15-410, F’

Hardware Overview

Sep. 4, 2013

Dave Eckhardt

Dave Eckhardt

Todd Mowry

Todd Mowry

L04_Hardware

“Computers make very fast, very accurate mistakes.”

--Brandon Long

15-410, F’

Synchronization

Partner signups

Partner signups



~12 group signups so far – thanks!



Please sign up as soon as you decide!



This helps other students



Both partners please sign up!



This helps course staff detect “love triangles”

15-410, F’

Synchronization

Personal Simics licenses

Personal Simics licenses



Simics machine-simulator software is licensed



We have enough “seats” for the class



Should work on most CMU-network machines



Will not work on most non-CMU-network

machines



CMU operates a VPN server for off-campus users

»

http://www.cmu.edu/computing/network/vpn

»

There is an open-source alternative (OpenConnect)

• It used to not work with the campus server
• Recently rumor has it that it does

15-410, F’

Synchronization

Simics on Windows?

Simics on Windows?



Simics simulator itself is available for Windows



15-410 build/debug infrastructure is not



Can be hacked up, issues may arise

»

Version skew, partner, ...

Options

Options



Dual-boot Linux/Windows, run Linux in VMware



Usability via X depends on network latency



May be too slow – though we are experimenting



Port to cygwin (may be non-trivial)



There are some cluster machines...



WeH 5207, GHC 3000, GHC 5201/

15-410, F’

Inside The Box - Historical/Logical

CPU

Memory

Graphics

Ethernet

IDE

Floppy

USB

15-410, F’

Inside The Box - 1997-

CPU

Memory

AGP Graphics

IDE

Floppy

USB

North Bridge

South Bridge

P

C

I

Ethernet

SCSI

15-410, F’

CPU State

User registers (on Planet IA32)

User registers (on Planet IA32)



General purpose - %eax, %ebx, %ecx, %edx



Stack Pointer - %esp



Frame Pointer - %ebp



Mysterious String Registers - %esi, %edi

15-410, F’

CPU State

Non-user

Non-user registers, a.k.a....

registers, a.k.a....

Processor status register(s)

Processor status register(s)



Currently running: user code / kernel code?



Interrupts on / off



Virtual memory on / off



Memory model



small, medium, large, purple, dinosaur

15-410, F’

Story time!

Time for some fairy tales

Time for some fairy tales



The getpid() story (shortest legal fairy tale)



The read() story (toddler version)



The read() story (grade-school version)

15-410, F’

The Story of getpid()

User process is computing

User process is computing



User process calls getpid() library routine



Library routine executes TRAP $



In Intel-land, TRAP is called “ INT ” (because it

isn't one)

REMEMBER: “ INT ” is not an interrupt

The world changes

The world changes



Some registers dumped into memory somewhere



Some registers loaded from memory somewhere

The processor has

The processor has entered kernel mode

entered kernel mode

15-410, F’

Entering Kernel Mode

Operating

System

Process 1

Process 2

CPU

save

15-410, F’

Entering Kernel Mode

Operating

System

Process 1

Process 2

CPU

Ethernet

SATA

Floppy

USB

15-410, F’

The Story of getpid()

Process runs in kernel mode

Process runs in kernel mode



running->u_reg[R_EAX] = running->u_pid;

Return from interrupt”

Return from interrupt”



Processor state restored to user mode



(modulo %eax)

User process returns to computing

User process returns to computing

 Library routine returns %eax as value of getpid()

15-410, F’

Returning to User Mode

Operating

System

Process 1

Process 2

CPU

restore
