Topic 10: Organic Chemistry
10.1 Fundamentals of organic chemistry
10.1.1 A homologous series is a series of compounds of the same general formula, which differ from each other by a common
structural unit
10.1.2 Structural formulas can be represented in full and condensed format
10.1.3 Structural isomers are compounds with the same molecular formula but different arrangements of atoms
10.1.4 Functional groups are the reactive parts of molecules
10.1.5 Saturated compounds contain single bonds only and unsaturated compounds contain double or triple bonds
10.1.6 Benzene is an aromatic, unsaturated hydrocarbon
10.1.7 Explanation of the trends in boiling points of members of a homologous series
10.1.8 Distinction between empirical, molecular and structural formulas
10.1.9 Identification of different classes: alkanes, alkenes, alkynes, halogenoalkanes, alcohols, ethers, aldehydes, ketones, esters,
carboxylic acids, amines, amides, nitriles and arenes
10.1.10 Identification of typical functional groups in molecules eg phenyl, hydroxyl, carbonyl, carboxyl, carboxamide, aldehyde, ester,
ether, amine, nitrile, alkyl, alkenyl and alkynyl
10.1.11 Construction of 3D models (real or virtual) or organic molecules
10.1.12 Application of IUPAC rules in the nomenclature of straight-chain and branched chain isomers
10.1.13 Identification of primary, secondary and tertiary carbon atoms I halogenoalkanes and alcohols and primary, secondary and
tertiary nitrogen atoms in amines
10.1.14 Discussion of the structure of benzene using physical and chemical evidence
# C atoms Prefix
1 meth-
2 eth-
3 prop-
4 but-
5 pent-
6 hex-
Homologous series
Homologous series: A series of compounds of the same family, with the same general formula, which differ from each other by a
common structural unit
The main features of a homologous series are:
o Members of a homologous series show a gradation in their physical properties due to the gradual increase of sizes
and weight (example: boiling points increase)
o Members of a homologous series show similar chemical properties as all compounds in the series have the same
functional group (functional groups are the reactive part)
o Successive members of a homologous series differ by a –CH2— group
Members of a homologous series are represented by same formula. They are named by:
o Prefix: # Of carbon atoms in the longest chain
o Suffix: Homologous series to which the compound belongs
Homologous Series Description Formula Suffix
Alkanes Saturated hydrocarbons containing carbon-carbon single bonds -ane
Alkenes Unsaturated hydrocarbons containing carbon-carbon double bonds -ene
Alkynes Unsaturated hydrocarbons containing carbon-carbon triple bonds -yne
Organic compound classes
Each class name contains a specific functional group which is a chemical group (small molecule) that determines the specific chemical
properties of a compound, which in turn determines the type of chemical reactions it undergoes
This means that different compounds/classes in organic chemistry undergo characteristic reactions depending on the functional groups
they contain
o Functional groups are specific groups of atoms or bonds within molecules that are responsible for the characteristic chemical
reaction of those molecules
o A functional group is either named as a prefix or a suffix
Example classes and functional groups include:
Class: Alkane Alkenes Alkynes
Functional Group:
Suffix - ane - ene - yne
Class: Alcohols Aldehyde
Functional Group:
Name/Suffix Hydroxyl - ol Aldehyde - al
Class: Amine Amide
Functional Group:
Name Amines Carboxyamide
Class: Ether Ester Nitrile
pf3
pf4
pf5
pf8
pf9
pfa

Partial preview of the text

Download multiple choice execrises from med and more Schemes and Mind Maps Biology in PDF only on Docsity!

