ENGR 2170 – Laboratory 1
Name: _________________________ ID: ___________________________
Objective: Write the objective of this experiment …. (5 points)
Equipment: Write a list of the equipment used for this lab. (5 points)
1. Resistor
2. Abc
3. Multisim
4. etc
Exercise 1: (20points)
i. Insert the screenshot of the breadboard connection and multi-sim for the Circuit if applicable
ii. Solve 1 & 2
Exercise 2 & 3 : (40 points)
i. Insert the screenshot of the breadboard connection and multi-sim for the Circuit if applicable
ii. Follow the instructions and complete the tables
Discussion (15 points)
You must include …
• High-level description of your experiment.
• A description of what experiment you did, with the detail that a classmate could repeat it from only what
you wrote down.
• Data resulting from your experiment.
• Interpretation of your results.
Feedback section (15 points)
Answering the following two questions:
– What was good about this lab and should be retained and magnified in future revisions?
– What was frustrating or confusing about this lab and needs to be reduced or changed in future
revisions?
– After doing the lab, what is your confidence in your ability to do lab objectives (1 = not confident at
all, 10 = certain I can do it), and in one or two sentences, what helped you build your confidence?
(Please submit in pdf)
For every lab, you can follow this pattern if we don’t upload any new instructions.
