Lecture 7
CS2110 – Fall 2008
Grammars & Parsing
2
Java Tips
! Declare fields and methods public if they are to be visible outside the class; helper methods and private data should be declared private ! Constants that will never be changed should be declared final ! Public classes should appear in a file of the same name ! Two kinds of boolean operators: " e1 & e2 : evaluate both and compute their conjunction " e1 && e2 : evaluate e1 ; don’t evaluate e2 unless necessary ! instead of if (s.equals("")) { f = true; } else { f = false; } write f = s.equals(""); ! instead of if (s.equals("")) { f = a; } else { f = b; } write f = s.equals("")? a : b; 3
Application of Recursion
! So far, we have discussed recursion on integers
" Factorial, fibonacci, combinations, an
! Let us now consider a new application that shows off
the full power of recursion: parsing
! Parsing has numerous applications: compilers, data
retrieval, data mining,…
4
Motivation
The cat ate the rat. The cat ate the rat slowly. The small cat ate the big rat slowly. The small cat ate the big rat on the mat slowly. The small cat that sat in the hat ate the big rat on the mat slowly. The small cat that sat in the hat ate the big rat on the mat slowly, then got sick. … ! Not all sequences of words are legal sentences " The ate cat rat the ! How many legal sentences are there? ! How many legal programs are there? ! Are all Java programs that compile legal programs? ! How do we know what programs are legal? http://java.sun.com/docs/books/jls/third_edition/html/syntax.html
A Grammar
Sentence! Noun Verb Noun Noun! boys Noun! girls Noun! bunnies Verb! like Verb! see ! Our sample grammar has these rules: " A Sentence can be a Noun followed by a Verb followed by a Noun " A Noun can be ‘boys’ or ‘girls’ or ‘bunnies’ " A Verb can be ‘like’ or ‘see’ ! Grammar: set of rules for generating sentences in a language ! Examples of Sentence: " boys see bunnies " bunnies like girls " … ! White space between words does not matter ! The words boys, girls, bunnies, like, see are called tokens or terminals ! The words Sentence, Noun, Verb are called nonterminals ! This is a very boring grammar because the set of Sentences is finite (exactly 18 sentences)
A Recursive Grammar
Sentence! Sentence and Sentence Sentence! Sentence or Sentence Sentence! Noun Verb Noun Noun! boys Noun! girls Noun! bunnies Verb! like Verb! see ! This grammar is more interesting than the last one because the set of Sentences is infinite ! Examples of Sentences in this language: " boys like girls " boys like girls and girls like bunnies " boys like girls and girls like bunnies and girls like bunnies " boys like girls and girls like bunnies and girls like bunnies and girls like bunnies " ……… ! What makes this set infinite? Answer: " Recursive definition of Sentence
7
Detour
! What if we want to add a period at the end of every sentence?
Sentence! Sentence and Sentence.
Sentence! Sentence or Sentence.
Sentence! Noun Verb Noun.
Noun! …
! Does this work?
! No! This produces sentences like:
girls like boys. and boys like bunnies..
Sentence Sentence Sentence 8
Sentences with Periods
PunctuatedSentence! Sentence.
Sentence! Sentence and Sentence
Sentence! Sentence or Sentence
Sentence! Noun Verb Noun
Noun! boys
Noun! girls
Noun! bunnies
Verb! like
Verb! see
! Add a new rule that adds
a period only at the end of
the sentence.
! The tokens here are the 7
words plus the period (.)