Topic 10: Organic Chemistry

10 .1 Fundamentals of organic chemistry

10 .1.1 A homologous series is a series of compounds of the same general formula, which differ from each other by a common structural unit 10 .1.2 Structural formulas can be represented in full and condensed format 10 .1.3 Structural isomers are compounds with the same molecular formula but different arrangements of atoms 10 .1.4 Functional groups are the reactive parts of molecules 10 .1.5 Saturated compounds contain single bonds only and unsaturated compounds contain double or triple bonds 10 .1.6 Benzene is an aromatic, unsaturated hydrocarbon 10 .1.7 Explanation of the trends in boiling points of members of a homologous series 10 .1.8 Distinction between empirical, molecular and structural formulas 10 .1.9 Identification of different classes: alkanes, alkenes, alkynes, halogenoalkanes, alcohols, ethers, aldehydes, ketones, esters, carboxylic acids, amines, amides, nitriles and arenes 10 .1.10 Identification of typical functional groups in molecules eg phenyl, hydroxyl, carbonyl, carboxyl, carboxamide, aldehyde, ester, ether, amine, nitrile, alkyl, alkenyl and alkynyl 10.1.11 Construction of 3D models (real or virtual) or organic molecules 10 .1.12 Application of IUPAC rules in the nomenclature of straight-chain and branched chain isomers 10.1.13 Identification of primary, secondary and tertiary carbon atoms I halogenoalkanes and alcohols and primary, secondary and tertiary nitrogen atoms in amines 10.1.14 Discussion of the structure of benzene using physical and chemical evidence

C atoms Prefix

1 meth- 2 eth- 3 prop- 4 but- 5 pent- 6 hex-

Homologous series

  • Homologous series: A series of compounds of the same family, with the same general formula, which differ from each other by a common structural unit
  • The main features of a homologous series are:

o Members of a homologous series show a gradation in their physical properties due to the gradual increase of sizes

and weight (example: boiling points increase)

o Members of a homologous series show similar chemical properties as all compounds in the series have the same

functional group (functional groups are the reactive part)

o Successive members of a homologous series differ by a –CH 2 — group

  • ••• Members of a homologous series are represented by same formula. They are named by:

o Prefix: # Of carbon atoms in the longest chain

o Suffix: Homologous series to which the compound belongs

Homologous Series Description Formula Suffix Alkanes Saturated hydrocarbons containing carbon-carbon single bonds - ane Alkenes Unsaturated hydrocarbons containing carbon-carbon double bonds - ene Alkynes Unsaturated hydrocarbons containing carbon-carbon triple bonds - yne

Organic compound classes

  • Each class name contains a specific functional group which is a chemical group (small molecule) that determines the specific chemical properties of a compound, which in turn determines the type of chemical reactions it undergoes
  • This means that different compounds/classes in organic chemistry undergo characteristic reactions depending on the functional groups they contain

o Functional groups are specific groups of atoms or bonds within molecules that are responsible for the characteristic chemical

reaction of those molecules

o A functional group is either named as a prefix or a suffix

  • Example classes and functional groups include: Class: Alkane Alkenes Alkynes Functional Group: Suffix - ane - ene - yne Class: Alcohols Aldehyde Functional Group: Name/Suffix Hydroxyl - ol Aldehyde - al Class: Amine Amide Functional Group: Name Amines Carboxyamide Class: Ether Ester Nitrile

Functional Group: Name Ether Ester Nitrile Class Ketones Carboxylic Acid Arenes Functional Group: Name/Suffix Carbonyl - one Carboxyl Phenyl Class Halogenoalkanes Functional Group: Prefix Fluoro- Chloro- Bromo-

Structural Formulas of Organic Compounds

  • ••• Structural formulas can be represented in full and condensed format

o Full structural formula shows the molecular geometry of the molecule. All bonds must be shown

o Condense structural formula (aka semi-structural) omits all bonds and groups together

  • ••• Skeletal formula (stereochemical formula) shows carbon-to-carbon backbone without any hydrogen atoms, however will show functional groups like Br 2

Structural Isomers

  • Structural Isomers: Compounds with the same molecular formula but different arrangement of atoms
  • Each isomer is a distinct compound having unique physical and chemical properties

