Multiscale transforms : wavelets, ridgelets,

curvelets, etc.

Outline :

  • The Fourier transform
  • Time-frequency analysis and the Heisenberg principle
  • Cauchy Schwartz inequality
  • The continuous wavelet transform
  • 2D wavelet transform
  • Anisotropic frames : Ridgelets, curvelets, etc.

The Fourier transform (1)

  • Diagonal representation of shift invariant linear transforms.
  • Truncated Fourier series give very good approximations to smooth functions.
  • Limitations :
  • Provides poor representation of non stationary signals or image.
  • Provides poor representations of discontinuous objects (Gibbs effect)

What is good representation for data?

  • Computational harmonic analysis seeks representations of s signal as linear combinations of basis, frame, dictionary, element :
  • Analyze the signal through the statistical properties of the coefficients
  • The analyzing functions (frame elements) should extract features of interest.
  • Approximation theory wants to exploit the sparsity of the coefficients.

coefficients basis, frame

Seeking sparse and generic representations

  • Sparsity
  • Why do we need sparsity?
    • data compression
    • Feature extraction, detection
    • Image restoration

sorted index

few big

many small

Heisenberg uncertainty principle

  • Different tilings in time frequency space :
  • Localization in time and frequency requires a compromise

Windowed/Short term Fourier transform

  • Invertibility condition :
  • Reconstruction :
  • Decomposition :

with

( with a gaussian window w, this is the Gabor transform)

Continuous Wavelet Transform

  • Example : The mexican hat wavelet

2D Continuous Wavelet transform

  • either a genuine 2D wavelet function (e.g. mexican hat) or a separable wavelet i.e. tensor product of two 1D wavelets.
  • example :

Images obtained using the nearly isotropic undecimated wavelet transform obtained with the a trous algorithm.

Continuous Ridgelet Transform

Ridgelet function:
The function is constant along lines.Transverse to these ridges, it is a wavelet.
Ridgelet Transform (Candes, 1998):

Rf  a , b ,    a , b ,   x f x   dx

 a , b ,    x  a

1

2  x^1 cos(^ )^ ^ x^2 sin(^ )^ ^ b

a

The ridgelet coefficients of an object f are given by analysis
of the Radon transform via:



Rf ( a , b , )  Rf ( , t ) (

tb

a

 ) dt

  • SNR = 0.
Ridgelet Filtering (5sigma)

Local Ridgelet Transform

The ridgelet transform is optimal to find only lines of the size of the image.
To detect line segments, a partitioning must be introduced. The image is
decomposed into blocks, and the ridgelet transform is applied on each block.
Partitioning
Ridgelet
transform
