ip address prefix-list^ protected-prefixesroute-map dampening-list permit^20 match ip address prefix-list^ <other^ prefix-list>set dampening <your dampening^ parameters>docsity.com

© 2002 Sécurité.Org^

BGP : Future (2) »^ Working Groups^ > IETF- rpsec (Routing Protocol Security Requirements)- ptomaine (Prefix Taxonomy Ongoing Measurement & InterNetwork Experiment)- msec (Multicast Security)> RIPE : Routing Working Group> IRTF : Group Security (GSEC, formerly Secure MulticastGroup)»^ Don’t forget router “host” security! »^ Forensics (who used to announce which prefix)^ > Route information stored inside DBs at large peering pointsor by large providers

docsity.com

© 2002 Sécurité.Org^

OSPF : Protocol description »^ OSPF (Open Shortest Path First)^ > Protocol type 89> Multicast traffic : “easy” to inject LSAs (Link StateAdvertisement)> Active adjacencies between all the routers and the (B)DRs(DR/BDR status is based on Router ID and priority)> SPF (Shortest Path First) recalculation takes time and CPU

Area 2 Backup DesignatedRouter (BDR)Designated Router(DR) Backbone area (Area 0)Network runningArea 1another IGP Area Border Router(ABR) Autonomous SystemBorder Router(ASBR)
