Acknowledgements
In the outset, we want to thank Prof. J.V. Rao for giving us this opportunity to familiarize practically with Object oriented system analysis and design through this project. His ample guidance and suggestions were invaluable in the successful completion of this project. Also, we thank BITS Pilani Goa Campus for giving us all the necessary resources and also including this course as an elective. Also we extend our gratitude to anyone who has directly or indirectly helped in this project.
Overview
This project is concerned with developing a flexible, open-ended design for hotel management information system that incorporates well-known design patterns and a lucid design style using UML diagrams. Our Hotel Management System consists of two users:
Customers can avail various services provided by the hotel like room reservation, restaurant, sauna, pool, casino etc. The system keeps a record of the customer details and previous visits of current and past customers so that privileges and points can be awarded based on their history. To keep the system history database to acceptable levels of data, excessive records are automatically purged at regular intervals. A Customer’s history consists of his/her previous visits, only one of which can be active (not completed) at any point in time. If no visits are active, then a new visit instance need to be created that can contain the various services that the customer need to avail during a new visit. If a visit instance is active, then any services availed are considered as part of that visit. Each visit is a composition of services that the customer uses. Any particular service usage consists of a single resource (e.g. Room No 110) that belongs to a particular service (e.g. Room Service). When a customer requests a resource, the system checks for that availability of the resource and adds that resource to the list of availed services during that visit. At the end of the visit, when all the service usages are finished, system automatically calculates the cost of the visit and also any points that need to be awarded based on this visit is computed as well. The customer has provision to redeem any in-house points that the customer has been awarded.
Manager(s) is (are) concerned with the overall functioning of the system. He/she has the provision to add new services or resources for any particular service. The system keeps track of the expenditure incurred by the various services which can be viewed by the manager. The manager’s decision making can be assisted based on the various service’s usage, total expenditure, total income etc., all of which the system automatically keep track of.
Class Descriptions
Class Name Attribute/Method Description Customer name Customer/Company Name addr Customer/Company Address cust_class Bit Vector to determine whether a particular resource can be assigned to this customer calc_history_pts() Abstract method for calculating in-house points awarded based on history. Part of interface Awardable. notify() Notifies the point object contained in the customer to update the history points. Part of Observer interface Individual_cust dob Date Of Birth of the customer Company_cust manager Manager’s name of the company Point redeemed_pts Total points that the customer has used so far history_pts Total points that the customer has been awarded based on history awardee Awardable (Customer) object that implements the calc_history_pts() method part of Awardable interface redeem_pts(pts) Avail Points. Call with negative argument to award points. update_pts() Update the history points by calling the calc_history_pts() method implemented by the awardee History history_count Static attribute that determines the number of persistent records to be stored. prune_interval Interval in which excessive records are removed (greater than history_count) visits_no Total number of visits so far prev_expenditure Total expenditure by the customer for records that has been removed so far total_expenditure Total expenditure so far latest_visit The latest visit object part of the history pruner Timer class object that removes
completed update_status() Sets the completion_status if all the services have been completed attach_usage(usage) Attaches a new service usage to the list detach_usage(usage,penalty) Removes a service usage if it has not been yet completed and adds the penalty for cancellation Service_Usage usage_resource The resource been used update_status() Sets the completion status, updates the cost and call the notify() method notify() Notifies the visit object to update its expenditure and carry on the notification to upper levels. The resource been used is then freed. calc_cost() Calculate the total cost incurred for using the resource find_resource(subtype,value = NONE)
Find a free resource for the customer. Subtype argement represent a particular type of resource that customer want. Value argument is used when a specific resource is required by the customer resource_cleanup() Free the reource Service name Name of the service. It matches the service name of all the resources contained in the service run_cost_calc_interval The interval in which the run cost is calculated by calling the action_performed() method part of Action_Listener interface total_run_cost Total run cost for the service so far expense_keeper Timer class for keeping the expense find_resource(class,subtype, value,start date,end date)
Finds a free resource that can be assigned to the customer belonging to a particular class matching the subtype and value (if any) that does not interfere with the required start and end dates for usage. free_resource(resource) Removes the resource from usage_list
add_resource(resource) Adds a new resource. remove_resource(id) Remove a resouce Resource id Unique ID service_name Name of the service that this resource Is part of value Specific value/name subtype The general category to which this reource belong cust_class The Class of customer to which this resource can be assigned calc_cost(duration) Abstract method to calculate the cost for the resource based on duration clean_up() Resets any resource specific attributes. Called when a resource is freed after usage resource_idle_cost(duration) Expense incurred by the hotel when resource Is idle for a duration of time resource_run_cost(duration) Expense incurred by the hotel when resource Is used for a duration of time Service_Manager add_service(service) Adds a new service rem_service(service) Remove an existing service find_service(name) Finds a service based on name calc_service_cur_usage(name) Calculate the percentage current usage for a particular service calc_total_run_cost() Total run cost incurred by all the services in the system
Sequence Diagrams
Sequence Diagrams
For e.g. A Muti-user operating system environment where resources can be in the form of shared resources like printer, storage, CPU time etc. and users are awarded points for their greater use of the system.
