Statistics 431:

Statistical Inference

Lecture 17: Linear regression diagnostics and

variable transformations

Regression diagnostics

• (^) The conditions required for inference from simple linear regression must be

checked:

• (^) Linearity. Diagnostic: residual plot.
• (^) Constant variance. Diagnostic: residual plot.
• (^) Normality. Diagnostics:
  • histogram of residuals.
  • normal quantile plot of residuals.
• (^) Independence. Diagnostic: residual plot.
• (^) Outliers and influential points. Diagnostic: scatterplot, Cook’s distances.

Bivariate Fit of HousePrice By CrimeRate

HousePrice

CrimeRate

Summary of Fit

Residual

Distri

Resid

3

CrimeRate

Summary of Fit

RSquare 0.

RSquare Adj 0.

Root Mean Square Error 78861.

Mean of Response 158464.

Observations (or Sum Wgts) 98

Parameter Estimates

Term Estimate Std Error t Ratio Prob>|t|

Intercept 225233.55 16404.02 13.73 <.

CrimeRate -2288.689 491.5375 -4.66 <.

Residual plots

• (^) A residual plot is a scatterplot of each residual ei vs its corresponding xi.
• (^) A residual plot can suggest nonlinearity and/or non-constant variance, both

violations of the assumptions in the ideal linear model.

• (^) If the ideal model holds, the residual plot should contain patternless scatter.
• (^) The residuals should be centered around a horizontal line at 0. A nonlinear

regression function μ( x ) will lead to a violation of this constraint. For example, the residuals on the left and right might be generally above zero, and those in the middle generally below zero.

• (^) The residuals should have the same spread around zero, at all x values. If,

for example, the residual plot has a “bulge” in the model, the constant-variance assumption has been violated.

• (^) Look for pronounced patterns. No residual plot will satisfy you as being

“perfectly” patternless (not even when we do a regression on data simulated from the ideal linear model!).

0

100000

200000

300000

Residual

10 20 30 40 50 60 70 CrimeRate

Distributions

Residuals HousePrice

• (^) Some evidence of upwards curvature in the average residuals at the low and high end of crime rate.

DisplayFeet

0

100

Residual

0 1 2 3 4 5 6 7 8

DisplayFeet

Residual plot shows mean residual less

1 and 7 display feet and greater than ze

• (^) The residual plot shows negative mean residuals at 1 foot and 7 feet, and positive mean residuals elsewhere.
• (^) What does this indicate?

Examining and Transforming Data Tukey’s bulging rule

Figure 15. Mosteller and Tukey’s bulging rule for selecting linearizing trans ormations.

10

Display effect: Transformations to

x

0

100

200

300

400

Sales

0 1 2 3 4 5 6 7 8 DisplayFeet

0

50 Residual

0 1 2 3 4 5 6 7 8 DisplayFeet

• (^) Still looks like overestimation at 1 foot and underestimation at 2–3 feet.

Display effect: Transformations to log x

0

100

200

300

400

Sales

0 1 2 3 4 5 6 7 8 DisplayFeet

0

50

100

Residual

0 1 2 3 4 5 6 7 8 DisplayFeet

• (^) This is a slight improvement.

Heteroscedasticity

• (^) You may have already forgotten that the ideal linear model assumes all the

distrns Y | X = x have the same variance σ 2. This is homoscedasticity.

• (^) When this assumption is violated, we have non-constant variances, or

heteroscedasticity.

• (^) To detect non-constant variance, look at the residual plot. If the vertical

spread of residuals is not the same from left to right, the constant variance assumption is in trouble. E.g.,

• “Fan pattern”: spread increases from left to right
• “Inverse fan pattern”: spread decreases from left to right
• (^) Consequences of heteroscedasticity:
• Hypothesis tests and confidence intervals for β’s are misspecified.
• But, least-squares estimates ( βˆ 0 , βˆ 1 ) are still unbiased.
• (^) What to do: try transformations of Y.

Another residual plot

• (^) We can plot residuals ei against their corresponding fitted values y ˆ i , rather

than against xi.

• (^) For simple linear regression, this is just an affine transformation of X (to

β^ ˆ 0 + ˆβ 1 X ): it moves the whole residual cloud up or down, and stretches the x axis, but doesn’t change the conclusions we draw.

• (^) However, it is useful in multiple linear regression, when there are many X

variables to choose from.

Heteroscedasticity

• When the requirement of a constant variance is

violated we have a condition of heteroscedasticity.

• (^) + (^) +

• (^) +

The spread increases with y^

y^

Residual

^y

++

+^ +

+^ ++

Display effect example

0

50

100

Residual

0 1 2 3 4 5 6 7 8 DisplayFeet

Distributions Residuals Sales

-50 0 50 100

No strong indication of violation of constant variance or

normality assumptions.

• (^) Nothing strongly suggests heteroscedasticity or departure from normality.

Residual plots vs time

• (^) A confounder is a variable that is not included among the covariates in a

study but influences both the covariates and the response.

• (^) Plots of the residuals versus the temporal or spatial order of observation

can reveal

• serial correlation (violation of independence)
• confounding variables associated with time and space (multiple regression can be used to account for these variables).
• (^) Example: the math department at a university must plan for the number of

instructors in large service courses. The goal is to predict enrollment in such courses Y based on number of first-year students X.
