Introduction

 Calcium electrowinning has been performed in a 5 – 10 wt% calcium oxide–calcium chloride molten salt by electrolytic dissociation of calcium oxide.

 This electrolysis requires the use of a porous ceramic sheath around the anode to keep the cathodically deposited calcium and the anodic gases separate.

 Stainless steel cathode and graphite anode have been used in the temperature range of 850–950°C.

Molten Salt Processing

4

 Molten salt processing provides a unique opportunity to process and produce metals where gas-based pyro- reduction, metallothermic reduction, hydrometallurgical methods or aqueous electrochemical techniques are not feasible due to thermodynamic or kinetic constraints.

 High temperature carbothermic or metallothermic smelting reduction methods for metal production are associated with the generation of significant quantity of waste as slags.

 Molten salt processing is intended to have low waste or ideally a ‘zero-waste’ generation.

Electrochemical Principle

 The principles employed here are similar to the Hall cell for aluminum production but the aluminum process is essentially restricted by the solubility of alumina in cryolite.

 Calcium has 4–6 atomic % solubility in the salt depending on the composition and temperature

 A molten flux electrolyte consisting of commercial grade calcium chloride and 10 wt% [20 at.%] calcium oxide, with additions of potassium and sodium chlorides for lowering the melting point, density and viscosity of the salt, has been used in the range of 825– 950 °C.

Electrochemical Principle

The rates of calcium deposition and oxygen evolution are given by the following equations.

Calcium Electrowinning Cell

Cell Parameters

Cell Dimensions

Results

13

 Ionic diffusion through the sheath is the rate- controlling step.

A diffusion coefficient in the range of 10-5-10-6^ cm^2 /sec is obtained for a 30% porous alumina sheath for cell temperatures between 800 and 900°C.
