CSCI-1200 Computer Science II — Fall 2008
Lab 7 — List Implementation
Introduction
This lab gives you practice in working with our implementation of the cs2list class that mimics the STL
list class. Create a directory/folder named lab7 and download these files into that folder:
http://www.cs.rpi.edu/academics/courses/fall08/cs2/labs/07_list_implementation/cs2list.h
http://www.cs.rpi.edu/academics/courses/fall08/cs2/labs/07_list_implementation/code.cpp
Checkpoint 1
The implementation of the cs2list class is incomplete. In particular, the class is missing the destroy_list
private member function that is used by the destructor and the clear member function. The provided
test case in test_cs2list.cpp works “fine”, so what’s the problem?
Before we fix the problem, let’s use the memory debugger Valgrind (http://valgrind.org) to look at
the details more carefully. Valgrind is available for free on Linux (but unfortunately not Windows!) If
you don’t have Linux, or if you don’t have Valgrind installed yet, don’t fear. We’ve setup a homework
submission site for this lab to let you run Valgrind remotely. Zip up the 2 original files just like you
would a homework assignment (in a directory named “lab7”, etc.). Submit the assignment and look at
the Valgrind output. The output should match your understanding of the problems caused by the missing
destroy_list implementation. Ask a TA if you have any questions. To run Valgrind on your own linux
machine, first compile the executable (e.g., to a.out), and then type this:
valgrind --leak-check=yes --show-reachable=yes a.out
Now write and debug the destroy_list function and then re-run Valgrind to show that the memory
problems have been fixed. Note that cout statements may cause additional messages about memory that
don’t directly refer to your code. It has to do with advanced memory allocation techniques that are used
by STL. You may ignore those messages.
To complete this checkpoint and the entire lab, show a TA the implementation and Valgrind output.
Checkpoint 2
One subtle difference between the STL list implementation and our version of the cs2list class is the
behavior of the iterator that represents the end of the list (the value returned by end()). In STL you may
decrement the end iterator. For example:
std::list<int>::iterator itr2 = b.end();
while (itr2 != b.begin()) {
itr--;
cout << *itr2;
}
The syntax is admittedly rather awkward, that’s why we would typically rely on reverse iterators to do
this task. How does the cs2list class behave on a corresponding test case? Try it out. How could you fix
the implementation so that it more closely matches the behavior of the STL version? There are a couple
different options... If you can’t come up with one quickly, please raise your hand and ask a TA. Make the
necessary changes to the implementation and test out your solution.
To complete this checkpoint and the entire lab, describe to a TA how you changed the implemen-
tation to allow the end iterator to be decremented.
