Introduction: Multipiece Structures

 For the equilibrium of structures made of several

connected parts , the internal forces as well the

external forces are considered.

 In the interaction between connected parts, Newton’s

3 rd^ Law states that the forces of action and reaction

between bodies in contact have the same magnitude ,

same line of action , and opposite sense.

 The Major Categories of Engineering Structures

  • Frames: contain at least one multi-force member, i.e., a member acted upon by 3 or more forces
  • Trusses : formed from two-force members , i.e., straight members with end point connections
  • Machines: structures containing moving parts designed to transmit and modify forces

Definition of a Truss

 A truss consists of straight members connected at joints. No member is continuous through a joint.

 Bolted or welded connections are assumed to be pinned together. Forces acting at the member ends reduce to a single force and NO couple. Only two-force members are considered  LoA CoIncident with Geometry

 A truss carries ONLY those loads which act in its plane , allowing the truss to be treated as a two-dimensional structure.

 When forces tend to pull the member apart, it is in tension. When the forces tend to push together the member, it is in compression.

Trusses Made of Simple Trusses

  • Compound trusses are statically determinant, rigid, and completely constrained. m  2 n  3
  • Truss contains a redundant member and is statically indeterminate. m  2 n  3
  • Necessary but INsufficient condition for a compound truss to be statically determinant, rigid, and completely constrained,

mr  2 n

non-rigid

m  2 n  3

  • Additional reaction forces may be necessary for a nonrigid truss.

rigid m  2 n  4

Method of Sections

 To determine the force in member BD, pass a section through the truss as shown and create a free body diagram for the left side.  With only three members cut by the section, the equations for static equilibrium may be applied to determine the unknown member forces, including FBD

 When the force in only one member or the forces in a very few members are desired, the method of sections works well.

Example  Method of Sections

• Take Section to Expose FFD

 Now Take Σ M E = 0

0  15 kip 10 '  15 kip 20 '  FFD  10 '

45 kip

10ft

150 300 kip ft

FFD  FFD ^45 kip Compression

Example  Method of Sections

 Determine the force in

members just right of Center:

  • FH
  • GH
  • GI

 SOLUTION PLAN

  • Take the entire truss as a free body. Apply the conditions for static equilibrium to solve for the reactions at A and L.
  • Pass a section through members FH , GH , and GI and take the right-hand section as a free body.
  • Apply the conditions for static equilibrium to determine the desired member forces.

Example  Method of Sections

  • Pass a section (n-n) through members FH, GH, and GI and take the right -hand section as a free body

 Apply the conditions for static equilibrium to determine the desired member forces.

       

  1. 13 kN

7.50kN 10 m 1 kN 5 m 5. 33 m 0

 

GI

GI

H

F
F
M

FGI  13. 13 kN T

Example  Method of Sections

           

  1. 82 kN

cos 8 m 0

7.5kN 15 m 1 kN 10 m 1 kN 5 m

15 m

8 m tan

FH

FH

G

F
F
M
GL
FG

FFH  13. 82 kN C

 

        

  1. 371 kN

1 kN 10 m 1 kN 5 m cos 15 m 0

8 m

5 m tan 3 2

GH

GH

L

F
F
M
HI
GI

FGH  1. 371 kN C

Pick: Pivot & PoA

• When doing Sections Recall that the LoA for

Truss Members are defined by the Member

Geometry

• Use Force Transmissibility → Forces are

SLIDING Vectors

– Pick a Pivot Point, on or Off the Body, where the

LoA’s of many Force LoA’s Cross

– Apply the Force of interest so that ONE of its X-

Y Components passes Thru the Pivot

Pick: Pivot & PoA Example

• After Finding support RCNs find force in

Member ED → Use Section a-a

• Pick Pt-B as Pivot to Eliminate from

Moment Calc FAB, FFB, FEB, 1000N