Primary, Secondary and tertiary carbon atoms

  • A primary carbon atom is bonded to zero or one other carbon atom
  • A secondary carbon atom is bonded to two other carbon atoms
  • A tertiary carbon is bonded to three other carbon atoms Primary Secondary Tertiary

10.2.13 Writing equations for the complete combustion of alcohols 10.2.14 Writing equations for the oxidation reactions of primary and secondary alcohols (using acidified potassium dichromate (VI) or potassium manganite (VII) as oxidizing agents). Explanation of distillation and in the isolation of the aldehyde and carboxylic acid products 10.2.15 Writing the equation for the condensation reaction of an alcohol with a carboxylic acid, in the presence of a catalyst (eg concentrated sulfuric acid) to form an ester 10.2.16 Writing the equation for the substitution reactions of halogenoalkanes with aqueous sodium hydroxide

Homolytic and Heterolytic bond fission

  • ••• In homolytic bond fission, a covalent bond between two atoms in a molecule breaks with each atom taking one electron from the bond
  • Homolytic bond fission results in the formation of free radicals which are highly reactive species with unpaired electrons
  • ••• In heterolytic bond fission, a covalent bond between two atoms in a molecule breaks with one atom taking both bonding electrons
  • Heterolytic bond fission results in the formation of ions (cation and anion). The more electronegative atom usually takes both bonding electrons

Benzene reactions

  • The Kekulé structure of benzene consists of alternating carbon to carbon single and double bonds
  • The actual structure of benzene is a resonance hybrid structure with equal bonds that are intermediate in length and strength between a single and a double bond
  • Benezene undergoes electrophilic substitution reactions in which a hydrogen atom is replaced by another group

o An electrophile is a species which is electron deficient (either a positive ion or has a positive charge)

  • For instance benzene reacts with chlorine to form chlorobenzene (to the right)

Alkanes Reactions

  • Alkanes undergo very few reactions as they are relatively unreactive
  • This is because the C-H bond is a non-polar bond and the C-C and C-H are relatively strong
  • The two types of reactions that alkanes undergo are combustion reactions and free radical substitution reactions

Combustion

  • ••• Complete combustion (in excess oxygen) of any hydrocarbon produces carbon dioxide and water
  • Provided the combustion is complete, all hydrocarbons will burn with a blue flame
  • However, the bigger the hydrocarbon, the more likely it will burn with a yellow, smoky flame (as it is more difficult to completely combust)
  • An incomplete combustion (lack of oxygen) can lead to the formation of carbon or carbon monoxide. I.e. the hydrogen in the hydrocarbon reacts with the oxygen first, then the carbon gets to react with the rest
  • Incomplete combustion produces carbon monoxide and water

o Carbon monoxide is produced as a colorless poisonous gas

o Carbon monoxide binds irreversibly (or very strongly) making a particular molecule of hemoglobin useless for carrying

oxygen

o If you breath in enough carbon monoxide you will die from a sort of internal suffocation

  • The chemical equation for the complete combustion of alkanes is:
  • The chemical equation for incomplete combustion of alkanes is:
  • A good technique to balancing these types of equations are to use CHOD (Carbon, Hydrogen, Oxygen, Double) Example: Propane Combustion With propane (C 3 H 8 ), you can balance the carbons and hydrogens as you write the equation down. Balance alkanes, carbon dioxide and water first. Then balance the oxygens:
  • Hydrocarbons become harder to ignite as the molecules get bigger. This is because bigger molecules don’t vaporize so easily. Furthermore, bigger molecules have greater Van der Waals attractions which makes it more difficult for them to break away from their neighbors and turn to gas

