The LLVM Compiler Framework

and Infrastructure

(Part 1)

Presented by Gennady Pekhimenko Substantial portions courtesy of Olatunji Ruwase, Chris Lattner, Vikram Adve, and David Koes

LLVM Compiler System

 The LLVM Compiler Infrastructure

 Provides reusable components for building compilers

 Reduce the time/cost to build a new compiler

 Build static compilers, JITs, trace-based optimizers, ...

 The LLVM Compiler Framework

 End-to-end compilers using the LLVM infrastructure

 C and C++ are robust and aggressive:

 Java, Scheme and others are in development

 Emit C code or native code for X86, Sparc, PowerPC

Tutorial Overview

 Introduction to the running example

 LLVM C/C++ Compiler Overview

 High-level view of an example LLVM compiler

 The LLVM Virtual Instruction Set

 IR overview and type-system

 The Pass Manager

 Important LLVM Tools

 opt, code generator, JIT, test suite, bugpoint

 Assignment Overview

Running example: arg promotion

Consider use of by-reference parameters:

int callee(const int &X) {

return X+1;

int caller() {

return callee(4);

int callee(const int *X) {

return *X+1; // memory load

int caller() {

int tmp; // stack object

tmp = 4; // memory store

return callee(&tmp);

compiles to

 Eliminated load in callee

 Eliminated store in caller

 Eliminated stack slot for ‘tmp’

int callee(int X) {

return X+1;

int caller() {

return callee(4);

We want:

Tutorial Overview

 Introduction to the running example

 LLVM C/C++ Compiler Overview

 High-level view of an example LLVM compiler

 The LLVM Virtual Instruction Set

 IR overview and type-system

 The Pass Manager

 Important LLVM Tools

 opt, code generator, JIT, test suite, bugpoint

 Assignment Overview

The LLVM C/C++ Compiler

 From the high level, it is a standard compiler:

 Compatible with standard makefiles

 Uses GCC 4.2 C and C++ parser

 Distinguishing features:

 Uses LLVM optimizers, not GCC optimizers

 .o files contain LLVM IR/bytecode, not machine code

 Executable can be bytecode (JIT’d) or machine code

llvmg++ -emit-llvm

C file llvmgcc -emit-llvm

C++ file

.o file

.o file

llvm linker executable

Compile Time Link Time

Looking into events at link-time

.o file

.o file

llvm linker executable

Native Code Backend Native executable

“llc” C Code Backend

C Compiler Native executable “llc –march=c” NOTE: Produces very ugly C. Officially deprecated, but still works fairly well.

“gcc”

Link in native .o files and libraries here

LLVM

Linker

Link-time Optimizer .bc file for LLVM JIT

.o file

.o file

20 LLVM Analysis & Optimization Passes

Optionally “internalizes”: marks most functions as internal, to improve IPO

Perfect place for argument promotion optimization! 10

Goals of the compiler design

 Analyze and optimize as early as possible:

 Compile-time opts reduce modify-rebuild-execute cycle

 Compile-time optimizations reduce work at link-time

(by shrinking the program)

 All IPA/IPO make an open-world assumption

 Thus, they all work on libraries and at compile-time

 “Internalize” pass enables “whole program” optzn

 One IR (without lowering) for analysis & optzn

 Compile-time optzns can be run at link-time too!

 The same IR is used as input to the JIT

IR design is the key to these goals!

Goals of LLVM IR

 Easy to produce, understand, and define!

 Language- and Target-Independent

 AST-level IR (e.g. ANDF, UNCOL) is not very feasible

 Every analysis/xform must know about ‘all’ languages

 One IR for analysis and optimization

 IR must be able to support aggressive IPO, loop opts,

scalar opts, … high- and low-level optimization!

 Optimize as much as early as possible

 Can’t postpone everything until link or runtime

 No lowering in the IR!

LLVM Instruction Set Overview

 Low-level and target-independent semantics

 RISC-like three address code

 Infinite virtual register set in SSA form

 Simple, low-level control flow constructs

 Load/store instructions with typed-pointers

 IR has text, binary, and in-memory forms

for (i = 0; i < N;

++i) Sum(&A[i], &P);

loop: ; preds = %bb0, %loop %i.1 = phi i32 [ 0, %bb0 ], [ %i.2, %loop ] %AiAddr = getelementptr float %A, i32 %i. call void @Sum(float %AiAddr, %pair %P) %i.2 = add i32 %i.1, 1 %exitcond = icmp eq i32 %i.1, %N br i1 %exitcond, label %outloop, label %loop** 14

LLVM Type System Details

 The entire type system consists of:

 Primitives: label, void, float, integer, …

 Arbitrary bitwidth integers (i1, i32, i64)

 Derived: pointer, array, structure, function

 No high-level types: type-system is language neutral!

 Type system allows arbitrary casts:

 Allows expressing weakly-typed languages, like C

 Front-ends can implement safe languages

 Also easy to define a type-safe subset of LLVM

See also: docs/LangRef.html

Lowering source-level types to LLVM

 Source language types are lowered:

 Rich type systems expanded to simple type system

 Implicit & abstract types are made explicit & concrete

 Examples of lowering:

 References turn into pointers: T&  T*

 Complex numbers: complex float  { float, float }

 Bitfields: struct X { int Y:4; int Z:2; }  { i32 }

 Inheritance: class T : S { int X; }  { S, i32 }

 Methods: class T { void foo(); }  void foo(T)*

 Same idea as lowering to machine code

Our example, compiled to LLVM

int callee(const int *X) {

return *X+1; // load

int caller() {

int T; // on stack

T = 4; // store

return callee(&T);

internal int %callee(int* %X) {

%tmp.1 = load int* %X

%tmp.2 = add int %tmp.1, 1

ret int %tmp.

int %caller() {

%T = alloca int

store int 4, int* %T

%tmp.3 = call int %callee(int* %T)

ret int %tmp.

Stack allocation is

explicit in LLVM

All loads/stores are

explicit in the LLVM

representation

Linker “internalizes”

most functions in most

cases

Our example, desired transformation

internal int %callee(int %X.val) {

%tmp.2 = add int %X.val, 1

ret int %tmp.

int %caller() {

%T = alloca int

store int 4, int* %T

%tmp.1 = load int %T*

%tmp.3 = call int %callee(%tmp.1)

ret int %tmp.

internal int %callee(int* %X) {

%tmp.1 = load int* %X

%tmp.2 = add int %tmp.1, 1

ret int %tmp.

int %caller() {

%T = alloca int

store int 4, int* %T

%tmp.3 = call int %callee(int* %T)

ret int %tmp.

Change the prototype

for the function

Insert load instructions

into all callers

Update all call sites of

‘callee’

Other transformation

(-mem2reg) cleans up

the rest

int %caller() {

%tmp.3 = call int %callee(int 4)

ret int %tmp.
