IFE (^) Course In Computer Architecture Slide 1 With respect to the way of data access we can classify memories as:
Random access memory - the access time to any piece of data is independent to the physical location of data. Access time is constant. Random access memories can be further classified as:
Dynamic random access memories (DRAM) - each one-bit memory cell uses a capacitor for data storage. Since capacitors leak there is a need to refresh the contents of memory periodically (usually once in ฯ=0,5 รท 2 ms). Memory cell for dynamic random access memory* Both read and write operations require to open the transistor by providing high voltage on line SEL. The bit of data to be written must be given at line IN/OUT. During reading operation the bit of data is available at the same line. Pros and Cons:
Programmable read only memories (PROM) - are programmed during manufacturing process. The contents of each memory cell is locked by a fuse or antifuse (diodes). PROMs are used for permanent data storage. Erasable read only memories (EPROM) - there is a possibility to erase EPROM with ultraviolet light (about 20 minutes) what sets all bits in memory cells to 1. Programming requires higher voltage. Memory cells are built with floating gate transistors. Data can be stored in EPROMs for about 10 years. Electrically erasable read only memories (EEPROM) - erasing does not require ultraviolet light but higher voltage and can be applied not to the whole circuit but to each memory cell separately. *Source of images: Wikipedia. Example of EPROM chip with glass window admitting UV light
Content addressable memories (CAM) - also known as associative memories; it is a type of computer memory used in applications requiring high speed searching. Such memory replies with โhitโ or โlack-of-hitโ status when some data vector (pattern) is given at its input. Searching consists in comparing of all data words stored in memory with the given pattern. The mask word indicating all essential bits also must be taken under consideration. If search finishes with hit one of the compliant words is copied to the output buffer. Which word it is determined by the multiply match resolver (MMR). Source of image: J. Biernat, โ Computer Architecture โ, OWPW, Wroclaw, 2005. Logical structure of an associative memory
Applications of CAMs:
Physical organisation of disks: head - corresponds with one side of a platter; track - circular area on platter where data is stored; sector - a fragment of track that is the smallest portion of data to be read or written on disk; cylinder - a set of tracks with the same number belonging to different platters. disk_capacity = number_of_headsnumber_of_tracksnumber_of_sectors*512 [B] Physical organisation of a disk
S (BOT) - 11 bytes 00h, D1 โ 0A1FCh, Z1 โ 12 bytes 0FFh, S โ 10 bytes 00h, D3 โ 5EA1h, ID โ sector address ID: byte 1 โ track number, byte 2 โ head number, byte 3 โ sector number, byte 4 โ sector status (invalid sector, sector replacement in spare area), ECC-1, 2 โ byte of error correction code (correction up to 11 errors), Z2 โ 5 bytes 00h, D4 โ 5EA1h, DATA โ 512 bytes, Z3 โ 3 bytes 00h and 17 bytes 0FFh, Z4 โ about. 93 bytes 00h. Structure of a disk track
RLL data recording technique Run Length Limited (RLL) is a technique applied to data recording on magnetic disks. Each input byte is divided into parts, i.e. chains of bits, that obtain their new bit chain representatives. Such sequences of bits are written on a magnetic layer. Bits with value of 1 correspond with a change in direction of a magnetic field. Example: 10011011 -> (10) + (011) + (011) -> (0100) + (001000) + (001000)
CD-ROMs In compact disks for data storage one spiral track is used. Data is stored on the disc as the series of microscopic indentations (โpitsโ) that cause destructive interference of laser light resulting in reduction of intensity of the reflected beam. The linear data density is constant what means that the linear rotational speed of the disk is linear. Such approach requires more complicated reading/writing circuits. The track is divided into sectors each storing 2352 bytes. First 12 bytes contain synchronisation data and next four a sector header. The following 2kB are predestined for user data storage and immediately behind we have: 4 bytes of CRC codes, 8 bytes filled with zeros and 278 bytes of ECCs. pit land land pit land 0000000010000000010000000000000000000010001000000 Laser structure* *Source of image: Wikipedia.