Free radical substitution

  • Alkanes undergo free radical substitution reactions
  • In a substitution reaction, an atom or group of atoms is replaced by another atom or group
  • The most common type of substitution reactions of alkanes involve halogenation
  • ••• Substitution reactions happen in which hydrogen atoms are replaced one by one by a halogen
  • Unlike the complex transformations of combustion, the halogenation of an alkane appears to be a simple substitution reaction in which a C-H bond is broken and a new C-X bond is formed
  • Replacing hydrogen atoms in an alkane molecule with chlorine or bromine is called chlorination or bromination
  • This type of reaction requires a catalyst to active the reaction usually in the form of UV light
  • Free radicals are species with unpaired electrons which are represented by a dot
  • We describe the substitution of a halogen by a sequence of steps known as a reaction mechanism. The three stages of the mechanism are called initiation (known as photochemical homolytic fusion), propagation and termination Initiation:
  • Initiation occurs in the presence of UV light
  • Photochemical homolytic fission then occurs where the bond between the halogen (in this case Bromine) is broken by UV light which produces two halogen radicals (two bromine radicals)
  • In initiation steps the number of free radicals increases Propagation:
  • In propagation these reactions keep the chain reaction going

o First the bromine free radical will then react with methane to produce a methyl radical and hydrogen bromide (the hydrogen

will bond with the bromine radical)

o Then the methyl radical (produced in the first propagation step) will react with a bromine molecule to produce

bromomethane and a bromine radical

o CH 3 Br can continue to react through similar propagation steps to form CH 2 Br 2 , CHBr 3 and eventually CBr 4

  • In propagation the number of free radicals stays the same Termination:
  • Free radicals react with each other to form molecules. Since the radicals are much more reactive than the molecules, the reaction stops when there are no more radicals
  • In termination steps the number of free radicals decreases

Tests for unsaturation

  • Bromine water can be used to distinguish between an alkane and an alkene

o Bromine water has a distinctive brown color

  • Alkenes are more reactive than alkanes due to their double carbon bond
  • ••• Alkenes react spontaneously with bromine water due to their unsaturated nature

o When alkenes come into contact with bromine water, they cause it to decolorize

o An addition reaction will take place and results with an alkane with two bromine functional groups

  • ••• Alkanes do not react with spontaneously bromine water due to their saturated nature

o When alkanes come into contact with bromine water, there is no color change

Alkene reactions

  • Alkenes undergo electrophilic addition reactions in which two molecules combine to produce a larger molecule (which also breaks the double bond). The types of reactions include:

Hydrogenation

  • An alkene reacts with hydrogen to form an alkane
  • The double C=C bond is broken and converted to a C-C single bond. The H 2 then breaks open and attaches itself as two individual H atoms to the carbon in the question
  • Catalyst used in this reaction: Finely divided nickel

Hydration

  • An alkene reacts with steam to form an alcohol
  • The double C=C bond is broken and is converted into a C-C single bond
  • H 2 O then breaks open and attaches itself as H and OH to the carbon atoms that are now open
  • Catalyst used in this reaction: H 2 SO 4

Halogenation

  • Alkenes react with halogens to produce dihalogen compounds

Addition Polymerization:

  • Addition polymers are formed when smaller unsaturated molecules (monomers) react together

o PVC or poly (vinyl chloride) is a polymer made from the monomer unit chloromethane (vinyl chloride)

o Poly (propene) is an additional polymers made from the monomer unit propene

o The polymerization of 2-methylpropene forms the polymer poly (2-methylpropene) or butyl rubber

  • In addition polymerization, small monomers that contain a C=C double bond link together to form a longer polymer
  • During the process the double bonds in the monomers are converted into single bonds in the polymer

Alcohol Reactions

  • Alcohols are molecules containing the hydroxyl functional group (- OH) that is bonded to the carbon
  • The hydroxyl functional group strongly contributes to the physical properties of alcohols. The hydroxyl group is polar so increases the solubility of alcohol in water
  • Chemical reactions in alcohols occur mainly at the functional group, but some involve hydrogen atoms attached to the OH-
  • Alcohols undergo three major kinds of alcohol reactions:

