Lecture 6

distributed mutual exclusion

distributed systems

CS425 / ECE 428 / CSE 424

sayan mitra

acknowledgment

these slides are based on ideas and material from the following sources:

• slides prepared by professors m. t. harandi and j. hou and subsequently modified by professors indranil gupta, nitin vaidya, and yih-chun hu at university of illinois
• slides from professor s. ghosh’s course at university of iowa

why mutual exclusion?

• bank database: think of two simultaneous

deposits of $10,000 into your bank account from

2 ATMs.

• both ATMs read initial amount of $1000 concurrently

from the bank server

• both ATM add $10,000 to this amount (locally at the

ATM)

• both write the final amount to the server
• what’s wrong?

• ATMs need mutually exclusive access to your

account entry at the server (or, to executing the

code that modifies the account entry)

 critical section problem : piece of code (at all clients) for

which we need to ensure there is at most one client

executing it at any point of time.

 solutions:

 semaphores, mutexes, locks, etc. in local operating systems

 message-passing-based protocols in distributed systems:

 enter() the critical section

 accessresource() in the critical section

 exit() the critical section

 distributed mutual exclusion requirements:

 safety – at most one process may execute in cs at any time

 liveness – every request for a cs is eventually granted

 fairness/ordering (desirable) – requests are granted in

FIFO order

mutual exclusion

refresher - semaphores

• to synchronize access of multiple threads to common

data structures

• semaphore is a protected variable with two operations
• init: semaphore s=1;
• wait(s):

while(true) {if (s > 0) then s := s-1; break} // each execution of loop is atomic

• signal(s):

s++; // atomic operation

refresher - semaphores

• to synchronize access of multiple threads to common

data structures

• semaphore is a protected variable with two operations
• init: semaphore s=1;
• wait(s):

while(true) {if (s > 0) then s := s-1; break} // each execution of loop is atomic

• signal(s):

s++; // atomic operation

enter()

exit()

distributed ME: performance criteria

• bandwidth : the total number of messages sent in each entry and exit operation.
• delay
  • client delay : the delay incurred by a process at each entry and exit operation (when no other process is waiting)
  • synchronization delay : the time interval between one process exiting the critical section and the next process entering it (when there is only one process waiting)
• these translate into throughput -- the rate at which the processes can access the critical section, i.e., x processes per second.

(these definitions more correct than the ones in the textbook)

assumptions

• for all the algorithms studied, we assume

• reliable FIFO channels between every process pair i.e., messages from i are eventually delivered to j’s input buffer in FIFO order
• processes do not fail.

 operations ( token gives access to CS)

 to enter a CS

send a request to the L & wait for token

 on exiting the CS

send a message to L to release the token

 upon receipt of a request

if no other process has the token, L replies with the token; otherwise, L queues the request

 upon receipt of a release message

L removes oldest entry in the queue (if any) replies with token  features:

 safety, liveness, order are guaranteed

 it takes 3 messages per (entry + exit) operation

 client delay: one round trip time (request + grant)

 synchronization delay: one round trip time (release + grant)

 coordinator : performance bottleneck and single point of failure

centralized control of mutual exclusion

 processes are organized in a logical unidirectional ring

pi has a communication channel to p(i+1)mod (n+1).

 operations:

 only the process holding the token can enter the CS

 to enter CS wait for the token

 to exit the CS (or relinquish opportunity) pi sends token to

p(i+1)mod (n+1)

token ring approach

P

P

P P

Pn

Previous holder of token

next holder of token

current holder of token

 features:

 safety & liveness are guaranteed, but ordering is not  bandwidth: 1 message per exit  client delay: 0 to (N+1) message transmissions  synchronization delay between one process’s exit from the CS and the next process’s entry is between 1 and N message transmissions.

Ricart and Agrawala’s algorithm

On initialization status := RELEASED; To enter the section status := WANTED; Multicast request to all processes; T := request’s timestamp; Wait until (number of replies received = (N – 1)); state := HELD;

On receipt of a request <Ti, pi> at pj (i ≠ j) if (status = HELD or (status = WANTED and (T, pj) < (Ti, pi))) then queue request from pi without replying; else reply immediately to pi; end if To exit the critical section state := RELEASED; reply to any queued requests;

request processing deferred here

Ricart and Agrawala’s algorithm

p 3

Reply

p 1

p 2

Reply Reply

timestamp approach: Maekawa’s algorithm

 multicasts messages to a (voting) subset of nodes

 each process pi is associated with a voting set vi (of processes)

 each process i belongs to its own voting set vi

 the intersection of any two voting sets is not empty

 each voting set is of size k

 each process belongs to m other voting sets

 to access at resource , pi requests permission from all other

processes in its own voting set vi

 guarantees safety, not liveness (may deadlock)

 Maekawa showed that k=m=n works best

 one way of doing this is to put nodes in a n by n matrix and

take the union of row & column containing pi as its voting set

Maekawa’s algorithm – part 1

On initialization status := RELEASED; voted := FALSE; For pi to enter the critical section status := WANTED; Multicast request to all processes in Vi – {pi}; Wait until (number of replies received = (K – 1)); state := HELD; On receipt of a request from pi at pj (i ≠ j) if (state = HELD or voted = TRUE) then queue request from pi without replying; else send reply to pi; voted := TRUE; end if
