Lecture 21

Network Security

slides are modified from Dave Hollinger Docsity.com

Chapter 8: Network Security

Chapter goals:

• understand principles of network security:
  • cryptography and its many uses beyond “confidentiality”
  • authentication
  • message integrity
• security in practice:
  • firewalls and intrusion detection systems
  • security in application, transport, network, link layers

What is network security?

Confidentiality: only sender, intended receiver should “understand” message contents

• sender encrypts message
• receiver decrypts message

Authentication: sender, receiver want to confirm identity of each other

Message integrity: sender, receiver want to ensure message not altered (in transit, or afterwards) without detection

Access and availability: services must be accessible and available to users

Friends and enemies: Alice, Bob, Trudy

• well-known in network security world
• Bob, Alice (lovers!) want to communicate “securely”
• Trudy (intruder) may intercept, delete, add messages

secure sender

secure receiver

channel data, control messages

data data

Alice (^) Bob

Trudy

There are bad guys (and girls) out there!

Q: What can a “bad guy” do?

A: A lot! See section 1.

• eavesdrop: intercept messages
• actively insert messages into connection
• impersonation: can fake (spoof) source address

in packet (or any field in packet)

• hijacking: “take over” ongoing connection by

removing sender or receiver, inserting himself

in place

• denial of service : prevent service from being

used by others (e.g., by overloading resources)

Chapter 8 roadmap

8.1 What is network security?

8.2 Principles of cryptography

8.3 Message integrity

8.4 Securing e-mail

8.5 Securing TCP connections: SSL

8.6 Network layer security: IPsec

8.7 Securing wireless LANs

8.8 Operational security: firewalls and IDS

Simple encryption scheme

substitution cipher: substituting one thing for another

• monoalphabetic cipher: substitute one letter for another

10

plaintext: abcdefghijklmnopqrstuvwxyz

ciphertext: mnbvcxzasdfghjklpoiuytrewq

Plaintext: bob. i love you. alice ciphertext: nkn. s gktc wky. mgsbc

E.g.:

Key: the mapping from the set of 26 letters to the set of 26 letters

Polyalphabetic encryption

• n monoalphabetic cyphers, M 1 ,M 2 ,…,M n

• Cycling pattern:

• e.g., n=4, M 1 ,M 3 ,M 4 ,M 3 ,M 2 ; M 1 ,M 3 ,M 4 ,M 3 ,M 2 ;

• For each new plaintext symbol, use

subsequent monoalphabetic pattern in cyclic

pattern

• dog: d from M 1 , o from M 3 , g from M (^4)

• Key: the n ciphers and the cyclic pattern

Types of Cryptography

• Crypto often uses keys:

• Algorithm is known to everyone
• Only “keys” are secret

• Public key cryptography

• Involves the use of two keys

• Symmetric key cryptography

• Involves the use one key

• Hash functions

• Involves the use of no keys
• Nothing secret: How can this be useful?

Symmetric key cryptography

symmetric key crypto: Bob and Alice share same (symmetric) key: K

• e.g., key is knowing substitution pattern in mono alphabetic substitution cipher Q: how do Bob and Alice agree on key value?

14

ciphertext plaintext

K S

encryption algorithm

decryption algorithm

S

K S

plaintext message, m K (^) S (m) m = K^ S (K^ S (m))

Stream Ciphers

• Combine each bit of keystream with bit of plaintext to get bit of ciphertext
• m(i) = ith bit of message
• ks(i) = ith bit of keystream
• c(i) = ith bit of ciphertext
• c(i) = ks(i) ⊕ m(i) (⊕ = exclusive or)
• m(i) = ks(i) ⊕ c(i)

16

keystream key (^) generator keystream

pseudo random

RC4 Stream Cipher

• RC4 is a popular stream cipher

• Extensively analyzed and considered good
• Key can be from 1 to 256 bytes

Block ciphers

• How many possible mappings are there for k=3?

• How many 3-bit inputs?
• How many permutations of the 3-bit inputs?
• Answer: 40,320 ; not very many!

• In general, 2 k^! mappings; huge for k=

• Problem:

• Table approach requires table with 2 64 entries, each

entry with 64 bits

• Table too big: instead use function that

simulates a randomly permuted table

Prototype function

20

64-bit input

S 1

8bits

8 bits

S 2

8bits

8 bits

S 3

8bits

8 bits

S 4

8bits

8 bits

S 7

8bits

8 bits

S 6

8bits

8 bits

S 5

8bits

8 bits

S 8

8bits

8 bits

64-bit intermediate

64-bit output

Loop for n rounds

8-bit to 8-bit mapping

From Kaufman et al