Oxidation

  • Because a variety of oxidizing agents can bring about oxidation, the symbol above the arrow indicates an oxidizing agent without specifying a particular one
  • Oxidation reactions with alcohols are used to make aldehydes, ketones and carboxylic acids
  • They can also be a way to distinguish between primary, secondary and tertiary alcohols

o Primary alcohols are oxidized to form aldehydes and can be oxidized again to form carboxylic acid

o Secondary alcohols are oxidized to form ketones

o Tertiary alcohols are not readily oxidized

  • The oxidizing agent used in these creations are normally a solution of potassium (VI) dichromate (K 2 Cr 2 O 7 ) Primary Alcohols:
  • The oxidation of any primary alcohol is a two-step process that first produces an aldehyde which is then further oxidized to a carboxylic acid
  • The alcohol is heated under reflux with an excess of the oxidizing (put heat under arrow in equation) and using K 2 Cr 2 O 7
  • When the reaction is complete, the carboxylic acid is distilled off

2 0. 1 Types of organic reactions Nucleophilic Substitution Reactions: 20.1.1 SN1 represents a nucleophilic unimolecular substitution reaction and SN2 represents a nucleophilic bimolecular substitution reaction 20 .1.2 For tertiary halogenoalkanes the predominant mechanism is SN1 and for primary halogenoalkanes it is SN2. Both mechanisms occur for secondary halogenoalkanes 20.1.3 The rate determining step (slow step) in an SN1 reaction depends only on the concentration of the halogenoalkane, For SN2,. SN2 is stereospecific with an inversion of configuration at the carbon 20.1.4 SN2 reactions are best conducted using aprotic, non-polar solvents and 2N1 reactions are best conducted using protic, polar solvents Electrophilic Addition Reactions: 20.1.5 An electrophile is an electron-deficient species that can accept electron pairs from a nucleophile. Electrophiles are Lewis acids 20.1.6 Markovnikov’s rule can be applied to predict the major product in electrophilic addition reactions of unsymmetrical alkenes with hydrogen halides and interhalogens. The formation of major product can be explained in terms of the relative stability of possible carbon cations in the reaction mechanism Electrophilic Substitution Reactions: 20.1.7 Benzene is the simplest aromatic hydrocarbon compound (or arene) and has a delocalized structure of bonds around its ring. Each carbon to carbon bond has a bond order of 1.5. Benzene is susceptible to attack by electrophiles Reduction Reactions: 20.1.8 Carboxylic acids can be reduced to primary alcohols (via the aldehyde). Ketones can be reduced to secondary alcohols. Typical reducing agents are lithium aluminum hydride (used to reduce carboxylic acids) and sodium borohydride Nucleophilic Substitution Reactions 20.1.9 Explanation of why hydroxide is a better nucleophile than water 20.1.10 Deduction of the mechanism of the nucleophile substitution reactions of halogenoalkanes with aqueous sodium hydroxide in terms of SN1 and SN2 mechanisms. Explanation of how the rate depends on the identity of the halogen (ie the leaving group), whether the halogenoalkane is primary, secondary or tertiary and the choice of solvent 20.1.11 Outline the difference between protic and aprotic solvents Electrophilic Addition Reactions 20.1.12 Deduction of the mechanism of the electrophilic addition reactions of alkenes with halogens/interhalogens and hydrogen halides Electrophilic Substitution Reactions: 20.1.13 Deduction of the mechanism of the nitration (electrophilic substitution) reaction of benzene (using a mixture of concentrated nitric acid and sulfuric acid) Reduction Reactions: 20.1.14 Writing reduction reactions of carbonyl containing compounds: aldehydes and ketones to primary and secondary alcohols and carboxylic acids to aldehydes, using suitable reducing agents. 20.1.15 Conversion of nitrobenzene to phenylamine via a two-stage reaction. Definitions Nucleophile: An electron rich species that can donate a pair of electrons to form a covalent bond (Acts like a Lewis base). i.e. they are strongly attracted to a region of positive charge. OH-^ is a better nucleophile than H 2 O because it has a negative charge whilst the water molecular only has a dipole. Therefore it is more attracted Leaving group – A substituent which easily withdraws its bonding electrons to form a separate, stable species

