Modeling Gravity Data
•Gravity data suffers from the same caveats as most geophysical
techniques
–Modeling data is an inverse problem, so results are non-unique
•You can calculate the predicted anomaly
from a known body exactly
•You cannot calculate the exact body
from the anomaly
–Data quality is limiting (noise, correction errors)
Docsity.com
pf3
pf4
pf5

Partial preview of the text

Download Modeling Gravity Data: Understanding Non-Uniqueness and Depth Rules and more Slides Geology in PDF only on Docsity!

Modeling Gravity Data

  • Gravity data suffers from the same caveats as most geophysical

techniques

  • Modeling data is an inverse problem, so results are non-unique
    • You can calculate the predicted anomaly from a known body exactly
    • You cannot calculate the exact body from the anomaly
  • Data quality is limiting (noise, correction errors)

Modeling Gravity Data

  • Recall that only the density contrast matters
    • So a half slab = 3.0 g/cm^3 embedded in a rock of 2.9 g/cm^3
    • Produces same anomaly as
    • Half slab = 2.7 g/cm^3 embedded in a rock of 2.6 g/cm^3
  • Also, a mass excess can produce the same anomaly as a mass

deficiency

  • To resolve the likely scenario, know the local geology!

While modeling gravity data suffers from non-uniqueness…

  • Total excess mass can be uniquely calculated
    • Must be very careful with calculating the tails
      • Tails are low in magnitude, but can extend very far
    • To calculate the mass of the body…

Total Excess Mass

excess Vanomaly G

M

body surrounding rock

body Mbody Mexcess

distance (m)

0 100 200 300 400 500

anomaly (mGals)

0

Useful if you want to know the total mass of an ore body
