For the Workshop II project, our group should analyze, plan, execute and manage tasks. Project assignments have been assigned to each group and the group should create a schedule to complete the assigned assignments on time and set the services provided for each group member. To avoid problems and mistakes, time and schedule management is important. Our main objective for Workshop II was to succeed through the challenges faced while completing the assigned tasks. In addition, having a deeper understanding of the service and knowing how it works is part of the objectives of this project. The result of this project is that students should be able to design a secure network infrastructure and be able to perform the specified network and security services. Students should be able to maintain and control a secure network service infrastructure. Our group decided to use GNS3 to simulate our network topology and connect to Windows platform and Linux platform. Our group uses Windows Server 201
Typology: Thesis
1 / 212
This page cannot be seen from the preview
Don't miss anything!
First and foremost, we want to express our gratitude to TS. Irda Binti Roslan, our project supervisor for her invaluable guidance and advice. Our supervisor motivated us to work on the project and provided guidance on how to accomplish all the services. Nevertheless, she also inspires us to contribute significantly to our project. In addition, we'd want to express our gratitude to our seniors for providing samples of the services we chose for our project that helped us understand better. This allows us to gain a better understanding of the service and finish our job on schedule. Next, we'd like to express our gratitude to our project evaluator, TS. Marliza Ramly for her time and effort in-term of evaluating us. Furthermore, we would also want to express our gratitude to Universiti Teknikal Malaysia Melaka (UTeM) for providing us with a conducive environment and facilities in which to finish this project. Finally, we want to extend our thanks to our family and friends for their patience and support in assisting us finish this project. Even those who experienced troubles while we were completing this project were able to overcome those obstacles with their assistance, and we were able to complete our project on schedule.
Untuk projek Workshop II, kumpulan kami harus menganalisis, merancang, melaksanakan dan menguruskan tugas. Tugasan projek telah diberikan kepada setiap kumpulan dan kumpulan tersebut harus membuat jadual untuk menyelesaikan tugasan yang diberikan tepat pada waktunya dan menetapkan servis yang disediakan untuk setiap ahli kumpulan. Untuk mengelakkan masalah dan kesilapan, pengurusan masa dan jadual adalah penting. Objektif utama kami untuk Bengkel II adalah untuk berjaya melalui cabaran yang dihadapi semasa menyelesaikan tugasan yang diberikan. Selain itu, mempunyai pemahaman yang lebih mendalam mengenai servis dan mengetahui cara kerjanya adalah sebahagian daripada objektif projek ini. Hasil dari projek ini ialah pelajar seharusnya dapat merancang infrastruktur rangkaian yang selamat dan dapat melaksanakan servis rangkaian dan keselamatan yang ditentukan. Pelajar harus dapat mengekalkan dan mengawal infrastruktur perkhidmatan rangkaian yang selamat. Kumpulan kami memutuskan untuk menggunakan GNS3 untuk mensimulasikan topologi rangkaian kami dan menyambung ke platform Windows dan platform Linux Kumpulan kami menggunakan Windows Server 2012 R2 dan Linux Ubuntu 18.04 LTS sebagai system operasi pelayan kerana kedua-duanya mempunyai banyak kebaikan untuk melaksanakan perkidmatan rangkaian ini. Untuk Bengkel II ini, kumpulan kami telah ditugaskan untuk membuat 17 servis iaitu Inter VLAN routing, VLSM addressing, Routing & NAT, DNS (IPv4 & IPv6), Active Directory; with minimum of 2 UAC/GPO (main), Join domain, DHCP (IPv4 & IPv6), Linux Email Server (main), Firewall – LINUX FIREWALL, Basic security policy, Layer 2 Security – VLAN and Port Security, Network Management System (main), IPSec site-to-site tunnelling (main), AAA (Authentication, Authorization, and Accounting) using Radius, Access Control List (ACL); with minimum of 4 rules, Cloud Storage, Web (IPv4 and IPv6 with SSL) with IPv6 Tunnelling, IDS – Port mirroring (customized rule).
1.1 Introduction This semester some students will be take subject BITU 3923, Workshop II which is from BITC students before they need to take Final Year Project. For this Workshop, there are about 15 group that have been divided each group contain 4 to 5 members. For this project, students are required to analyse, design, build, manage, and integrate network services infrastructure that suit with the network environment to achieve excellent, safe and protected network. This Workshop II, we will be doing it remotely due to the pandemic that occur to our entire world that prevent us to work together and face to face. We have been provided with proper equipment in the lab computer at the faculty that be available to use. The tools that have been provided are ISO Ubuntu 16, ISO Windows 2012, VMWare, VNC and GNS3. This course is implemented from all the other BITC students’ previous subjects that have been learned before. Based on the equipment that have been provided above, we required to design, set up and monitor a network environment with the basic server application and basic services. There are multiple different Operating Systems that are required to install in each server. There are about 15 services given to BITC students set up the network which are DNS (IPv4 & IPv6), Linux Mail, DHCP (IPv4 & IPv6), VPN(Virtual Private Network), Routing & NAT, Access Control List (ACL), Active Directory, Intrusion Detection System(IDS), Proxy Server, AAA (Authentication, Authorization, and Accounting using Radius), Layer 2 Security(Port Security), IPv6 Transition Mechanism, Web, SSL & Virtual Hosting, Network Management System, and Inter VLAN.
1.2 Objective