Nucleophilic Substitution Reactions

  • There are two major classes of nucleophilic substitution reactions: SN1 and SN 2
  • This can be thought of like cats. Cat #1 finds Cat #2 on his comfy chair and wants to sit. He has two option:

o He can wait for Cat #2 to leave, and then sit in the comfy chair

o Or he can be a bitch and kick Cat #2 out of the comfy chair

  • Situation 1 resembles SN1 reactions, and Situation 2 represents SN2 reactions. The chair is the solvent, Cat #1 is nucleophile
  • In the substitution reaction where the halogen is substituted, the halogen is referred to as the leaving group (Cat #2)
  • Halogenoalkanes undergo nucleophilic substitution reactions as the bond between the carbon atoms and the halogen is polar as the halogen is highly electronegative giving the carbon atoms a partial positive charge

SN 1 : Nucleophilic unimolecular substitution reaction

  • SN 1 is a two step reaction that involves the formation of a carbocation intermediate
  • As SN1 reaction initiates, the leaving group will depart from the substrate, and in doing so creates a stable intermediate
  • However, soon after the nucleophile will attack and bond to the intermediate which results in the final product
  • Note there is a complete loss of stereochemistry as the nucleophile can bond anywhere
  • The reaction is unimolecular. The rate determining step depends on the concentration of the leaving group only
  • ••• Tertiary halogenoalkanes undergo SN1 reactions (so replace leaving group with the halogen name when explaining)
  • Some factors favoring SN1 reactions include:

o Weak nucleophiles

o More substitute substrates

o Better leading groups

o Solvent charge

SN 2 : Nucleophilic biomolecular substitution reaction

  • SN 2 is a one step reaction that involves the formation of an unstable transition state
  • The nucleophile will first attack the opposite side of the leaving group, despite the leaving group haven’t not departed yet
  • An unstable transition state is then formed in which the carbon is weakly bonded to the leaving group and the nucleophile
  • The carbon to the leaving group breaks heterolytically and the leaving group departs
  • The backside attack causes an inversion of stereochemistry
  • The rate is bimolecular. The rate determining step (slow step) depends on both the concentration of the leaving group and the nucleophile
  • ••• Primary halogenoalkanes undergo SN2 reactions (so replace leaving group with the halogen name when explaining)
  • Some factors favoring SN2 reactions:

o Good nucleophiles

o Less substituted substrates

o Poor leaving groups

SN 1 SN 2

Mechanism Two step mechanism Single connected step Kinetics First order kinetics Second order kinetics: Stereochemistry Loss of stereochemistry Sterochemical inversion Nucleophile* Weak Strong Substrate* Highly substituted Less substituted Leaving group* Good Poor *Favorable conditions

Choice of solvent

  • A protic solvent is one in which there is a hydrogen atom attached to an oxygen or nitrogen atom and that is capable of being donated
  • ••• Polar, protic solvents are preferred for SN1 reactions
  • Examples of commonly used protic solvents include: water, methanol, ethanol, methanoic acid and ethanoic acid
  • An aprotic solvent is one which does not possess a hydrogen atom that is capable of being donated. Aprotic solvents can be polar or non-polar. Common examples include: propanone and ethyl ethanoate (both polar) as well as hexane and benzene (non-polar) Polar, protic solvents are preferred for SN1 reactions
  • ••• Non-polar, aprotic solvents are preferred for SN2 reactions

Electrophilic addition reactions

Definitions Electrophile: An electron deficient species that can accept an electron pair to form a new covalent bond (Acts like a Lewis Acid)