! This grammar is
ambiguous:
boys like girls
and girls like boys
or girls like bunnies
9
Grammar for Simple Expressions
E! integer E! ( E + E ) ! Simple expressions: " An E can be an integer. " An E can be ‘(’ followed by an E followed by ‘+’ followed by an E followed by ‘)’ ! Set of expressions defined by this grammar is a recursively- defined set " Is language finite or infinite? " Do recursive grammars always yield infinite languages? ! Here are some legal expressions: " 2 " (3 + 34) " ((4+23) + 89) " ((89 + 23) + (23 + (34+12))) ! Here are some illegal expressions: " ( " 3 + 4 ! The tokens in this grammar are (, +, ), and any integer 10
Parsing
! Grammars can be used in two
ways
" A grammar defines a language (i.e., the set of properly structured sentences ) " A grammar can be used to parse a sentence (thus, checking if the sentence is in the language )
! To parse a sentence is to
build a parse tree
" This is much like diagramming a sentence
! Example: Show that
is a valid expression E by
building a parse tree
E
( E + E )
( E + E )
Recursive Descent Parsing
! Idea: Use the grammar to design a recursive program to check if a sentence is in the language ! To parse an expression E, for instance " We look for each terminal (i.e., each token ) " Each nonterminal (e.g., E) can handle itself by using a recursive call ! The grammar tells how to write the program! boolean parseE() { if (first token is an integer) return true; if (first token is ‘(‘ ) { parseE(); Make sure there is a ‘+’ token; parseE( ); Make sure there is a ‘)’ token; return true; } return false; } (^) 12
Java Code for Parsing E
public static Node parseE(Scanner scanner) { if (scanner.hasNextInt()) { int data = scanner.nextInt(); return new Node(data); } check(scanner, ’(’); left = parseE(scanner); check(scanner, ’+’); right = parseE(scanner); check(scanner, ’)’); return new Node(left, right); }
19
Using a Parser to Generate Code
! We can modify the parser so
that it generates stack code to
evaluate arithmetic
expressions:
2 PUSH 2
STOP
(2 + 3) PUSH 2
PUSH 3
ADD
STOP
! Goal: Method parseE should
return a string containing
stack code for expression it
has parsed
! Method parseE can generate
code in a recursive way:
" For integer i, it returns string “PUSH ” + i + “\n” " For (E1 + E2),
Recursive calls for E1 and E
return code strings c1 and c2, respectively
For (E1 + E2), return
c1 + c2 + “ADD\n” " Top-level method should tack on a STOP command after code received from parseE 20
Does Recursive Descent Always Work?
! There are some grammars
that cannot be used as the
basis for recursive descent
" A trivial example (causes infinite recursion):
S! b
S^!^ Sa
! Can rewrite grammar
S! b
S! bA
A! a
A! aA
! For some constructs,
recursive descent is hard to
use
" Can use a more powerful parsing technique (there are several, but not in this course) 21
Syntactic Ambiguity
! Sometimes a sentence has
more than one parse tree
S! A | aaxB A! x | aAb B! b | bB " The string aaxbb can be parsed in two ways
! This kind of ambiguity
sometimes shows up in
programming languages
if E1 then if E2 then S1 else S
Which then does the else go
with?
! This ambiguity actually affects
the program’s meaning
! How do we resolve this?
" Provide an extra non-grammar rule (e.g., the else goes with the closest if ) " Modify the language (e.g., an if-statement must end with a ‘fi’ ) " Operator precedence (e.g. 1 + 2 * 3 should always be parsed as 1 + (2 * 3), not (1 + 2) * 3 " Other methods (e.g., Python uses amount of indentation) 22
Conclusion
! Recursion is a very powerful technique for writing
compact programs that do complex things
! Common mistakes:
" Incorrect or missing base cases
" Subproblems must be simpler than top-level problem
! Try to write description of recursive algorithm and
reason about base cases before writing code
" Why?
Syntactic junk such as type declarations, etc. can create mental
fog that obscures the underlying recursive algorithm
" Best to separate the logic of the program from coding details
Exercises
! Think about recursive calls made to parse and
generate code for simple expressions
! Derive an expression for the total number of calls
made to parseE for parsing an expression
" Hint: think inductively
! Derive an expression for the maximum number of
recursive calls that are active at any time during the
parsing of an expression (i.e. max depth of call stack)
Exercises
! Write a grammar and recursive program for palindromes
" mom " dad " i prefer pi " race car " murder for a jar of red rum " sex at noon taxes
! Write a grammar and recursive program for strings AnBn
" AB
" AABB
" AAAAAAABBBBBBB
! Write a grammar and recursive program for Java identifiers
" [ or ]0…N " j27, but not 2j