  • An addition reaction is a reaction in which two molecules join together to make a bigger one
  • Nothing is lost in the process and all the atoms in the original molecules are found in the bigger one
  • An electrophilic addition reaction is an addition reaction where a molecule with a region of high electron density is attacked by something carrying some degree of positive charge
  • Electrophilic addition reactions involves any alkane with molecules such as halogens or hydrogen halides
  • The δ+ hydrogen atom of H-Br is attracted towards the C=C in ethene. The two electrons from the π -bond in the C=C attack the hydrogen atom and, at the same time, the H−Br bond breaks to form a bromide ion
  • A lone pair of electrons on the bromide ion attacks the positively-charged carbon atom on the carbocation intermediate forming a coordinate bond
  • The correct drawing for the mechanism includes curly arrows and lone pairs of electrons

Markovnikov’s Rule

  • Markovnikov’s rule helps to determine which atoms in an electrophile join to which of the two carbon atoms in a C=C
  • As you can see the hydrogen and bromine can be bonded to two different spots (as shown by major and minor)
  • To decide which one bonds where remember “the hydrogen rich get richer”
  • In other words the carbon with the more hydrogen will gain more hydrogen
  • Major is used to describe the more likely structure
  • Markovnikov’s rule only applies to asymmetrical alkenes where two products are possible (does not apply to ethene)

Nitration of benzene

  • Benzene reacts with a mixture of concentrated nitric acid (HNO 3 ) and concentrated sulfuric acid (H 2 SO 4 ) to form nitrobenzene (C 6 H 5 NO 2 ) and water
  • This reaction requires a H 2 SO 4 catalyst, and roughly 55°C
  • The nitration of benzene involves the electrophilic substitution mechanism:

o A pair of electrons from the π - system attacks the NO 2 +^ electrophile forming a coordinate bond and destroying the

delocalization

o The HSO 4 −^ ion acts as a base, pulling off a hydrogen atom and reforming sulfuric acid

o The C−H bond breaks and the two electrons reform the delocalized π -system

  • Also referred to as functional group isomers, these are isomers where the molecular formula remains the same, but the type of functional group in the atom is changed. This is possible by rearranging the atoms within the molecule so that they’re bonded together in different ways

Stereoisomerism

  • Stereoisomerism have different spatial arrangement of atoms
  • There are two types of stereoisomerism: Geometric isomerism, and optical isomerism Geometric isomerism

Conformational isomerism: Interconvert by rotation around the sigma bond

  • This type of isomerism most frequently involves carbon double bonds
  • This means that the rotation of these bonds is restricted, compared to single bonds, which can rotate freely
  • In other words if there are two different atoms, or groups of atoms, they can be arranged in different ways to give different molecules

Configurational isomerism: Interconvert only by breaking a bond

  • Optical isomers are so named due to their effect on plane-polarized light and come in pairs
  • They usually (although not always) contain a chiral center, which is a carbon atom, with four different atoms attached to it
  • These atoms or groups can be arranged differently around the central carbon in such as a way that the molecule can’t be rotated to make the two arrangements align. This is referred to as “non-superimposable mirror images” where one of the isomers is the mirror image of the other Cis-trans isomerism:
  • Cis-trans isomerism occurs when there is restricted rotation around a bond either because of a double bond or as a result of the ring structure in a cyclic molecule
  • Cycloalkanes contain a ring structure that restricts rotation. When the molecule contains two or more different groups attached to the ring, two different isomers are formed

o Cis isomers have the same groups on the same side of the double bond/ring

o Trans isomers have the same groups on opposite sides of the double bonds/ring

E/Z/ Isomerism

  • A chiral carbon is a carbon atom bonded to four different atoms or groups Optical isomerism
  • A chiral carbon is a carbon atom bonded to four different atoms or groups
  • Mirror images are non-superimposable and are known as enantiomers
  • Diastereomers are stereoisomers that are non-superimposable but not mirror images
  • Ordinary light consists of waves that vibrate in all planes perpendicular to its direction of travel
  • Plane-polarized light consists of waves vibrating in one plane only
